| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2200 x 880 x 850 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 820 x 850 mm | |
| Coffee table overall dimensions | 1300 x 700 x 450 mm | |
| Side table overall dimensions | 500 x 500 x 550 mm | |
| Sofa seat height from floor | 450 mm | |
| Sofa seat depth | 580 mm | |
| Sofa backrest height from seat | 400 mm | |
| Sofa armrest height from seat | 180 mm | |
| Coffee table storage compartment inner dimensions | 260 x 580 x 150 mm per side shelf | |
| Sofa leg height | 120 mm | |
| Gap under sofa frame for floor cleaning | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 85 kg | |
|---|---|---|
| 3-seater sofa total static load capacity | 450 kg | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seat foam density | 40 kg/m³ | |
| Seat foam thickness | 120 mm | |
| Product warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating outer upholstery | Dark brown matte smooth upholstery, visual match to semi-aniline leather effect faux leather | |
|---|---|---|
| Seating internal frame | Solid kiln-dried hardwood + 15mm thick plywood structural frame | |
| Seat cushion filling | High resilience polyurethane foam wrapped with 20mm thick soft polyester fiber | |
| Backrest filling | 35 kg/m³ polyurethane foam with polyester fiber top layer | |
| Seating support legs | 25mm diameter tapered powder-coated dark grey carbon steel legs | |
| Coffee table frame and panels | 18mm thick particleboard substrate with dark walnut wood grain melamine laminate finish | |
| Coffee table hardware | Brushed champagne gold metal drawer pulls, full extension 3-section drawer slides | |
| Coffee table feet | 30mm diameter black nylon swivel caster feet, 2 per long side | |
| Side table top and frame | 18mm thick engineered wood with matching dark grey/black matte laminate finish | |
| Upholstery stitching | Matching dark brown bonded nylon thread, 8 stitches per inch seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright seating designed for short-stay guest reception | |
|---|---|---|
| Coffee table storage layout | 2 central soft-close drawers plus 4 open side storage shelves (2 per long side) for magazines, remotes and guest amenities | |
| Coffee table mobility | Low-profile fixed caster feet allow easy repositioning for cleaning without sliding damage to flooring | |
| Floor clearance design | 100mm open gap under all seating frames allows standard vacuum cleaners and robot vacuums to access under units | |
| Armrest design | Wide fully padded integrated armrests provide arm support for seated guests and protect upholstery edges from wear | |
| Table surface function | Scratch-resistant melamine table tops support drink service, decorative items and reading materials without permanent marking | |
| Assembly requirement | Knock-down assembly of legs to seating frames and table components, no complex upholstery assembly required | |
| Color offering | Available in 1 standard dark brown upholstery finish, dark wood table finish as displayed | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 6 cartons total | |
|---|---|---|
| 3-seater sofa shipping carton dimensions | 2250 x 920 x 650 mm | |
| Single armchair shipping carton dimensions | 950 x 870 x 650 mm | |
| Coffee table shipping carton dimensions | 1350 x 750 x 500 mm | |
| Total set shipping gross weight | 210 kg | |
| Total shipping volume per set | 2.8 CBM | |
| On-site assembly time | 60 minutes for 2-person assembly team | |
| 40ft HQ container loading quantity | 42 complete sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate office reception lobbies | Formal dark brown professional styling matches executive office design, provides structured guest seating for visitor waiting areas | |
|---|---|---|
| Executive office meeting spaces | Compact seating configuration pairs with executive desks for small informal meetings between staff and visitors | |
| Small business waiting rooms | 5-piece set (3-seater + 2 armchairs + tables) provides complete seating for 5 guests without requiring separate furniture sourcing | |
| Hotel lounge and business center areas | Durable commercial-grade construction withstands high daily visitor traffic, understated design fits neutral hospitality interiors | |
| VIP visitor waiting zones | Padded armrests and mid-back support provide comfortable short-stay seating for important guests without overstuffed casual design | |
| Staff break room casual meeting areas | Stain-resistant upholstery and scratch-resistant tables support daily break use and impromptu team discussions | |
| Executive office internal meeting spaces | Compact seating configuration pairs with executive desks for small informal meetings between staff and visitors without occupying excessive floor space | |
| Hotel business center and lounge areas | Durable commercial-grade construction withstands 50000 Martindale cycle abrasion from high daily visitor traffic, understated dark finish fits neutral hospitality interior palettes |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office furniture - Office work chair safety requirements, reference for stability and strength of guest seating units | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic storage furniture, applicable to coffee table storage components | |
| EN 12521:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, reference for commercial reception seating strength thresholds |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood table components in this set for dimensional stability and surface durability | |
|---|---|---|
| GB/T 16799-2008 | Leather and artificial leather for furniture, applicable to upholstery material testing for abrasion, color fastness and tear strength | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for all wood-based components | |
| GB/T 27904-2011 | Office furniture seating mechanical test methods, applicable for static load, durability and stability testing of sofa units |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood table components in this set for dimensional stability and surface durability; 2. GB/T 16799-2008: Leather and artificial leather for furniture, applicable to upholstery material testing for abrasion, color fastness and tear strength; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for all wood-based components; 4. GB/T 27904-2011: Office furniture seating mechanical test methods, applicable for static load, durability and stability testing of sofa units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
