Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2200 x 850 x 750 mm | |
|---|---|---|
| Single-seat armchair overall dimensions | 950 x 850 x 750 mm | |
| Coffee table overall dimensions | 1200 x 700 x 450 mm | |
| Sofa seat height from floor | 420 mm | |
| Sofa seat depth | 600 mm | |
| Sofa armrest height from seat | 180 mm | |
| Sofa backrest height from seat | 330 mm | |
| Coffee table lower shelf clearance | 180 mm | |
| Sofa support foot height | 30 mm | |
| Coffee table leg section size | 50 x 50 mm | |
| Sofa cushion thickness | 120 mm | |
| Coffee table upper glass overhang | 50 mm | |
| Sofa arm width | 120 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Single sofa seat static load capacity | 150 kg per seat | |
|---|---|---|
| 3-seater sofa net weight | 75 kg | |
| Upholstery abrasion resistance | 50000 cycles | |
| Recommended seating capacity for full set | 5 persons | |
| Sofa frame structural durability | 10 years of regular commercial use | |
| Seam tensile strength | 120 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa outer upholstery | Black matte faux leather (PU leather) | |
|---|---|---|
| Sofa seat cushion core | 40 kg/m³ high-density polyurethane foam | |
| Sofa backrest cushion core | 30 kg/m³ medium-density polyurethane foam | |
| Sofa internal frame | 25 mm thick kiln-dried hardwood frame | |
| Sofa support feet | Polished chrome-plated square metal feet | |
| Coffee table top surface | 12 mm thick black tempered safety glass | |
| Coffee table lower shelf | 8 mm thick black tempered safety glass | |
| Coffee table frame and legs | Polished chrome-plated 1.2 mm thick steel tube | |
| Seat support platform | 4 mm thick sinuous spring webbing | |
| Upholstery stitching | High-strength polyester bonded thread, 8 stitches per inch | |
| Back support layer | 25 mm thick recycled cotton padding layer | |
| Sofa base dust cover | 20 g/m² non-woven black fabric |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed integrated 1+1+3 modular set | |
|---|---|---|
| Seat support function | Sinuous spring suspension under seat foam | |
| Coffee table storage function | Dual-tier open shelf design | |
| Floor protection function | Integrated non-slip felt pads under all metal sofa feet | |
| Cleaning and maintenance | Smooth non-porous faux leather upholstery | |
| Structural stability | Fixed non-tilting frame construction | |
| Coffee table edge protection | Rounded polished glass edges on all glass surfaces | |
| Arrangement flexibility | Independent free-standing seating units | |
| Upholstery stain resistance | Non-porous PU surface, resistant to common office beverage spills including coffee, tea and water | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total number of shipping packages | 4 | |
|---|---|---|
| 3-seater sofa shipping carton dimensions | 2250 x 900 x 650 mm | |
| Single armchair shipping carton dimensions | 1000 x 900 x 650 mm per unit | |
| Coffee table shipping carton dimensions | 1250 x 750 x 150 mm | |
| Total shipping gross weight | 180 kg | |
| Total shipping volume (CBM) | 2.75 | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 12 sets | |
| 40ft HQ container loading quantity | 30 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for formal executive reception lobbies and guest waiting areas, projecting a professional, modern business image for visiting clients and partners | |
|---|---|---|
| Executive office meeting spaces | Designed for placement in private executive offices for small informal meetings and guest seating during one-on-one discussions | |
| Institutional waiting areas | Appropriate for bank, government service hall and institutional public waiting spaces, with durable, easy-to-clean upholstery for high-traffic use | |
| Conference room breakout zones | Suitable for breakout and rest areas adjacent to large conference rooms, providing comfortable short-duration seating for meeting attendees | |
| Recommended supporting configuration | Pairs with matching glass side tables and table lamps to create a cohesive, polished reception space layout as shown in reference imagery | |
| User suitability | Designed for adult guests and staff, supporting upright formal seating posture for 60 minute waits or conversations without deep lounge recline | |
| Property sales center reception halls | Suitable for real estate sales offices and property showrooms, with scratch-resistant chrome feet and stain-resistant upholstery suitable for daily visitor use over extended sales cycles |
EU Market Access Requirements* EN Standards
| EN 13759:2001 | Applicable European standard for domestic and contract seating furniture stability, testing resistance to overturning during normal use | |
|---|---|---|
| EN 12520:2015 | Applicable standard for furniture strength, durability and safety requirements for seating used in non-domestic commercial environments | |
| EN 12150-1:2015 | Applicable standard for thermally toughened soda lime silicate safety glass used in furniture, covering mechanical strength and safety properties | |
| EN 1022:2005 | Applicable European standard for seating furniture stability testing, verifying resistance to forward, rearward and side overturning |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture, covering internal frame material quality, dimensional stability and structural safety | |
|---|---|---|
| GB 15763.2-2005 | Applicable standard for tempered safety glass used in furniture, specifying impact resistance, fragmentation safety requirements for glass table components | |
| GB/T 16799-2008 | Applicable standard for polyurethane synthetic leather used in furniture, covering abrasion resistance, peel strength and color fastness requirements | |
| GB 28007-2011 | Applicable standard for strength and durability of furniture used in public spaces, covering static load, impact and fatigue testing for commercial seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture, covering internal frame material quality, dimensional stability and structural safety; 2. GB 15763.2-2005: Applicable standard for tempered safety glass used in furniture, specifying impact resistance, fragmentation safety requirements for glass table components; 3. GB/T 16799-2008: Applicable standard for polyurethane synthetic leather used in furniture, covering abrasion resistance, peel strength and color fastness requirements; 4. GB 28007-2011: Applicable standard for strength and durability of furniture used in public spaces, covering static load, impact and fatigue testing for commercial seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
