Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (3-seater) | 2200 x 850 x 780 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Seat depth (usable cushion) | 620 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height above seat | 350 mm | |
| Armrest height above seat | 200 mm | |
| Leg height | 120 mm | |
| Usable seating width (per position) | 630 mm | |
| Armrest width | 120 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Net product weight | 62 kg | |
|---|---|---|
| Per-seat static load capacity | 160 kg | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 32 kg/m³ | |
| Recommended daily usage duration | 8 hours | |
| Standard warranty period | 3 years | |
| Available upholstery color options | 6 | |
| Seat foam rebound rate | 45% | |
| Structural warranty period | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer arm and back upholstery | Light gray faux leather, 1.0mm thickness | |
|---|---|---|
| Seat and back cushion upholstery | Dark gray faux leather, 1.0mm thickness, abrasion resistance 50000 double rubs | |
| Internal support frame | 1.2mm thick rectangular steel tube frame | |
| Armrest edge trim | 0.8mm brushed stainless steel trim | |
| Support legs | 1.5mm thick brushed silver metal tapered legs | |
| Seat cushion core | High-resilience polyurethane foam, 120mm thickness, 40kg/m³ density, 45% rebound rate | |
| Back cushion core | Medium-density polyurethane foam, 100mm thickness, 32kg/m³ density, 40% rebound rate | |
| Sofa base deck | 8mm thick elastic webbing support | |
| Stitching specification | Polyester bonded thread, 8 stitches per 30mm | |
| Outer arm and outer back upholstery | Light gray matte faux leather, 1.0mm thickness | |
| Seat cushion and inner back upholstery | Dark gray matte faux leather, 1.0mm thickness, 50000 double rub abrasion resistance | |
| Seat support deck | 80mm wide elastic webbing, 50mm spacing, 40kg tensile strength per strap |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 3 fixed individual seating positions, no recline or adjustment | |
|---|---|---|
| Armrest design | Integrated wrap-around padded armrests on both ends with metal accent trim | |
| Floor clearance | 120 mm clearance under sofa frame | |
| Installation requirement | Fully assembled except leg attachment, tools included for leg mounting | |
| Modular compatibility | Matches 1-seat single chairs from the same product series for coordinated reception sets | |
| Surface maintenance | Stain-resistant faux leather surface, wipe-clean with neutral detergent | |
| Modular coordination | Dimensionally matched to same-series single-seat armchairs for coordinated reception seating sets | |
| Mobility restriction | Fixed non-rolling design with non-marking foot pads, no caster wheels | |
| Stress point reinforcement | Double-stitched seams at armrest and seat junction points to withstand frequent entry/exit use | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Packaged carton dimensions | 2250 x 900 x 600 mm | |
| Packaged gross weight | 70 kg | |
| Packaged volume per unit | 1.22 CBM | |
| On-site assembly time | 15 minutes | |
| 20ft GP container loading quantity | 18 units | |
| 40ft HQ container loading quantity | 46 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Corporate lobby reception areas | Coordinated set design creates a formal, polished welcome space for visiting clients and guests | |
|---|---|---|
| Executive office visitor seating | Compact footprint fits opposite executive desks for short guest meetings without blocking circulation paths | |
| Open plan breakout waiting zones | Durable wipe-clean upholstery withstands high daily traffic in shared office spaces | |
| Commercial building public waiting rooms | Commercial-rated load capacity supports continuous use in high-footfall facilities | |
| Small meeting room supplementary seating | Fixed non-adjustable design provides stable, formal seating without casual recline features suitable for short meetings | |
| Corporate main lobby reception areas | Coordinated two-tone design creates a polished professional welcome space for visiting clients, configurable with matching armchairs and coffee tables to form full seating groups | |
| Open plan office breakout waiting zones | Durable 50000 double rub upholstery withstands continuous daily high-traffic use in shared office common areas | |
| Commercial building public waiting areas | 480kg total load capacity supports continuous use in high-footfall facilities including office towers, bank branches and service centers |
European market access and chemical requirements
| Applicable upholstered furniture safety standard | EN 12520:2015 | |
|---|---|---|
| Applicable upholstery fire standard | EN 1021:2014 | |
| Applicable formaldehyde emission standard | EN 717:2004 | |
| Applicable non-domestic seating strength standard | EN 12520:2015 | |
| Applicable upholstery ignition resistance standard | EN 1021:2014 |
US and Canada office-furniture standards
Standards applicable to China-market projects
| Applicable upholstery material standard | GB 20400 | |
|---|---|---|
| Applicable hardware standard | GB/T 3324 | |
| Applicable upholstery safety standard | GB 20400 | |
| Applicable metal furniture hardware standard | GB/T 3324 | |
| Applicable furniture fire performance standard | GB 20286 |
This product must meet the following technical requirements: 1. Applicable upholstery material standard: GB 20400; 2. Applicable hardware standard: GB/T 3324; 3. Applicable upholstery safety standard: GB 20400; 4. Applicable metal furniture hardware standard: GB/T 3324; 5. Applicable furniture fire performance standard: GB 20286; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
Open Export ToolThe HUIBANG 3-Seater Office Reception Sofa, model OFS-S2200presents a polished, formal silhouette defined by a streamlined two-tone gray faux leather finish. Its smooth, uninterrupted frame features integrated wrap-around padded armrests trimmed with brushed stnless steel accents, supported by slender tapered brushed silver metal legs at each corner. The three equally sized fixed seating positions are evenly spaced across the frame, with a balanced proportion that aligns with standard commercial reception seating aesthetics, creating a structured, welcoming visual profile suitable for professional environments. Built for consistent high-traffic use, the sofa is constructed around a rectangular steel tube internal frame, with an 8mm elastic webbing support deck for even weight distribution. Outer arm and back panels are upholstered in 1.0mm thick light gray matte faux leather, while seat and inner back cushions use 1.0mm thick dark gray matte faux leather rated for 50000 double rubs of abrasion resistance. Seat cushions are cored with high-resilience polyurethane foam, pred with medium-density polyurethane foam back cushions to deliver lower to mid-back support. Seams at high-stress armrest and seat junctions use double-stitched polyester bonded thread for added durability, and non-marking foot pads on the base ensure stable stationary placement without floor damage. Designed for practical public and commercial use, the sofa offers fixed, non-adjustable upright seating optimized for short to medium duration wts, with a stn-resistant wipe-clean surface that requires only neutral detergent for routine mntenance. It features sufficient under-frame clearance for standard cleaning access, and is delivered nearly fully assembled, with only leg attachment required for setup using included tools. The design coordinates dimensionally with matching single-seat armchrs from the same product series to create cohesive seating groups. This sofa is well suited for a range of professional spaces, including corporate lobby reception areas, executive office visitor seating positions opposite work desks, open plan office breakout wting zones, commercial building public wting rooms in office towers, bank branches or service centers, and small meeting rooms as supplementary formal seating. Its neutral two-tone finish complements most modern commercial interior palettes, and its commercial-rated per-seat load capacity supports continuous dly use of up to 8 hours, backed by a 3-year warranty covering structural frame components. For procurement planning, buyers should note that the sofa ships in protective packaging, with efficient loading capacity for both 20ft GP and 40ft HQ contners to support large-scale furnishing projects. Facilities teams can plan for minimal on-site assembly time, and should account for the product’s stationary, non-rolling design when mapping space layouts to ensure clear circulation paths around placed seating. The avlable neutral upholstery options allow for coordination with existing decor, and the durable upholstery rating reduces long-term mntenance demands for high-footfall locations.
