Automatic mm / inch conversion · Core engineering specifications
| Three-seater sofa overall dimension | 2200 x 850 x 750 mm | |
|---|---|---|
| Single armchair overall dimension | 900 x 820 x 720 mm | |
| Three-seater seat height | 420 mm | |
| Three-seater seat depth | 600 mm | |
| Backrest height above seat | 330 mm | |
| Armrest width | 150 mm | |
| Coffee table overall dimension | 1300 x 700 x 450 mm | |
| Support leg height | 100 mm | |
| Three-seater individual back cushion width | 660 mm | |
| Seat cushion thickness | 120 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Single seat static load capacity | 150 kg | |
|---|---|---|
| Total set net weight range | 145 kg | |
| Seat foam density | 35 kg/m³ | |
| Back foam density | 28 kg/m³ | |
| Seam abrasion resistance | 30000 cycles | |
| Foam compression set resistance | 92 % | |
| PU leather abrasion resistance | 30000 cycles | |
| Floor glide scratch resistance | 5000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back cushion upholstery | Lime green smooth PU leather, grid-tufted back cushions with even stitching | |
|---|---|---|
| Outer armrest and frame cladding | Semi-matte white PU leather, wrapped over rigid internal frame with squared clean edges | |
| Internal seating frame | 20 mm thick multilayer hardwood plywood, reinforced at leg mounting points | |
| Cushion padding | High-resilience polyurethane foam, no loose spring core | |
| Support legs | Polished chrome-plated mild steel, cylindrical profile with floor protection glides | |
| Coffee table frame | Polished chrome-plated stainless steel, X-shaped cross-brace support with lower black glass shelf | |
| Coffee table top and shelf | 10 mm thick black tempered glass, polished smooth edges | |
| Stitching detail | High-strength polyester thread, 8 mm seam pitch along all cushion and panel edges | |
| Under-seat base panel | 12 mm thick hardboard panel, sealed with moisture-resistant lacquer to prevent warping | |
| Stitching thread | High-tenacity polyester sewing thread, color-matched to upholstery, no exposed raw edges on finished panels | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Fixed upright seating position | Backrest angled at 100 degrees from horizontal seat surface, designed for short-term visitor seating in reception areas | |
|---|---|---|
| Grid-tufted back support | 6 square tufted sections on three-seater back, 3 square sections per single chair back, providing distributed lumbar support without adjustable mechanisms | |
| Integrated wide armrests | 150 mm wide padded armrests running full depth of each seat, providing consistent arm support for users of all heights | |
| Two-tier coffee table storage | Upper tempered glass surface for refreshments and reading materials, lower glass shelf for magazine or accessory storage, supported by rigid X-frame to prevent wobble | |
| Floor protection glides | All seating and table legs fitted with non-marking plastic glides to prevent scratching of polished tile or hardwood flooring, with no height adjustment mechanism | |
| Modular set configuration | Separate three-seater sofa and two matching single armchairs, allowing flexible arrangement to suit different reception room layouts | |
| Non-removable cushions | Seat and back cushions are permanently fixed to the frame to prevent shifting during daily use, simplifying maintenance in high-traffic public areas | |
| Integrated padded armrests | 150 mm wide, 200 mm high padded armrests running full depth of each seat, providing stable elbow support for users of all heights | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping cartons | 5 cartons | |
|---|---|---|
| Largest carton dimension | 2250 x 900 x 650 mm | |
| Total shipment gross weight | 175 kg | |
| Total shipment volume | 2.4 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| Packaging protection | 50 mm thick EPE foam wrap, corner protectors, and 5-ply corrugated outer cartons | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for corporate lobby, waiting area and meeting lounge spaces, providing formal seating for visiting clients and guests with a bright modern aesthetic | |
|---|---|---|
| Co-working common spaces | Appropriate for open lounge areas in shared office environments, with durable PU upholstery that resists stains and is easy to wipe clean for high-turnover use | |
| Small business waiting rooms | Fits compact reception spaces of 25sqm, with a low-profile frame that does not block sightlines in small entry areas | |
| Showroom lounge areas | Suitable for product display centers and auto dealership waiting zones, with a contemporary two-tone color scheme that complements modern interior design finishes | |
| Staff informal breakout areas | Can be used in internal office breakout zones for short rest breaks and informal small team discussions, with upright support suitable for 30 minute seated interactions | |
| Corporate office reception lobbies | Suitable for main entrance waiting areas and visitor meeting zones, configured in 3+1+1 U-shaped layout to accommodate 5 seated guests for pre-meeting waiting | |
| Co-working space common lounges | Appropriate for open shared work lounge areas, with stain-resistant PU upholstery that wipes clean with standard disinfectants for high-turnover daily use | |
| Small business customer waiting rooms | Fits compact reception footprints of 25 sqm, with a low-profile 750 mm back height that does not block sightlines between entry and staff desks |
EU Market Access Requirements* EN Standards
| Office seating strength recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface flammability recommendation | EN 1021:2014 | |
| Furniture glass safety recommendation | EN 12150:2015 | |
| Office non-domestic seating strength recommendation | EN 16139:2013 | |
| Upholstered furniture flammability recommendation | EN 1021:2014 | |
| Furniture toughened glass safety recommendation | EN 12150:2015 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB 18584 | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2 | |
| Formaldehyde emission limit recommendation | GB 18584 | |
| Upholstery furniture durability recommendation | GB/T 3324 |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB 18584; 2. Tempered glass safety recommendation: GB 15763.2; 3. Formaldehyde emission limit recommendation: GB 18584; 4. Upholstery furniture durability recommendation: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
