Automatic mm / inch conversion · Core engineering specifications
| 2-seater sofa overall dimensions | 1500 x 750 x 750 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 750 x 750 mm | |
| Rectangular coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Side end table overall dimensions | 600 x 600 x 500 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 550 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height above floor | 600 mm | |
| Metal support leg diameter | 25 mm | |
| Coffee table top glass thickness | 10 mm | |
| Coffee table lower shelf glass thickness | 8 mm | |
| Seat cushion thickness | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single sofa unit weight range | 45 kg | |
|---|---|---|
| 2-seater sofa unit weight range | 70 kg | |
| Per-seat static load capacity | 150 kg | |
| Abrasion resistance of upholstery fabric | 50000 double rubs | |
| Set total seating capacity | 4 persons | |
| Foam density (seat/back) | 38 kg/m³ | |
| Foam rebound rate | 55% | |
| Single sofa unit weight | 45 kg | |
| 2-seater sofa unit weight | 70 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Woven polyester fabric, matte yellow finish, 0.8mm thickness | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam, wrapped with non-woven fabric layer | |
| Back cushion core | Medium-density polyurethane foam with integrated throw pillow inserts | |
| Sofa support frame | 1.2mm thick polished chrome-plated square steel tube frame | |
| Sofa legs | 25mm diameter polished chrome-plated cylindrical steel legs, with non-slip plastic foot pads | |
| Coffee table frame | 1.5mm thick polished stainless steel rectangular tube with X-shaped cross bracing | |
| Coffee table tops | 10mm thick black tempered glass top, 8mm thick black tempered glass lower shelf, polished flat edges | |
| Side table frame and surfaces | Polished stainless steel frame, black tempered glass top and lower shelf, matching coffee table finish | |
| Accent throw pillows | Removable woven polyester covers in lime green and teal, filled with polyester fiberfill | |
| Stitching details | Reinforced polyester stitching, 8mm stitch pitch along all upholstery seams | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular arrangement with two single armchairs and one 2-seater sofa, sized to form a U-shaped reception layout | |
|---|---|---|
| Table function | Double-tier coffee table provides upper surface for drinks, reading materials and decor, lower glass shelf for magazine and accessory storage | |
| Side table function | Matching single-tier side table fits between armchairs to hold tea sets, small decor or personal items for adjacent seats | |
| Frame stability | Stainless steel X-brace on coffee table frame prevents lateral racking, integrated steel sofa frame eliminates wobble during regular use | |
| Floor protection | All metal legs include fitted non-slip plastic glides to prevent scratching hard flooring and reduce movement noise | |
| Accent pillow adjustability | All throw pillows are removable and repositionable for user comfort or decor customization | |
| Surface maintenance | Tempered glass table surfaces are non-porous and can be wiped clean with standard glass cleaning products; fabric upholstery can be spot cleaned for light stains | |
| Assembly requirement | Sofa units and tables ship knockdown for transport, requiring only leg attachment and frame bolt tightening for on-site setup | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total number of packages per set | 5 | |
|---|---|---|
| Single armchair carton dimensions | 870 x 770 x 570 mm | |
| 2-seater sofa carton dimensions | 1520 x 770 x 570 mm | |
| Coffee table carton dimensions | 1240 x 640 x 160 mm | |
| Side table carton dimensions | 640 x 640 x 160 mm | |
| Total gross weight per full set | 160 kg | |
| Total CBM per full set | 1.65 m³ | |
| On-site assembly time | 50 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for corporate lobby and visitor waiting areas, provides formal, bright seating for 4 guests with adjacent table space for refreshments and reading materials | |
|---|---|---|
| Small business meeting spaces | Appropriate for informal client discussion areas or startup open office breakout zones, compact footprint fits rooms from 15sqm upwards | |
| Public service waiting areas | Suitable for bank, clinic or service center waiting zones, durable fabric and metal construction withstands high-frequency daily public use | |
| Recommended matching configuration | Pairs with neutral light gray or white hard flooring, large windows or bright overhead lighting to complement the warm yellow upholstery and polished metal finishes | |
| Available color options | Available in 6 standard upholstery color options including yellow, gray, black, dark blue, beige and brown to match different interior design schemes | |
| Installation requirement | Requires two-person assembly for safe handling of glass table components and sofa frames, no specialized tools required for setup | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Contract furniture safety recommendation | EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable for seating load and stability testing | |
|---|---|---|
| Glass furniture safety recommendation | EN 12150:2015 Glass in building - Thermally toughened soda lime silicate safety glass, applicable for glass table top safety verification | |
| Furniture stability recommendation | EN 1730:2012 Furniture - Test methods for tables - Determination of stability, strength and durability, applicable for coffee table and side table structural verification |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324General technical requirements for wooden furniture, applicable for structural safety verification of internal framing | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for glass table top impact and breakage safety verification | |
| Upholstered furniture durability recommendation | GB/T 19001Quality management systems, applicable for production consistency verification of foam and upholstery components | |
| Formaldehyde emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for verifying low-VOC emissions from internal materials |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324General technical requirements for wooden furniture, applicable for structural safety verification of internal framing; 2. Tempered glass safety recommendation: GB 15763.2Safety glazing materials in building - Part 2: Tempered glass, applicable for glass table top impact and breakage safety verification; 3. Upholstered furniture durability recommendation: GB/T 19001Quality management systems, applicable for production consistency verification of foam and upholstery components; 4. Formaldehyde emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for verifying low-VOC emissions from internal materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
