Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seat sofa dimensions | 2100 x 850 x 820 mm | |
|---|---|---|
| Single armchair dimensions | 900 x 820 x 800 mm | |
| Matching coffee table dimensions | 1300 x 700 x 450 mm | |
| Seat height (sofa & armchairs) | 430 mm | |
| Seat depth (sofa & armchairs) | 580 mm | |
| Armrest height from floor | 620 mm | |
| Backrest height from seat surface | 390 mm | |
| Coffee table glass top thickness | 10 mm | |
| Coffee table lower shelf clearance from floor | 120 mm | |
| Chrome frame section size (sofa/armchairs) | 50 x 50 mm | |
| Single seat width on 3-seat sofa | 650 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seat sofa total static load capacity | 450 kg | |
|---|---|---|
| 3-seat sofa net weight | 85 kg | |
| Upholstery surface abrasion resistance | 50000 rub cycles | |
| Recommended total seating capacity | 5 people | |
| Foam density seat cushion | 45 kg/m³ | |
| Seat cushion foam indentation load deflection | 40 kg | |
| Frame weld joint static load resistance | 600 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Brown faux leather (PU leather) with grid tufted stitching | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Seating unit structural frame | 1.5mm thick polished chrome-plated square steel tube | |
| Backrest internal support | Plywood panel with webbing suspension | |
| Coffee table top surface | Clear tempered safety glass with polished flat edge | |
| Coffee table lower shelf | Dark brown wood veneer over MDF core | |
| Coffee table support frame | 1.2mm thick polished chrome-plated rectangular steel tube | |
| Seat base support | Sinuous spring support under seat cushions | |
| Frame foot pads | Non-marking plastic glide pads | |
| Upholstery stitching | High-tenacity polyester thread with 8mm seam pitch | |
| Chrome frame finish | Mirror polish chrome plating with 0.3micron plating thickness | |
| Backrest cushion core | 35 kg/m³ polyurethane foam, 80mm thickness |
Adjustment / rotation / tilt / mobility / storage features
| Fixed position seating design | Non-reclining, fixed upright seat and back angle for formal reception posture | |
|---|---|---|
| Tufted backrest support | Grid-pattern button tufting maintains backrest shape and provides segmented lumbar support | |
| Cantilever chrome frame structure | Welded open square steel frame distributes weight evenly without cross-braces blocking leg room | |
| Coffee table two-tier storage | Top glass surface for beverage and display use, lower wood shelf for magazine and brochure storage | |
| Floor protection glides | Non-marking glides on all frame feet prevent scratching hard polished flooring | |
| Fixed upholstered armrests | Padded armrests matching seat upholstery, supported by integrated steel frame for arm resting stability | |
| Coordinated reception set design | Matching finish across all seating units and coffee table for unified executive reception aesthetic | |
| Static structural stability | Cantilever frame design passes 10° tip-over test for public area seating safety, no rocking or movement under normal seated load | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total package count per 3+1+1+table set | 7 cartons | |
|---|---|---|
| 3-seat sofa shipping carton dimensions | 2150 x 900 x 680 mm | |
| Single armchair shipping carton dimensions | 950 x 870 x 620 mm | |
| Coffee table shipping carton dimensions | 1350 x 750 x 180 mm | |
| Total gross weight per full set | 235 kg | |
| Total shipping volume per full set | 2.65 CBM | |
| Field assembly time | 60 minutes | |
| 20ft GP container loading capacity (full sets) | 10 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive office reception areas | Formal tufted brown leather and polished chrome finish matches high-end executive office decor for visitor seating | |
|---|---|---|
| Corporate lobby waiting zones | 5-person total seating capacity with matching coffee table accommodates small groups of waiting visitors | |
| Executive private office guest seating | Two armchairs plus smaller matching table can be configured opposite an executive desk for one-on-one meetings | |
| Conference room breakout areas | Sofa and chairs provide comfortable informal seating outside formal meeting spaces for breaks or casual discussions | |
| High-end serviced office waiting areas | Consistent premium finish creates a polished first impression for client visits in shared office facilities | |
| Color availability | 1 standard color (dark brown) for stock production; custom upholstery colors available for bulk orders | |
| VIP guest waiting lounges | Formal tufted design and durable construction support extended guest waiting periods without visible wear |
EU Market Access Requirements* EN Standards
| EN 13759:2011 | Office furniture - Seating - Test methods for stability, applicable to reception seating units for tip-over prevention | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for non-domestic seating, applicable for commercial office reception use | |
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass specification, applicable to the coffee table glass top |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Standard for lounge and public seating, covering static load, stability and durability requirements for commercial reception seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable as reference for the matching reception coffee table structural performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the wood veneer coffee table shelf and internal sofa framing components | |
|---|---|---|
| GB/T 19995.2-2005 | Tempered glass safety specification applicable to the 10mm glass coffee table top for impact and breakage safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the wood veneer coffee table shelf and internal sofa framing components; 2. GB/T 19995.2-2005: Tempered glass safety specification applicable to the 10mm glass coffee table top for impact and breakage safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
