Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2100 × 760 × 820 mm | |
|---|---|---|
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 58 kg | |
|---|---|---|
| Rated total seating load | 300 kg | |
| Single-seat static load | 120 kg | |
| Seat count | 3 persons | |
| Back cushion foam density | 30 kg/m3 | |
| Seat foam density | 35 kg/m3 | |
| Foam indentation resilience | 38% | |
| Fabric abrasion acceptance | 30000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 50 mm | |
| Warranty | 36 months |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Beige woven fabric with visible soft texture and tailored panel seams | |
|---|---|---|
| Seat cushion | 180 mm polyurethane foam core with fabric envelope and fibre topper | |
| Back cushions | Two 480 mm square loose fibre-filled cushions with removable fabric covers | |
| Inner load frame | Kiln-dried timber and engineered wood rail frame with reinforced corner joints | |
| Support base | Elastic webbing suspension over timber seat rails | |
| Legs | Four black tapered metal legs with outward splay and floor-protecting feet |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating layout | Continuous three-person bench seat with integrated arms and two loose back cushions | |
|---|---|---|
| Back support | Fixed upholstered back panel supplemented by two independently positioned throw cushions | |
| Support and stability | Four splayed black metal legs transfer load outside the seat footprint to improve tipping resistance | |
| Maintenance access | 150 mm floor clearance permits robot vacuum and routine cleaning access beneath the sofa |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary space | Living rooms, executive lounges, hotel suites and reception areas needing compact three-person seating | |
|---|---|---|
| Recommended arrangement | Place opposite two matching armchairs with a rectangular coffee table in a 3200 mm wide conversation zone |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
