Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 1800 x 750 x 750 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 750 x 750 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (all seating pieces) | 550 mm | |
| Armrest height from seat surface | 200 mm | |
| Backrest height from seat surface | 380 mm | |
| Armrest width (each side) | 120 mm | |
| Coffee table glass thickness | 10 mm | |
| Coffee table metal leg section | 50 x 50 mm | |
| Clearance under seating pieces | 100 mm | |
| Seat cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set reference weight | 145 kg | |
|---|---|---|
| 3-seat sofa total static load capacity | 450 kg | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Foam density (seat cushions) | 40 kg/m³ | |
| Recommended maximum occupancy | 5 people | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Total set net weight | 152 kg | |
| Seat foam density | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Chrome plating corrosion resistance | 48 hours |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating outer upholstery | Black smooth PVC faux leather, matte finish | |
|---|---|---|
| Seat cushion padding | High-density polyurethane foam | |
| Backrest padding | Medium-density polyurethane foam | |
| Armrest padding | Integral polyurethane foam wrapped in matching faux leather | |
| Seating support legs | Polished chrome-plated square steel tube | |
| Internal seating frame | 1.2mm thick welded steel tube | |
| Coffee table top | 10mm thick black tempered glass with polished edge | |
| Coffee table frame and legs | Polished chrome-plated square steel tube, matching seating leg finish | |
| Underside dust cover | Black non-woven fabric | |
| Seat support base | Elastic webbing suspension | |
| Seat support suspension | 70mm wide elastic webbing, 80mm spacing | |
| Leg floor glides | 10mm diameter nylon injection-molded glides |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed stationary design with no recline, swivel, or adjustable components | |
|---|---|---|
| Surface cleanability | Wipe-clean faux leather upholstery compatible with standard office disinfectants | |
| Coffee table surface function | Flat tempered glass surface provides stable placement for laptops, beverages, magazines, and reception materials | |
| Elevated floor clearance | 100mm gap under all furniture pieces allows standard vacuum cleaners and cleaning tools to access under units | |
| Structural alignment | Matching leg finish and upholstery across all pieces provides coordinated modular reception layout | |
| Wall placement compatibility | Flat straight backrests allow seating to be positioned flush against reception area walls | |
| Floor protection | Integral plastic glide feet fitted to the base of each metal leg prevent scratching hard floor surfaces | |
| Color option availability | Available in black as standard; typical commercial SKUs offer additional brown and grey upholstery options | |
| Seating structure | Fixed stationary design with no recline, swivel, or adjustment mechanisms | |
| Coffee table utility | Flat tempered glass surface supports stable placement of laptops, beverages, magazines, and reception collateral | |
| Floor clearance access | 100mm gap under all furniture pieces allows access for standard 90mm cleaning head vacuum cleaners and flat mop heads | |
| Layout modularity | Matching leg finish and upholstery across all pieces supports flexible linear, U-shaped, or L-shaped reception area layouts |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 | |
|---|---|---|
| 3-seat sofa packed carton dimensions | 1850 x 800 x 650 mm | |
| Single armchair packed carton dimensions | 900 x 800 x 650 mm | |
| Coffee table packed carton dimensions | 1250 x 650 x 150 mm | |
| Total shipped gross weight | 175 kg | |
| Total shipping volume | 2.2 CBM | |
| On-site assembly time | 40 minutes | |
| Recommended 40HQ container load quantity | 42 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for corporate lobby and waiting areas, providing formal coordinated seating for visiting clients and guests | |
|---|---|---|
| Executive meeting spaces | Usable in small executive meeting rooms for short informal discussions, with coffee table for document and beverage placement | |
| Public service waiting rooms | Appropriate for government, bank, or healthcare service waiting areas, with durable easy-clean upholstery for high-traffic use | |
| Small business lounge areas | Suitable for startup or co-working lounge spaces, providing comfortable seating for informal breaks and visitor waiting | |
| Recommended matching configuration | Pairs with low-pile commercial carpet or hard tile flooring, with no additional side tables required for small reception layouts | |
| User suitability | Designed for adult users across standard height ranges, with seat height optimized for easy standing and sitting during short waiting periods | |
| Corporate office reception lobbies | Suitable for main entry waiting areas, providing formal coordinated seating for visiting clients and guests | |
| Small executive meeting spaces | Usable in compact executive meeting rooms for short informal discussions, with integrated coffee table for document and beverage placement |
EU Market Access Requirements* EN Standards
| Office seating stability recommendation | EN 13761:2004 | |
|---|---|---|
| Furniture surface durability recommendation | EN 14465:2004 | |
| Glass furniture safety recommendation | EN 12150:2015 | |
| Office visitor seating stability recommendation | EN 13761:2004 | |
| Upholstery fabric durability recommendation | EN 14465:2004 | |
| Toughened glass safety recommendation | EN 12150:2015 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Tempered glass safety recommendation | GB 15763.2 | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584 | |
| Metal furniture coating recommendation | GB/T 3325 |
This product must meet the following technical requirements: 1. Tempered glass safety recommendation: GB 15763.2; 2. Formaldehyde emission recommendation: GB 18584; 3. Metal furniture coating recommendation: GB/T 3325; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
