Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 3200 x 1800 x 1100 mm | |
|---|---|---|
| Curved L-shaped sofa overall dimensions | 2800 x 1600 x 900 mm | |
| Sofa seat height | 420 mm | |
| Sofa seat depth | 600 mm | |
| Sofa backrest peak height | 900 mm | |
| Lounge chair overall dimensions | 750 x 800 x 1100 mm | |
| Lounge chair seat height | 430 mm | |
| Lounge chair seat depth | 580 mm | |
| Coffee table overall dimensions | 800 x 800 x 450 mm | |
| Sofa base plinth height | 120 mm | |
| Lounge chair backrest height | 1100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 215 kg | |
|---|---|---|
| Sofa per-seat static load capacity | 150 kg | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Seating total capacity | 6 people | |
| Swivel chair rotation durability | 30000 cycles | |
| Cushion foam density | 40 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa seat cushion core | High-resilience polyurethane molded foam, density 40kg/m³ | |
|---|---|---|
| Sofa upholstery | Woven polyester commercial fabric, matte finish | |
| Sofa internal frame | Kiln-dried hardwood and plywood composite frame, 18mm thick panels | |
| Sofa lower plinth | Upholstered fabric-covered rigid frame, no exposed legs | |
| Lounge chair upholstery | Matching woven polyester fabric, integrated padded armrests | |
| Lounge chair base | Polished chrome-plated steel 4-star cross base, 3mm thick wall section | |
| Lounge chair swivel mechanism | Steel swivel plate with sealed bearing, 5mm thick plate | |
| Coffee table top | 8mm thick matte white laminate over MDF core, rounded edge profile | |
| Coffee table base | Polished chrome-plated steel Y-shaped 3-leg frame, 25mm diameter tubular steel | |
| Sofa backrest padding | 30kg/m³ polyurethane foam, 80mm thick, contoured to asymmetric peak shape | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Lounge chair 360-degree swivel | Full rotation on sealed bearing swivel mount, no tilt or height adjustment, fixed lounge position | |
|---|---|---|
| Asymmetric curved sofa layout | Continuous L-shape with peaked asymmetric backrest, fixed corner configuration fits wall corners for open meeting spaces | |
| Integrated lounge chair armrests | Fully upholstered wrap-around armrests contoured to match seat and back shape, 200mm arm height above seat | |
| Matching lumbar support pillows | One small contoured fabric pillow per lounge chair, matching upholstery color, positioned for lower back support | |
| Fixed sofa cushion design | Attached seat and back cushions with tailored upholstery, no removable loose cushions for reduced maintenance in commercial spaces | |
| Coffee table level adjustment | Small adjustable glide feet on each base leg tip to compensate for uneven carpeted floors | |
| Floor protection design | All chair and table base tips fitted with non-marking plastic glides to prevent scuffing on carpet or hard flooring | |
| Chair swivel base diameter | 680 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 6 | |
|---|---|---|
| Sofa section carton dimensions | 2200 x 850 x 650 mm | |
| Lounge chair carton dimensions | 850 x 850 x 1150 mm | |
| Coffee table carton dimensions | 850 x 850 x 150 mm | |
| Total shipping gross weight | 250 kg | |
| Total shipping volume (CBM) | 2.2 | |
| On-site assembly time | 45 minutes | |
| 40ft HQ container loading quantity | 40 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Suitable for corporate lobby spaces, creating a welcoming colored seating zone for visitors waiting for appointments | |
|---|---|---|
| Casual collaborative meeting zones | Ideal for open office breakout areas, supporting small informal team discussions for up to 6 people | |
| Creative studio and design office spaces | Bold contrasting orange, yellow and gray color scheme fits modern creative work environments, adds visual interest without requiring custom upholstery | |
| Hotel executive lounge areas | Suitable for premium hotel lounge waiting zones, providing comfortable perching for guests during check-in or lounge access | |
| Educational institution common areas | Appropriate for university student lounges and faculty meeting spaces, durable construction withstands heavy daily use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 Furniture - Seating - Strength, durability and safety requirements for non-domestic seating | Applies to strength and durability testing for all commercial lounge seating components in this set, suitable for public reception areas | |
|---|---|---|
| EN 1022:2018 Furniture - Seating - Determination of stability | Applies to stability testing of swivel chairs and curved sofa to prevent tipping during normal use | |
| EN 13722:2004 Furniture - Tables - Test methods for stability | Applies to static stability testing of the round coffee table for uneven floor conditions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 Lounge and Public Seating | Recommended performance standard for structural load, durability and stability of all seating items in commercial waiting and reception applications | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 Desk Products | Applies to static load and stability requirements for the matching round coffee table |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applies to structural safety, dimensional tolerance and finish quality requirements for all wooden and upholstered seating components in this set | |
|---|---|---|
| GB 20400-2006 Limit of harmful substances of leather and fur | Applies if fabric has coated leather elements, sets limits for formaldehyde and heavy metal content in upholstery materials | |
| GB/T 19001-2016 Quality management systems | Recommended procurement requirement for consistent production quality across all set components | |
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Applies to all MDF and plywood frame and core components, sets E1 grade formaldehyde emission limit |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applies to structural safety, dimensional tolerance and finish quality requirements for all wooden and upholstered seating components in this set; 2. GB 20400-2006 Limit of harmful substances of leather and fur: Applies if fabric has coated leather elements, sets limits for formaldehyde and heavy metal content in upholstery materials; 3. GB/T 19001-2016 Quality management systems: Recommended procurement requirement for consistent production quality across all set components; 4. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Applies to all MDF and plywood frame and core components, sets E1 grade formaldehyde emission limit; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
