Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2000 x 850 x 780 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 800 x 780 mm | |
| Seat height from floor | 450 mm | |
| Seat depth (usable) | 580 mm | |
| Armrest height from seat | 180 mm | |
| Backrest height above seat | 330 mm | |
| 3-seater coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Single seating area coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Lower glass shelf height from floor (coffee table) | 150 mm | |
| Chrome support leg diameter (coffee table) | 50 mm | |
| Sofa/armchair leg height | 50 mm | |
| Armrest width | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 78 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Applicable maximum seating capacity (full set) | 8 people | |
| PU upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam thickness (seat cushion) | 120 mm | |
| Backrest foam thickness | 80 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | 0.8mm thick polyurethane (PU) leather, matte finish | |
|---|---|---|
| Seat cushion core | High resilience polyurethane foam, 45kg/m³ density | |
| Backrest cushion core | Soft polyurethane foam, 30kg/m³ density | |
| Internal seating frame | 20mm x 40mm solid kiln-dried hardwood frame, corner blocked for stability | |
| Seating support base | 8mm thick sinuous spring suspension with polypropylene webbing | |
| Seating legs | 1.2mm thick polished chrome-plated steel, tapered square profile | |
| Coffee table top | 10mm thick black tempered safety glass, polished edges | |
| Coffee table lower shelf | 8mm thick black tempered safety glass | |
| Coffee table support structure | 1.5mm thick polished chrome-plated square steel legs and frame | |
| Stitching details | Matching color bonded polyester thread, 8 stitches per 30mm seam length | |
| Seaming construction | Matching color bonded polyester thread, 8 stitches per 30mm seam length, double-stitched at high-stress corners | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating design function | Fixed upright ergonomic posture, no recline mechanism, optimized for short-stay guest reception and waiting areas | |
|---|---|---|
| Coffee table storage function | Two-tier tempered glass design, top surface for beverage and reading material placement, lower open shelf for magazine and accessory storage | |
| Floor protection function | Plastic glide pads fitted to base of all metal legs, prevents scratching of carpet, tile or hardwood flooring | |
| Configuration flexibility | Modular individual units, can be arranged in linear, L-shape or clustered circular layouts to suit different reception room dimensions | |
| Surface maintenance function | Smooth non-porous PU upholstery and glass surfaces, can be wiped clean with standard mild detergent, resistant to common office beverage spills | |
| Color customization option | Available in black, white, and red PU upholstery as shown, supports custom corporate color matching for bulk orders | |
| Structural stability feature | Wide, low-profile base with four contact points per seating unit, prevents tipping when users lean on armrests or enter/exit seats | |
| Seating ergonomic design | Fixed upright 100-degree back angle, no recline mechanism, optimized for 45 minute short-stay guest reception | |
| Anti-tipping stability feature | 50mm leg height and 800mm wide armchair base creates 380mm low center of gravity, passes 10-degree tilt stability test without tipping when users lean on armrests | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| Full set packaging count | 8 cartons | |
|---|---|---|
| 3-seater sofa carton dimensions | 2050 x 900 x 650 mm | |
| Single armchair carton dimensions | 950 x 850 x 650 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Full set total gross weight | 290 kg | |
| Full set total shipping volume | 2.8 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity (full sets) | 10 sets | |
| 40ft HQ container loading quantity (full sets) | 25 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate executive reception area | Formal professional appearance suited for welcoming visiting clients, partners and job candidates, matching modern high-rise office interiors as shown | |
|---|---|---|
| Office waiting lounge | Durable, easy-clean construction suitable for high-traffic employee and visitor waiting areas outside meeting rooms or executive suites | |
| Government or institutional meeting space | Formal, non-flashy design meets requirements for official meeting and reception spaces, available in multiple color options to match interior branding | |
| Small business lounge and break area | Modular configurable layout can be adapted to small or irregularly shaped lounge spaces, provides comfortable seating for short rest periods | |
| Hotel business center lounge | Wear-resistant PU upholstery is suitable for high-turnover public areas in hotels and serviced offices, requires minimal routine maintenance | |
| Recommended matching configuration | Pair with 500x500mm commercial carpet tiles as shown, add small table top decor and potted plants to complete a welcoming reception environment | |
| Government and institutional meeting space | Neutral structured non-decorative design meets official space furnishing requirements, available in custom color options to match institutional branding guidelines | |
| Small business office lounge | Modular freestanding units can be rearranged to fit irregularly shaped spaces from 15sqm, provides comfortable short-stay seating for employees and visitors |
EU Market Access Requirements* EN Standards
| Office furniture strength recommendation | EN 16139:2013, strength, durability and safety requirements for non-domestic seating, applicable for level 2 general office use | |
|---|---|---|
| Furniture surface durability recommendation | EN 12720:2009, resistance to cold liquids for furniture surfaces, applicable for PU upholstery and glass tops to withstand common beverage spills | |
| Non-domestic seating strength requirement | EN 16139:2013, strength, durability and safety requirements for non-domestic seating, applicable for level 2 general office use | |
| Furniture surface liquid resistance requirement | EN 12720:2009, resistance to cold liquids for furniture surfaces, applicable for PU upholstery and glass tops to withstand common beverage spills |
US and Canada office-furniture standards
| Lounge seating performance recommendation | ANSI/BIFMA X2020performance standard for lounge and public seating, includes static load, stability and durability test requirements for commercial reception seating | |
|---|---|---|
| Lounge seating performance requirement | ANSI/BIFMA X5.4:2020, performance standard for lounge and public seating, includes static load, stability and durability test requirements for commercial reception seating |
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB 18584applicable limit for formaldehyde emission from wooden furniture components <1.5mg/L, required for indoor office use | |
|---|---|---|
| Upholstered furniture fire safety recommendation | GB 20286flame retardant performance requirements for public area upholstered furniture, required for high-traffic commercial reception spaces | |
| Tempered glass safety recommendation | GB 15763.2safety requirements for tempered glass used in furniture, mandatory for glass table tops to prevent shard injury | |
| Formaldehyde emission requirement | GB 18584:2001, limit for formaldehyde emission from wooden furniture components ≤1.5mg/L, required for indoor office use | |
| Upholstered furniture fire safety requirement | GB 20286:2006, flame retardant performance requirements for public area upholstered furniture, required for high-traffic commercial reception spaces | |
| Tempered glass safety requirement | GB 15763.2:2005, safety requirements for tempered glass used in furniture, mandatory for glass table tops to prevent laceration injury from breakage |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB 18584applicable limit for formaldehyde emission from wooden furniture components <1.5mg/L, required for indoor office use; 2. Upholstered furniture fire safety recommendation: GB 20286flame retardant performance requirements for public area upholstered furniture, required for high-traffic commercial reception spaces; 3. Tempered glass safety recommendation: GB 15763.2safety requirements for tempered glass used in furniture, mandatory for glass table tops to prevent shard injury; 4. Formaldehyde emission requirement: GB 18584:2001, limit for formaldehyde emission from wooden furniture components ≤1.5mg/L, required for indoor office use; 5. Upholstered furniture fire safety requirement: GB 20286:2006, flame retardant performance requirements for public area upholstered furniture, required for high-traffic commercial reception spaces; 6. Tempered glass safety requirement: GB 15763.2:2005, safety requirements for tempered glass used in furniture, mandatory for glass table tops to prevent laceration injury from breakage; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
