Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (3-seat sofa) | 2000 x 820 x 780 mm | |
|---|---|---|
| Large coffee table dimensions | 1200 x 600 x 450 mm | |
| Small side table dimensions | 600 x 600 x 550 mm | |
| Seat height (all seating units) | 450 mm | |
| Seat depth (all seating units) | 580 mm | |
| Seat width per seating position | 620 mm | |
| Backrest height (above seat) | 330 mm | |
| Armrest height (above floor) | 620 mm | |
| Metal base rail thickness | 25 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended user count for full set | 5 people | |
| Seam stitch tensile strength | 70 N | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Recommended total user capacity for full set | 5 people | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Matte grey woven polyester fabric | |
|---|---|---|
| Seat core cushion | 35 kg/m³ high-resilience polyurethane foam, 120mm thickness | |
| Back cushion core | 28 kg/m³ soft polyurethane foam, 80mm thickness | |
| Seating inner frame | 25mm thick kiln-dried hardwood plywood | |
| Seating base frame | Polished chrome-plated 1.5mm thick cold-rolled steel, sled-style | |
| Coffee/side table top | 18mm thick E1 grade MDF core with walnut wood veneer, matte clear lacquer finish | |
| Table support frame | Polished chrome-plated 1.2mm thick square steel tube, open cantilever frame | |
| Floor protection pads | 5mm thick non-slip PE pads attached to base feet | |
| Seat and back upholstery fabric | 300 g/m² matte grey woven polyester fabric, seam stitch pitch 8 stitches per inch | |
| Seating inner load-bearing frame | 25 mm thick kiln-dried hardwood plywood, 12% maximum moisture content, glued and stapled joinery | |
| Seating support system | 50 mm wide elastic webbing spaced 100 mm apart under seat foam | |
| Coffee/side table top substrate | 18 mm thick E1 grade MDF core, walnut natural wood veneer face, 0.15 mm matte clear polyurethane lacquer finish |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed upright position with no recline or tilt mechanism | |
|---|---|---|
| Table surface function | Flat, stable surface for placing beverages, reading materials and decorative items | |
| Sled base stability | Continuous steel base rail distributes weight evenly, no rocking on level hard flooring | |
| Set layout flexibility | Armchairs and side tables can be repositioned independently to adjust reception layout | |
| Seating ergonomics | Medium-height backrest provides lumbar support for short to medium duration guest seating | |
| Surface maintenance | Stain-resistant fabric upholstery and lacquered wood tops allow wiping clean with mild detergent | |
| Seating positioning | Fixed upright seat angle of 103 degrees with no recline, tilt, or swivel mechanism, no user adjustment controls | |
| Table surface utility | Flat, level scratch-resistant surface for placing beverages, reading materials, and small decorative items, with rounded 2 mm edge profile for safety | |
| Sled base performance | Continuous steel base rail distributes weight evenly across 4 contact points per unit, no rocking on level hard flooring, no sharp protruding edges | |
| Layout modularity | Armchairs and side tables are freestanding with no fixed inter-unit connections, allowing reconfiguration of reception layout for different group sizes | |
| Table level adjustment | Integrated 10 mm height adjustable feet on table frames allow compensation for uneven floor surfaces up to 10 mm slope | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons (full set) | 6 cartons | |
|---|---|---|
| Sofa carton dimensions | 2050 x 870 x 600 mm | |
| Single armchair carton dimensions | 950 x 870 x 600 mm | |
| Large coffee table carton dimensions | 1250 x 650 x 150 mm | |
| Side table carton dimensions | 650 x 650 x 150 mm | |
| Total gross weight (full set) | 190 kg | |
| Total shipping volume (full set) | 2.4 CBM | |
| Assembly time (full set) | 60 minutes | |
| 40HQ container loading capacity | 38 sets | |
| Single small side table carton dimensions | 650 x 650 x 150 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Professional neutral grey and wood finish creates a formal welcoming space for visitors, matches modern office design schemes | |
|---|---|---|
| Executive lounge waiting zones | Structured upright seating provides appropriate support for guests waiting for meetings, aligns with executive office aesthetics | |
| Hotel business center lobbies | Durable commercial-grade construction withstands high-traffic public use, neutral color palette coordinates with varied interior designs | |
| Small meeting breakout spaces | Modular set layout supports casual small group discussions of up to 5 people, compact footprint fits smaller rooms | |
| Studio or open plan office guest areas | Slim profile metal bases maintain an open visual feel without cluttering open workspace environments | |
| Corporate office reception lobbies | Neutral grey fabric and walnut wood finish creates a formal welcoming space for visiting guests, coordinates with modern office interior palettes | |
| Executive floor waiting zones | Structured upright seating provides appropriate formal support for guests waiting for executive meetings, chrome frame finish matches executive office furniture aesthetics | |
| Hotel business center public areas | Commercial-grade durable construction withstands high-traffic daily public use, stain-resistant fabric reduces maintenance requirements for housekeeping staff |
EU Market Access Requirements* EN Standards
| BS EN 16139 | 2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating: Applicable for commercial reception seating strength and safety acceptance | |
|---|---|---|
| BS EN 15372 | 2016 Furniture - Strength, durability and safety - Requirements for non-domestic tables: Applicable for reception table strength and safety acceptance |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for table top substrate and finish quality acceptance | |
|---|---|---|
| GB/T 1952.1-2012 Upholstered furniture | Sofas: Applicable for sofa seating load capacity, foam performance, and structural durability acceptance | |
| GB/T 21655.1-2008 Textiles - Evaluation of absorption and quick-drying - Part 1 | Method for absorbency: Applicable for upholstery fabric absorbency performance acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for table top substrate and finish quality acceptance; 2. GB/T 1952.1-2012 Upholstered furniture: Sofas: Applicable for sofa seating load capacity, foam performance, and structural durability acceptance; 3. GB/T 21655.1-2008 Textiles - Evaluation of absorption and quick-drying - Part 1: Method for absorbency: Applicable for upholstery fabric absorbency performance acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
