Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 950 × 900 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat cushion depth | 580 mm | |
| Backrest total height | 480 mm | |
| Armrest width | 180 mm | |
| Armrest height from seat | 180 mm | |
| Leg height | 150 mm | |
| Coffee table top thickness | 12 mm | |
| Floor clearance under sofa | 150 mm | |
| Backrest cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Three-seater sofa net weight | 95 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended total seating capacity | 4 persons | |
| Seat foam indentation load deflection | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Leather upholstery abrasion resistance | 50000 double rubs | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Metal leg static load per leg | 120 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Top-grain cognac brown leather, split leather match on non-contact side panels | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam with polyester fiber wrap | |
| Backrest cushion core | Medium-density polyurethane foam with soft fiber topper | |
| Armrest padding | Dense foam wrapped in matching leather, stitched edge detailing | |
| Internal seating frame | Kiln-dried hardwood frame with 20mm plywood reinforcement | |
| Sofa support system | 4mm sinuous spring suspension with elastic webbing layer | |
| Sofa legs | 1.5mm thick matte black powder-coated carbon steel, tapered angled design | |
| Coffee table top | 12mm dark gray matte sintered stone, rounded edge finish | |
| Coffee table frame | 2mm thick matte black powder-coated carbon steel, geometric open-base design | |
| Sofa base rail | Hardwood frame wrapped in matching leather, finished edge at leg connection | |
| Stitching details | High-tensile bonded nylon thread, matched to leather color | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed non-reclining lounge design with integrated padded headrest section | |
|---|---|---|
| Back support design | Two-tier contoured back cushion with built-in lumbar support zone | |
| Armrest function | Wide padded fixed armrests designed to support forearm weight during relaxed seating | |
| Floor clearance feature | 150mm open space under all seating units allows access for robotic vacuums and standard cleaning tools | |
| Coffee table function | Low-profile stable surface for beverage service, reading materials and decorative objects | |
| Upholstery maintenance | Smooth non-porous leather surface allows wipe-clean maintenance for high-traffic reception areas | |
| Leg installation | Knock-down metal leg attachment with pre-installed threaded inserts, enables flat-pack shipping | |
| Weight distribution | Four-point leg placement on each seating unit ensures even weight distribution on carpet or hard flooring | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total shipping packages | 3 packages | |
|---|---|---|
| Three-seater sofa shipping carton dimensions | 2250 x 1000 x 650 mm | |
| Single-seater sofa shipping carton dimensions | 1150 x 1000 x 650 mm | |
| Coffee table shipping carton dimensions | 1350 x 750 x 150 mm | |
| Total shipping gross weight | 205 kg | |
| Total shipping volume | 2.4 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 45 sets | |
| Reference Package Count | 1 set / 2 cartons |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception areas | Designed for visitor waiting zones, with professional cognac leather finish that complements modern neutral office interiors | |
|---|---|---|
| Executive lounge spaces | Suitable for informal meeting areas adjacent to private offices, supporting relaxed small-group discussion | |
| High-end hotel lobbies | Durable commercial-grade construction suitable for moderate daily traffic in hospitality public spaces | |
| Consulting firm waiting rooms | Comfortable padded seating for extended client waiting periods, with easy-to-clean leather surfaces | |
| Showroom and gallery seating | Minimalist modern design does not distract from displayed products while providing rest points for visitors | |
| Recommended configuration | Pair with included geometric coffee table, and add matching two-seater sofa for larger reception spaces requiring extra seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture strength recommendation | EN 16139:2013 | |
|---|---|---|
| Upholstered furniture flammability recommendation | EN 1021:2014 | |
| Furniture surface durability recommendation | EN 15187:2006 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324 | |
|---|---|---|
| Leather upholstery testing recommendation | GB/T 16799 | |
| Formaldehyde emission recommendation | GB 18584 | |
| Hardware durability recommendation | GB/T 24821 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324; 2. Leather upholstery testing recommendation: GB/T 16799; 3. Formaldehyde emission recommendation: GB 18584; 4. Hardware durability recommendation: GB/T 24821; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
