Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2100 x 850 x 750 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 800 x 750 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height (from floor to seat surface) | 420 mm | |
| Seat depth (front edge to back cushion) | 580 mm | |
| Back cushion height | 330 mm | |
| Armrest width (top surface) | 120 mm | |
| Leg/base height (floor to bottom of sofa frame) | 30 mm | |
| Back cushion thickness | 120 mm | |
| Seat cushion thickness | 100 mm | |
| Coffee table top thickness | 12 mm | |
| Triangular side decorative brace width | 40 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seat sofa total weight | 95 kg | |
|---|---|---|
| Single armchair total weight | 38 kg | |
| Per-seat static load capacity | 150 kg | |
| Recommended maximum occupancy for full set | 5 people | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Product warranty period | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa outer frame panels | White painted medium-density fiberboard (MDF) with matte finish | |
|---|---|---|
| Seat and back upholstery (green sections) | Lime green polyurethane (PU) leather with fine grain texture | |
| Seat cushion core | High-density polyurethane foam wrapped in non-woven fabric | |
| Back cushion core | Medium-density polyurethane foam with polyester fiber topper | |
| Sofa support base | Black powder-coated steel rectangular tube frame | |
| Side decorative triangular braces | Chrome-plated polished steel trim | |
| Adjustable support feet | Chrome-plated steel with anti-slip rubber pad | |
| Coffee table top | White painted MDF or high-gloss tempered glass with smooth matte white finish | |
| Coffee table frame | White powder-coated square steel tube with closed U-base design | |
| Internal seat support | 70mm wide elastic webbing spaced 80mm apart, fastened to frame with steel staples | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular 3-piece set (1 three-seat sofa + 2 single armchairs) designed for clustered conversation layout | |
|---|---|---|
| Floor protection | Chrome-plated feet with integrated rubber pads prevent scuffing on hard floors and carpet indentation | |
| Upholstery maintenance | Smooth PU leather surface allows wipe-clean sanitization with common office cleaning agents | |
| Structural bracing | Triangular steel side braces reinforce frame joints between arm panels and base, reducing lateral wobble during regular use | |
| Coffee table clearance | 420mm open leg space under table top allows leg room for seated users reaching for items on the table | |
| Fixed cushion design | Non-removable seat and back cushions are secured to the frame to prevent shifting during regular use | |
| Color customization | Upholstery available in multiple standard office color options to match corporate branding | |
| Leveling adjustment | Individual support feet offer 10mm vertical adjustment range to compensate for minor floor unevenness, eliminating rocking on installations with up to 5mm floor height variation | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 5 packages | |
|---|---|---|
| Largest carton dimensions (3-seat sofa) | 2150 x 880 x 620 mm | |
| Single armchair carton dimensions | 950 x 830 x 620 mm | |
| Coffee table carton dimensions | 1250 x 650 x 180 mm | |
| Total gross shipping weight | 210 kg | |
| Total shipping volume (CBM) | 2.4 m³ | |
| Assembly time (2 trained workers) | 40 minutes | |
| 20ft GP container loading quantity | 10 sets | |
| 40ft HQ container loading quantity | 24 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for visitor waiting spaces, with professional bright lime green and white color scheme that presents a modern, welcoming image for incoming guests | |
|---|---|---|
| Small informal meeting spaces | Supports short 30 minute collaborative discussions for 5people, with upright seat posture suitable for quick conversations rather than extended lounging | |
| Startup or creative office open collaboration zones | Compact footprint fits in open plan breakout areas without blocking walkways, with durable wipe-clean upholstery suitable for frequent daily use | |
| Public institution visitor waiting rooms | Robust fixed construction resists damage from high-traffic unsupervised public use, with no loose removable parts to reduce risk of loss or tampering | |
| Recommended pairing configuration | Place centered against a feature wall with the coffee table equidistant from all seating units, with 800mm clear walkway around the set to maintain accessible egress | |
| Flooring compatibility | Suitable for installation on low-pile commercial carpet, luxury vinyl tile, or polished concrete floors, with adjustable feet to accommodate minor floor level variations | |
| Recommended layout configuration | Place the 3-seat sofa against a feature wall with the coffee table 400mm from all seat front edges, maintaining 800mm clear walkway around the set for accessible egress per commercial building codes |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office furniture - Office work chair - Part 2: Safety requirements, applicable as reference for static load and stability testing for commercial seating units | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating - Determination of stability, applicable for evaluating tipping risk of sofas when users sit on arm or seat edges | |
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable as durability reference for medium-traffic reception sofas | |
| EN 15372:2016 | Furniture - Durability requirements for tables for non-domestic use, applicable for coffee table structural durability in public office areas | |
| EN 13722:2004 | Furniture - Assessment of surface resistance to cold liquids, applicable for painted MDF frame and table top surfaces, requiring no staining after 1 hour contact with common office beverages |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to painted MDF frame components, covering dimensional tolerance, surface finish and structural strength requirements | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for MDF panels used in sofa frames | |
| GB/T 16799-2008 | Polyurethane leather for furniture, applicable for PU upholstery material performance testing covering abrasion, color fastness and tear strength | |
| GB/T 39223.2-2020 | Office furniture - Part 2: Safety and strength requirements for seating, applicable for structural load testing of sofas for commercial use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to painted MDF frame components, covering dimensional tolerance, surface finish and structural strength requirements; 2. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for MDF panels used in sofa frames; 3. GB/T 16799-2008: Polyurethane leather for furniture, applicable for PU upholstery material performance testing covering abrasion, color fastness and tear strength; 4. GB/T 39223.2-2020: Office furniture - Part 2: Safety and strength requirements for seating, applicable for structural load testing of sofas for commercial use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
