| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1900 x 800 x 750 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth | 550 mm | |
| Seat width | 1650 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height above floor | 620 mm | |
| Armrest width | 120 mm | |
| Base clearance under sofa | 120 mm | |
| Backrest thickness | 120 mm | |
| Seat cushion thickness | 100 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Product net weight | 52 kg | |
|---|---|---|
| Total static load capacity | 450 kg | |
| Seat foam density | 40 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Recommended maximum user weight per seat | 150 kg | |
| Surface scratch resistance | 4H | |
| Seam tensile strength | 120 N | |
| Surface discoloration resistance | Grade 4 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Black matte PVC faux leather | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Backrest core | Medium-density polyurethane foam | |
| Armrest core | Multi-layer plywood inner frame wrapped in padding | |
| Lower support base | Brushed 304 stainless steel rectangular tube frame | |
| Inner structural frame | 25mm thick square steel tube internal frame | |
| Upholstery stitching | Nylon bonded thread with 8mm stitch pitch | |
| Base foot pads | Non-slip rubber glides | |
| Seat support layer | 70mm wide elastic webbing, 50mm spacing | |
| Surface finish | Matte anti-fingerprint coating on metal base | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3-position seater with no movable cushions | |
|---|---|---|
| Structural stability | Continuous sled-style steel base contacting floor at four end points | |
| Floor protection | Integrated rubber glides on all base contact points | |
| Cleaning suitability | Smooth non-porous faux leather surface | |
| Configuration compatibility | Matches complementary single-seat chairs and coffee tables in the same collection | |
| Back support design | Fixed upright back angle at 105 degrees from seat | |
| Cleaning performance | Smooth non-porous faux leather surface | |
| Posture support | Fixed upright back angle at 105 degrees from seat surface | |
| Placement compatibility | Modular coordination with matching single-seat armchairs and coffee tables in the same product line | |
| Anti-tamper design | Concealed fasteners attaching upholstery panels to internal frame | |
| Cushion retention | Fixed seat and back cushions bonded to internal frame | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 1980 x 880 x 830 mm | |
| Gross shipping weight | 62 kg | |
| Packaged volume per unit | 1.45 CBM | |
| On-site assembly time | 10 minutes | |
| 20ft GP container loading capacity | 18 units | |
| 40ft HQ container loading capacity | 46 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Automotive showroom reception areas | Neutral black professional appearance coordinated with luxury retail environments, durable construction for frequent visitor use as seen in source image | |
|---|---|---|
| Corporate office waiting rooms | Formal structured design matching executive office aesthetics, easy to clean between visitor appointments | |
| Banking and financial service lobbies | High abrasion resistance withstands high daily foot traffic, fixed structure eliminates tampering or rearrangement risks in public spaces | |
| Hotel business center lounges | Compact depth fits narrow lobby zones, coordinated design with matching armchairs for modular seating arrangements | |
| Executive office guest seating | Compact footprint fits in front of executive desks, formal aesthetic complements traditional office furniture | |
| Conference room breakout areas | Firm padding supports short-duration meeting breaks, metal base resists scuffing from frequent movement around the seating area | |
| Public service hall waiting zones | Wipe-clean surface supports frequent disinfection protocols, robust steel base resists scuffing from constant foot traffic around seating areas |
EU Market Access Requirements* EN Standards
| EN 15373:2007 | Applicable European standard for non-domestic seating, specifying strength, durability and stability requirements for public area furniture | |
|---|---|---|
| EN 1022:2018 | Applicable standard for seating stability, defining test methods for forward, side and rearward overturn resistance | |
| EN 13501-1 | Applicable fire classification standard for upholstered furniture materials, relevant for public space fire safety requirements |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB 18584-2001 | Applicable indoor decoration material standard, limiting formaldehyde and heavy metal emissions from furniture materials for indoor public spaces | |
|---|---|---|
| GB/T 3324-2017 | Applicable general technical standard for wooden and upholstered furniture, defining surface quality, structural strength and inspection rules | |
| GB 20286-2006 | Fire performance standard for public place furniture and components, requiring flame-retardant material ratings for high-occupancy spaces |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable indoor decoration material standard, limiting formaldehyde and heavy metal emissions from furniture materials for indoor public spaces; 2. GB/T 3324-2017: Applicable general technical standard for wooden and upholstered furniture, defining surface quality, structural strength and inspection rules; 3. GB 20286-2006: Fire performance standard for public place furniture and components, requiring flame-retardant material ratings for high-occupancy spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
