Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 820 × 800 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 580 mm | |
| Backrest height above seat | 380 mm | |
| Armrest height above seat | 180 mm | |
| Chrome frame trim thickness | 20 mm | |
| Coffee table lower shelf height above floor | 150 mm | |
| Feet base spread per seating unit | 60 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Two-seater sofa net weight | 58 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Foam density (seat cushion) | 40 kg/m³ | |
| Foam density (back cushion) | 28 kg/m³ | |
| Recommended maximum seating capacity | 4 persons | |
| Seat cushion foam density | 40 kg/m³ | |
| Back cushion foam density | 28 kg/m³ | |
| Maximum total seating capacity | 4 persons | |
| Seam strength | 120 N |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Orange smooth PU faux leather | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Inner seating frame | Solid hardwood + engineered wood composite | |
| Armrest vertical trim | Polished chrome-plated steel | |
| Sofa feet | Polished die-cast aluminum alloy | |
| Coffee table top and lower shelf | 10mm thick tempered black safety glass | |
| Coffee table support frame | Brushed stainless steel square tube | |
| Stitching detail | Matching orange polyester thread, 8 stitches per inch | |
| Back cushion core | High-resilience polyurethane foam, fixed padded construction | |
| Seat support system | 50mm wide elastic webbing, 80mm spacing | |
| Armrest padding | 20mm thick polyurethane foam layer under upholstery | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed non-modular 3-piece set | |
|---|---|---|
| Cushion design | Fixed attached seat and back cushions | |
| Armrest support | Integrated padded armrests with chrome accent trim | |
| Coffee table storage | Two-tier open glass shelving | |
| Floor protection | Non-slip non-marking pads fitted to all feet | |
| Cleaning suitability | Smooth non-porous upholstery surface | |
| Structural stability | Four-point outrigger foot design on each seating unit | |
| Assembly requirement | Knock-down leg and frame assembly | |
| Cushion attachment | Permanently fixed attached seat and back cushions | |
| Cleaning performance | Non-porous smooth PU upholstery surface | |
| Assembly design | Knock-down leg and frame construction | |
| Edge protection | Polished chrome trim on armrest leading edges |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total number of shipping cartons | 5 cartons | |
|---|---|---|
| Two-seater sofa carton dimensions | 1820 x 840 x 580 mm | |
| Single armchair carton dimensions (per unit) | 870 x 820 x 560 mm | |
| Coffee table carton dimensions | 1250 x 700 x 180 mm | |
| Total gross shipping weight | 145 kg | |
| Total shipping volume (CBM) | 1.72 m³ | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 45 sets | |
| Total shipping carton count | 5 cartons |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Suitable for lobbies and visitor waiting spaces, formal professional appearance matches modern office design schemes | |
|---|---|---|
| Executive meeting breakout zones | Supports small informal meetings between staff and guests, paired with matching coffee table for document and beverage placement | |
| Public service waiting rooms | Durable wipe-clean upholstery suitable for high-traffic use in government, banking or healthcare administrative waiting areas | |
| Small business lounge spaces | Compact footprint fits tight lounge spaces in startup offices, co-working facilities and studio workspaces | |
| Recommended complementary configuration | Pair with the matching black glass coffee table shown to create a complete coordinated reception seating group, no additional side tables required for basic setup | |
| Flooring suitability | Performs well on hard flooring surfaces including polished concrete, tile, luxury vinyl and low-pile commercial carpet | |
| Corporate office reception lobbies | Fits main visitor waiting spaces, formal orange and chrome appearance matches modern commercial office design schemes for professional first impressions | |
| Co-working facility lounge spaces | Compact footprint fits tight lounge spaces in startup offices, flexible seating arrangement supports both individual waiting and small group conversations |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture - Visitors chairs, applicable to seating stability, static load and durability requirements for guest use | |
|---|---|---|
| EN 1022:2018 | Domestic and contract furniture - Seating - Determination of stability, applicable to anti-tip performance of all seating units | |
| EN 12521:2015 | Furniture - Strength, durability and safety - Requirements for domestic and contract tables, applicable to the glass coffee table structural performance |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and dimensional tolerance of sofa inner frames | |
|---|---|---|
| GB 20400-2006 | Limit of harmful substances in leather and fur, applicable to PU leather upholstery formaldehyde and heavy metal content limits | |
| GB/T 24821-2009 | Office furniture sofas, applicable to seating strength, durability and stability performance requirements | |
| GB 15763.2-2005 | Safety glazing materials in building, applicable to tempered glass components on the matching coffee table |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and dimensional tolerance of sofa inner frames; 2. GB 20400-2006: Limit of harmful substances in leather and fur, applicable to PU leather upholstery formaldehyde and heavy metal content limits; 3. GB/T 24821-2009: Office furniture sofas, applicable to seating strength, durability and stability performance requirements; 4. GB 15763.2-2005: Safety glazing materials in building, applicable to tempered glass components on the matching coffee table; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
