Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2000 x 850 x 850 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 850 x 850 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Side table overall dimensions | 600 x 600 x 550 mm | |
| Sofa seat height from floor | 420 mm | |
| Sofa seat depth | 550 mm | |
| Sofa armrest height from seat | 200 mm | |
| Sofa backrest height from seat | 430 mm | |
| Chrome sofa/chair leg height | 50 mm | |
| Coffee table glass top thickness | 12 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set net weight range | 145 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Seating recommended user count | 5 people total | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam density for seat cushions | 45 kg/m³ | |
| Seat cushion foam density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Seam tensile strength | 150 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Black smooth faux leather (PU leather) | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Backrest core | Medium-density polyurethane foam | |
| Seating support frame | 1.2 mm thick powder-coated steel inner frame | |
| Seating legs | Polished chrome-plated steel angled feet | |
| Table tops (coffee + side tables) | 12 mm thick black tempered glass | |
| Table frames | Brushed/polished chrome-plated square steel tube frames | |
| Seat seam construction | Reinforced stitched seams with 8 stitches per inch | |
| Protective feet pads | Non-slip plastic floor glides fitted to metal legs | |
| Seating support system | 50 mm wide elastic webbing, 40 mm spacing under seat cushions | |
| Seating inner frame | 1.2 mm thick cold-rolled steel tube, anti-rust phosphate pretreatment | |
| Upholstery backing | 100 g/m² non-woven fabric backing under all upholstered panels |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular 1+1+3 layout with matching tables | |
|---|---|---|
| Table surface function | Flat scratch-resistant tempered glass tops support placement of reading materials, drinks, decorative items and table lamps | |
| Seating support design | Fixed tight seat and back cushions provide upright formal support for short to medium visitor wait times | |
| Table frame stability | Welded open chrome steel frames eliminate wobble for regular commercial use | |
| Floor protection function | Non-slip glides on all legs prevent scratching of polished tile or stone flooring and reduce sliding during use | |
| Upholstery maintenance feature | Smooth non-porous faux leather surface can be wiped clean with standard disinfectant without staining | |
| Set coordination function | Matching seating and table finishes create a uniform formal appearance for professional reception spaces | |
| Assembly function | Knock-down construction requires only leg attachment to seating units and frame bolting for tables, no special tools required for installation | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 6 cartons total | |
|---|---|---|
| Shipping carton dimensions (sofa) | 2050 x 900 x 650 mm | |
| Shipping carton dimensions (single armchair) | 950 x 900 x 650 mm per unit | |
| Shipping carton dimensions (coffee table) | 1250 x 650 x 120 mm | |
| Shipping carton dimensions (side table) | 650 x 650 x 120 mm per unit | |
| Total shipping gross weight | 170 kg | |
| Total shipping volume (CBM) | 2.4 cbm | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading quantity (full set) | 10 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal professional appearance suitable for waiting areas serving clients and visitors, with durable easy-clean upholstery that maintains a tidy appearance | |
|---|---|---|
| Executive office breakout and meeting zones | Matching upholstered seating and tables create a consistent premium look for informal meetings or guest seating adjacent to executive desks | |
| Public service waiting rooms | High-traffic durable construction and wipe-clean surfaces support regular daily use by members of the public in government, bank or medical office lobbies | |
| Small business lounge spaces | Compact 5-person seating footprint fits efficiently in small office entryways without overcrowding available floor space | |
| Conference room auxiliary seating | Single armchairs can be placed around meeting tables or against walls to provide flexible additional guest seating during large meetings | |
| Recommended complementary configuration | Pair with matching office visitor chairs and floor lamps to extend the reception seating area for larger visitor volumes | |
| Executive office guest zones | Matching seating and tables create a consistent premium look for informal meetings or guest seating adjacent to executive workstations | |
| Small business entry spaces | Compact 5-person seating footprint fits efficiently in small office entryways without overcrowding 20sqm reception areas |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office furniture - Office work chair safety requirements, applicable as safety reference for fixed reception seating | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety requirements for non-domestic tables, applicable as performance reference for coffee and side tables | |
| EN 1022:2019 | Domestic and non-domestic seating - Determination of stability, applicable as stability reference for all fixed seating units | |
| EN 13722:2004 | Furniture - Assessment of surface resistance to cold liquids, applicable as finish durability reference for upholstery and table tops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for Lounge and Public Seating, applicable as performance and durability reference for all seating units in commercial environments | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for Desk Products, applicable as structural performance reference for coffee and side tables used in office spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden/metal furniture, applicable as acceptance reference for structural stability and finish quality of all set pieces | |
|---|---|---|
| GB 28007-2011 | Safety requirements for upholstered furniture for office and public use, applicable as reference for structural safety and flame retardant performance of seating units | |
| GB/T 2828.1-2012 | Sampling inspection standard for incoming procurement acceptance of batch units | |
| GB 18584-2001 | Limit of harmful substances in interior decoration materials (wood furniture), applicable for formaldehyde and VOC emission acceptance reference for all components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden/metal furniture, applicable as acceptance reference for structural stability and finish quality of all set pieces; 2. GB 28007-2011: Safety requirements for upholstered furniture for office and public use, applicable as reference for structural safety and flame retardant performance of seating units; 3. GB/T 2828.1-2012: Sampling inspection standard for incoming procurement acceptance of batch units; 4. GB 18584-2001: Limit of harmful substances in interior decoration materials (wood furniture), applicable for formaldehyde and VOC emission acceptance reference for all components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
