Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 1800 x 1800 mm | |
|---|---|---|
| Table top dimensions | Dia800 x 10 mm | |
| Table overall dimensions | Dia800 x 750 mm | |
| Table support column diameter | 80 mm | |
| Table base diameter | 450 mm | |
| Chair overall dimensions (max height) | 580 x 560 x 850 mm | |
| Chair seat dimensions | 450 x 420 mm | |
| Chair seat height adjustment range | 560 mm | |
| Chair backrest height | 320 mm | |
| Chair base diameter | 380 mm | |
| Chair armrest height above seat | 180 mm | |
| Chair seat height adjustment maximum | 720 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Table static load capacity | 80 kg | |
|---|---|---|
| Set total net weight | 85 kg | |
| Seating capacity | 4 people | |
| Gas lift cycle rating | 60000 cycles | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Chair swivel bearing cycle rating | 30000 cycles | |
| Table base tip resistance load | 30 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top | 10mm thick white tempered glass with polished edge | |
|---|---|---|
| Table column | Chrome-plated 1.2mm thick steel tubular support | |
| Table base | 1.5mm thick chrome-plated steel round flared disc | |
| Chair frame | 1.0mm thick chrome-plated steel tubular inner frame | |
| Chair gas lift | Class 3 chrome-plated steel gas lift with height adjustment lever | |
| Chair base | 1.2mm thick chrome-plated steel round disc base | |
| Seat and back padding | 50mm thick 35kg/m³ high-density polyurethane foam | |
| Upholstery fabric | 280g/m² linen-look woven polyester fabric in lime green | |
| Hardware | Chrome-plated steel swivel bearing and adjustment lever | |
| Floor protection | 1.5mm thick EVA rubber pads on all base bottoms | |
| Chair inner frame | 1.2mm thick chrome-plated steel tubular welded frame | |
| Chair mechanism | 2.5mm thick steel swivel and height adjustment chassis |
Adjustment / rotation / tilt / mobility / storage features
| Chair height adjustment | Pneumatic gas lift adjusts seat height from 420mm to 560mm via side lever, locks at desired height | |
|---|---|---|
| Chair 360° swivel | Full rotation swivel bearing allows unlimited 360-degree seat rotation without height change | |
| Table surface function | Smooth tempered glass surface is stain-resistant and supports easy wipe-clean maintenance, center cap covers hardware assembly | |
| Chair ergonomic support | Wrap-around curved barrel back and integrated armrests provide lateral torso and arm support for relaxed seated posture | |
| Floor protection | Soft rubber pads on all table and chair bases prevent scratching hard flooring without requiring additional glides | |
| Seating arrangement | Four chairs tuck fully under the round table edge to minimize footprint when not in use | |
| Seating nesting function | Four chairs tuck fully under the round table overhang to reduce footprint to 900x900mm when not in use | |
| Chair weight-activated stability | Weighted chrome disc base remains stationary on flooring when seat swivels or adjusts height, no floor mounting required | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential kitchen breakfast nook | Compact 800mm round size fits small dining areas, bright lime upholstery adds accent color to kitchen spaces | |
|---|---|---|
| Café and coffee shop seating | Light commercial grade construction and swivel adjustable chairs suit casual customer seating, wipe-clean glass top simplifies maintenance | |
| Office breakout and reception areas | Contemporary styling creates informal meeting spaces, swivel function supports relaxed collaborative conversation | |
| Small apartment dining space | Chairs tuck fully under the table to minimize unused footprint, ideal for compact urban living spaces | |
| Beauty salon waiting area | Plush upholstered seating and bright color create welcoming waiting spaces, height adjustment accommodates users of different heights | |
| Independent café and coffee shop seating | Light commercial rated construction and swivel adjustable chairs suit high-turnover casual customer seating, wipe-clean glass top reduces post-use cleaning time | |
| Office breakout and informal meeting areas | Contemporary styling creates relaxed collaborative spaces, 360-degree swivel function supports easy conversation between meeting participants | |
| Studio and small apartment dining space | Chairs tuck fully under the table to minimize unused footprint, ideal for compact urban living spaces under 50sqm |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Mechanical safety requirements for domestic and contract seating, applicable to chair strength, durability and stability | |
|---|---|---|
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for furniture, applicable to the table top impact and breakage safety | |
| EN 15372:2016 | Mechanical safety requirements for domestic and contract tables, applicable to table load capacity and stability | |
| Table top impact resistance | EN 12150standard tempered glass impact grade | |
| EN 14465:2003 | Upholstery fabric abrasion resistance testing, applicable to chair fabric durability for light commercial use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden/metal furniture, applicable to dimensional stability and structural durability of the set | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture, applicable to the glass table top to ensure impact safety and breakage pattern | |
| GB/T 3922-2013 | Color fastness testing for upholstery fabrics, applicable to the chair fabric to prevent fading with regular cleaning and use | |
| GB 28007-2011 | Stability and mechanical safety requirements for seating furniture, applicable to chair tip-over prevention and load safety | |
| GB/T 3920-2008 | Color fastness to rubbing for upholstery fabrics, applicable to the chair fabric to prevent fading and dye transfer with regular use and cleaning |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden/metal furniture, applicable to dimensional stability and structural durability of the set; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture, applicable to the glass table top to ensure impact safety and breakage pattern; 3. GB/T 3922-2013: Color fastness testing for upholstery fabrics, applicable to the chair fabric to prevent fading with regular cleaning and use; 4. GB 28007-2011: Stability and mechanical safety requirements for seating furniture, applicable to chair tip-over prevention and load safety; 5. GB/T 3920-2008: Color fastness to rubbing for upholstery fabrics, applicable to the chair fabric to prevent fading and dye transfer with regular use and cleaning; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
