Automatic mm / inch conversion · Core engineering specifications
| overall dimensions (2-seat + 2-seat combined) | 3200 x 850 x 820 mm | |
|---|---|---|
| single 2-seat module dimensions | 1600 x 850 x 820 mm | |
| seat height from floor to seat top | 420 mm | |
| seat depth (front edge to back cushion face) | 620 mm | |
| back cushion height | 450 mm | |
| armrest height from seat top | 180 mm | |
| armrest width | 120 mm | |
| throw pillow dimensions | 450 x 450 mm | |
| metal support foot height | 30 mm | |
| seat cushion thickness | 150 mm | |
| back cushion thickness | 200 mm | |
| bottom plinth trim width | 80 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| total product weight (combined set) | 140 kg | |
|---|---|---|
| static load capacity per seat position | 150 kg | |
| seat foam density | 45 kg/m³ | |
| back foam density | 30 kg/m³ | |
| upholstery abrasion resistance (Martindale) | 50000 cycles | |
| foam rebound rate | 45% | |
| accompanying throw pillow count | 4 | |
| recommended maximum occupancy | 4 adults | |
| total product weight (combined 2-module set) | 140 kg | |
| seat cushion foam density | 45 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer frame (arms, base trim) upholstery | Matte orange synthetic leather (PU leatherette), 1.2mm thickness | |
|---|---|---|
| seat and back cushion upholstery | Matte cream/off-white synthetic leather (PU leatherette), 1.0mm thickness | |
| internal support frame | Kiln-dried solid pine wood + 15mm plywood structural panels | |
| seat cushion core | High-density polyurethane foam wrapped in 20mm soft dacron batting | |
| back cushion core | Medium-density polyurethane foam blended with 20% down alternative fiber filling | |
| throw pillow filling | 100% hollow conjugated polyester fiber fill | |
| base support feet | Brushed 304 stainless steel, square profile | |
| stitching specification | Coordinated color bonded nylon thread, 8 stitches per 30mm seam distance | |
| base plinth structure | 18mm particleboard substrate wrapped in matching orange upholstery | |
| outer frame (arms, base plinth) upholstery | Matte orange PU synthetic leather, 1.2mm thickness | |
| seat and back cushion face upholstery | Matte cream off-white PU synthetic leather, 1.0mm thickness | |
| internal structural frame | Kiln-dried solid pine wood + 15mm plywood reinforcement panels |
Adjustment / rotation / tilt / mobility / storage features
| modular configuration | Two identical 2-seat units connected by integrated alignment brackets at adjoining arms, arranged as a straight 4-seat configuration | |
|---|---|---|
| back cushion support | Removable loose back cushions secured by hidden hook and loop fasteners to prevent sliding, allowing removal for cleaning or cushion rotation | |
| seat cushion design | Fixed semi-attached seat cushions stitched to the base frame to prevent shifting during use, with visible panel seams dividing seating positions | |
| armrest design | Fully padded wide armrests on both outer ends and adjoining module sides, providing uniform arm support for all seating positions | |
| floor protection | Low-profile stainless steel feet elevate the base 30mm above floor level, preventing floor scuffing and enabling easy cleaning beneath the sofa | |
| cleanability feature | Smooth non-porous upholstery surface enables wipe-down cleaning with standard mild upholstery cleaners, suitable for high-traffic public reception areas | |
| reconfiguration capability | Modules can be separated for use as individual 2-seat sofas, or reconnected into L-shapes (with additional corner module purchase) for custom reception layouts | |
| permanent compression set resistance | Seat foam specified to retain 95% of original thickness after 3 years of standard commercial use | |
| modular connection system | Two identical 2-seat units connected by integrated steel alignment brackets at adjoining arms, forming a straight 4-seat configuration | |
| back cushion retention | Removable loose back cushions secured by hidden hook and loop fasteners to prevent sliding, allowing removal for spot cleaning or periodic cushion rotation | |
| seat cushion anchoring | Fixed semi-attached seat cushions secured to the base frame with hidden fabric clips to prevent shifting during ingress/egress, with visible stitched seams dividing individual seating positions | |
| armrest support structure | Fully padded wide armrests integrated on both outer ends and adjoining module sides, providing uniform 180mm high arm support for all 4 seating positions |
Verified carton / gross weight / assembly / loading data
| number of shipping packages | 2 | |
|---|---|---|
| single carton dimensions (per module) | 1680 x 920 x 600 mm | |
| total gross shipping weight | 165 kg | |
| total shipping volume (CBM) | 1.86 CBM | |
| assembly time on site | 20 minutes | |
| 20ft GP container loading quantity | 14 sets | |
| 40ft HQ container loading quantity | 36 sets | |
| packaging material specification | 5-layer corrugated carton, 20mm thick EPE foam wrapping, corner hardboard protectors | |
| total shipping volume | 1.86 CBM | |
| on-site assembly time | 20 minutes |
Recommended spaces / users / usage modes
| corporate office reception areas | Suitable for lobby and waiting zones, with two-tone professional color scheme that complements modern minimalist office interiors | |
|---|---|---|
| residential open-plan living rooms | Appropriate for contemporary apartment seating, with low-profile compact depth that suits smaller living spaces without overwhelming the room | |
| executive private office lounge zones | Can be positioned adjacent to executive desks for informal guest seating, with durable easy-clean upholstery suitable for daily visitor use | |
| shared co-working space common areas | Designed for high-traffic public waiting and breakout use, with commercial grade upholstery and frame construction rated for frequent occupancy | |
| small commercial lounge and cafe waiting areas | Provides formal yet comfortable seating for boutique hospitality spaces, with modular design that can be adapted to different floor plan layouts | |
| healthcare clinic waiting rooms | Easy-clean non-porous upholstery supports regular sanitization, with supportive seat height suitable for users of varying mobility levels | |
| corporate office reception lobbies | Suitable for main entrance waiting zones, with a professional two-tone color scheme that complements modern minimalist office interior design | |
| shared co-working space breakout areas | Designed for high-traffic public waiting and casual collaboration use, with commercial grade upholstery and frame construction rated for frequent daily occupancy |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture - Seating - Determination of stability, applicable for verifying static stability of the sofa under normal use loads | |
|---|---|---|
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable for structural strength and cyclic load testing for commercial-adjacent use | |
| EN 13759:2011 | Furniture - Seating - Test methods for the determination of durability of upholstered seating mechanisms, applicable for modular connection strength testing |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety, dimension tolerance, and surface finish quality verification of the wood internal frame | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission testing of wood panel components | |
| GB/T 1952.1-2012 | Upholstered furniture - Sofa, applicable for sofa durability, load bearing, foam performance, and structural stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety, dimension tolerance, and surface finish quality verification of the wood internal frame; 2. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission testing of wood panel components; 3. GB/T 1952.1-2012: Upholstered furniture - Sofa, applicable for sofa durability, load bearing, foam performance, and structural stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
