Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (WxDxH) | 1900 x 820 x 780 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth (front to back) | 560 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height (from seat surface to top) | 400 mm | |
| Armrest height from floor | 600 mm | |
| Armrest width (horizontal) | 120 mm | |
| Leg height | 80 mm | |
| Per-seat usable width | 560 mm | |
| Clearance under sofa base | 60 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Gross product weight | 75 kg | |
|---|---|---|
| Total static load capacity | 450 kg | |
| Seat foam density | 38 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Backrest foam density | 28 kg/m³ | |
| Abrasion resistance of upholstery | 50000 double rubs (Wyzenbeek) | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Design service life | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Black PVC faux leather, 1.0mm thickness | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam wrapped with 20mm soft polyester fiber layer | |
| Backrest cushion core | Medium-density polyurethane foam with fiber wrap | |
| Internal frame | Kiln-dried solid pine wood frame, 30mm x 50mm structural members | |
| Support springs | Sinuous zigzag steel springs, 3.6mm wire diameter, spaced 100mm apart | |
| Armrest structure | Padded wood frame wrapped in matching faux leather, square boxy profile | |
| Legs | Polished chrome-plated tapered steel legs, 1.5mm wall thickness | |
| Bottom dust cover | Black non-woven fabric under-base cover | |
| Seat support system | Sinuous zigzag steel springs, 3.8mm wire diameter, spaced 100mm apart, secured with plastic spring clips | |
| Stitching thread | Bonded polyester upholstery thread, UV and abrasion resistant | |
| Frame joinery | Dado and screwed corner joints with wood glue reinforcement | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Adjustment / rotation / tilt / mobility / storage features
| Seating capacity | Accommodates 3 adult users simultaneously | |
|---|---|---|
| Tufted seat surface | Evenly spaced recessed tufting on seat cushions to hold padding in place and prevent shifting | |
| Stationary fixed configuration | No recline, tilt or moving parts, rigid fixed frame for long-term stable placement | |
| Floor protection | Hidden felt pads on base of each metal leg to prevent scratching hard flooring | |
| Stain-resistant surface | Smooth non-porous faux leather surface allows wipe-clean maintenance for spills and marks | |
| Leveling adjustment | Small adjustable glide insert on each leg to compensate for uneven floor surfaces | |
| Coordinated set compatibility | Matching styling and leg finish to pair with identical single-seat armchairs and complementary chrome-frame glass coffee tables | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Packed carton dimensions | 1980 x 880 x 580 mm | |
| Packed gross weight | 85 kg | |
| Packed volume (CBM) | 1.01 CBM | |
| On-site assembly time | 10 minutes | |
| 20ft GP container loading quantity | 26 units | |
| 40ft HQ container loading quantity | 62 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal black faux leather design matches professional business environments for visitor waiting zones | |
|---|---|---|
| Executive office meeting spaces | Pairs with matching armchairs and glass coffee table for small in-office meeting setups | |
| Public waiting rooms and lobbies | Durable wipe-clean upholstery suitable for high-traffic areas with frequent daily use | |
| Small business conference lounge areas | Compact footprint fits standard lounge layouts without requiring excessive floor space | |
| Recommended matching configuration | Pairs with 2 identical single-seat armchairs and a 1200mm black glass chrome-frame coffee table for a complete reception set | |
| Public waiting rooms and lobby areas | Durable wipe-clean upholstery suitable for high-traffic government, bank or hotel lobbies with frequent daily use | |
| Breakout and informal meeting zones | Medium-firm cushioning supports 45-minute informal discussions without the deep softness of residential lounge seating |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture - Visitor chairs, applicable to static load, stability and durability for non-adjustable reception seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability (cigarette source), sets fire resistance baseline for public office spaces | |
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for non-domestic seating |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame strength, dimensional stability and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, sets formaldehyde emission limits for wood components and adhesives | |
| GB/T 19001-2016 | Quality management system requirement for production consistency of upholstered office furniture | |
| GB/T 27904-2011 | Upholstered furniture for public office use, sets structural strength and stability requirements for commercial reception seating | |
| GB 20400-2006 | Leather and fur - Limits of harmful matter, applicable if genuine leather is substituted for faux leather per supplier BOM |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame strength, dimensional stability and finish quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, sets formaldehyde emission limits for wood components and adhesives; 3. GB/T 19001-2016: Quality management system requirement for production consistency of upholstered office furniture; 4. GB/T 27904-2011: Upholstered furniture for public office use, sets structural strength and stability requirements for commercial reception seating; 5. GB 20400-2006: Leather and fur - Limits of harmful matter, applicable if genuine leather is substituted for faux leather per supplier BOM; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
