Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 1900 x 820 x 780 mm | |
|---|---|---|
| Single armchair overall dimensions | 880 x 820 x 780 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable surface) | 580 mm | |
| Backrest height (seat surface to top) | 400 mm | |
| Armrest height (floor to top) | 620 mm | |
| Armrest width | 120 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Coffee table lower shelf clearance | 180 mm | |
| Sofa leg height | 80 mm | |
| Quilted seat tuft spacing | 180 mm | |
| Side end table overall dimensions | 600 x 600 x 500 mm | |
| Armrest padding thickness | 80 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set net weight | 135 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seating capacity (full set) | 5 persons | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam compression set resistance | 95% rebound after 40% compression | |
| Recommended commercial warranty | 3 years | |
| Sofa frame joint cyclic durability | 50000 seat cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa outer upholstery | 1.0mm thick black PU faux leather, matte grained finish | |
|---|---|---|
| Seat core padding | 40mm thick 40kg/m³ high-density polyurethane foam, wrapped with 10mm soft foam layer | |
| Backrest padding | 30mm thick 35kg/m³ high-density polyurethane foam | |
| Sofa internal frame | 20mm thick multilayer hardwood plywood frame with reinforced corner blocking | |
| Sofa support legs | 1.5mm thick polished chrome-plated zinc alloy tapered feet, fitted with non-slip floor protection pads | |
| Coffee table top surface | 10mm thick tempered black safety glass with polished rounded edges, fitted with chrome decorative mounting caps | |
| Coffee table lower shelf | 8mm thick tempered black safety glass | |
| Coffee table support frame | 40x40mm 1.2mm thick polished chrome-plated square steel tube legs with cross bracing | |
| Seat upholstery stitching | 10 stitches per 100mm reinforced polyester thread, grid quilted pattern | |
| Floor protection pads | 5mm thick non-marking rubber pads affixed to base of all sofa and table feet | |
| Seat support system | 70mm wide elastic webbing spaced 120mm apart under seat foam, no zig-zag springs | |
| Side end table materials | 8mm thick tempered black safety glass top and lower shelf, 1.2mm thick polished chrome square steel tube frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright position, optimized for formal short-duration guest reception use | |
|---|---|---|
| Coffee table storage | Two-tier open shelving design, top surface for active serving use, lower shelf for out-of-sight document and magazine storage | |
| Cleaning and maintenance | Smooth non-porous upholstery surface enables wipe-down cleaning with standard office cleaning products, no removable cushion covers | |
| Floor protection | Integrated rubber feet on all seating and table pieces prevent scratching of hard floor surfaces, no additional glides required for standard installation | |
| Set modularity | Consistent height, depth and finish across all seating pieces allows flexible arrangement to suit different reception room layouts | |
| Coffee table cable management | Pre-drilled chrome capped access points on table top support routing of charging cables for small devices placed on the table surface | |
| Side end table function | Matching two-tier side table provides additional surface area next to seating for placing small devices, visitor amenities or decorative items | |
| Seat cushion retention | Fixed seat cushions secured to frame with hidden hook and loop fasteners to prevent shifting during regular use | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 5 cartons | |
|---|---|---|
| 3-seater sofa carton dimensions | 1950 x 870 x 680 mm | |
| Single armchair carton dimensions | 930 x 870 x 680 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Total set gross shipping weight | 158 kg | |
| Total shipping volume (CBM) | 1.72 CBM | |
| On-site assembly time | 45 minutes | |
| 40HQ container load quantity | 42 sets | |
| Side end table carton dimensions | 650 x 650 x 110 mm | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Ideal for main visitor waiting zones, formal black finish matches professional office decor and provides 5 seats for small to medium visitor groups | |
|---|---|---|
| Executive office meeting spaces | Suitable for informal meeting areas adjacent to executive workspaces, paired with matching glass coffee table for serving refreshments during discussions | |
| Public service waiting rooms | Durable faux leather upholstery withstands high daily traffic in government, banking or professional service waiting areas, easy to sanitize between visitors | |
| Small business lounge areas | Modular arrangement works for startup or SME breakout lounges, providing structured comfortable seating without oversized casual sofa proportions | |
| Recommended complementary layout | Position 3-seater sofa against the primary wall, place two single armchairs at 45 degree angles opposite, center coffee table between seating pieces to create a 3m x 3m dedicated reception zone | |
| Temporary visitor waiting zones | Suitable for short-stay waiting areas outside meeting rooms or interview spaces, easy to reposition for event use due to modular piece weights |
EU Market Access Requirements* EN Standards
| Office furniture stability recommendation | EN 16139:2013 | |
|---|---|---|
| Furniture surface fire safety recommendation | EN 1021:2014 | |
| Glass furniture safety recommendation | EN 12150:2015 | |
| Furniture hardware durability recommendation | EN 12520:2015 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18580 | |
| Tempered glass safety recommendation | GB 15763.2 | |
| Upholstery leather/faux leather safety recommendation | GB 20400 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Formaldehyde emission recommendation: GB 18580; 3. Tempered glass safety recommendation: GB 15763.2; 4. Upholstery leather/faux leather safety recommendation: GB 20400; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
