Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2100 × 850 × 850 mm | |
|---|---|---|
| Sofa seat height | 420 mm | |
| Sofa seat depth | 550 mm | |
| Sofa backrest height above seat | 430 mm | |
| Sofa armrest width | 150 mm | |
| Coffee table glass top thickness | 10 mm | |
| Table metal frame tube section | 40 x 20 mm | |
| Sofa seat cushion thickness | 120 mm | |
| Sofa backrest cushion thickness | 100 mm | |
| Side table glass top thickness | 8 mm | |
| Sofa base clearance above floor | 20 mm | |
| Seating knee room depth for 3-seat sofa | 550 mm | |
| Armrest height above seat surface | 180 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| 3-seat sofa net weight | 75 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seating set total seating capacity | 5 persons | |
| Upholstery abrasion resistance reference | 50000 Martindale cycles | |
| Foam density for seat cushions | 40 kg/m³ | |
| Seat foam compression set rating | 4 % | |
| Seating frame structural durability | 50000 seat impact cycles | |
| Table frame stability lateral load rating | 300 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seating upholstery | Black smooth faux leather (PU leather) | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Backrest cushion core | Medium-density polyurethane foam | |
| Seating inner frame | Kiln-dried solid hardwood + plywood composite | |
| Table tops | 10mm thick tempered black glass | |
| Table support frames | Polished chrome-plated rectangular steel tube | |
| Sofa base support | Black matte finish solid block feet | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Seating suspension support | 70mm wide elastic webbing, 50mm spacing, sinuous steel spring reinforcement | |
| Floor protection glides | Hard non-marking polypropylene glides, 20mm diameter, fitted to all furniture feet | |
| Backrest throw cushions | Matching black faux leather cover, filled with 25D polyurethane foam and polyester fiber blend | |
| Table frame joinery | Welded steel joints with polished weld seams, allen-key bolted leg assembly |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed non-reclining upright posture design | |
|---|---|---|
| Table surface function | Smooth non-porous glass surface for easy cleaning and stain resistance | |
| Set layout function | Symmetric face-to-face reception arrangement | |
| Base stability | Full perimeter block base on seating units prevents tipping and eliminates sharp exposed frame edges | |
| Floor protection | Non-marking glide pads fitted to all furniture feet | |
| Cleaning functionality | Faux leather upholstery and glass table surfaces support daily wipe-down with standard commercial cleaning agents without material degradation | |
| Assembly functionality | Table units ship with detachable legs, requiring only allen key attachment of legs to pre-drilled frame mounts, no permanent on-site welding or cutting required | |
| Modular layout flexibility | Individual seating and table units can be reconfigured into linear, L-shaped or clustered arrangements to fit different reception area dimensions without structural modification | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total shipping units | 7 cartons | |
|---|---|---|
| Largest carton dimensions (3-seat sofa) | 2150 x 900 x 650 mm | |
| Total shipment gross weight | 185 kg | |
| Total shipment CBM | 2.9 cbm | |
| On-site assembly time | 60 minutes | |
| 40ft HQ container loading quantity | 42 sets | |
| Single armchair carton dimensions | 950 x 850 x 620 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Single side table carton dimensions | 600 x 600 x 120 mm | |
| Reference Package Count | 1 set / 2 cartons |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate reception areas | Suitable for company lobby and guest waiting zones, provides formal professional seating for visiting clients and partners | |
|---|---|---|
| Executive office meeting spaces | Ideal for informal meeting areas inside private executive offices, supports small group discussions between staff and visitors | |
| Public service waiting rooms | Appropriate for government service halls, bank branches and medical clinic waiting areas, durable upholstery withstands high daily foot traffic | |
| Small business lounge zones | Suitable for startup office breakout areas and staff lounge spaces, coordinated styling matches modern minimalist office interiors | |
| Recommended floor placement | Works best on low-pile commercial carpet or hard flooring, no additional underlay required due to stable solid base construction | |
| Matching furniture compatibility | Coordinates with standard office bookcases and storage cabinets in neutral black, white or light wood finishes for a unified office aesthetic | |
| Recommended matching configuration | Coordinates with standard office bookcases and storage cabinets in black, white or light wood finishes for a unified office reception aesthetic |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture safety recommendation | EN 16139:2013 Furniture - Strength, durability and safety for non-domestic seating | |
|---|---|---|
| Glass furniture safety recommendation | EN 12150:2015 Glass in building - Thermally toughened soda lime silicate safety glass | |
| Furniture surface fire safety recommendation | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Tempered glass safety recommendation | GB 15763.2Safety glazing materials for building - Part 2: Tempered glass | |
| Upholstery durability recommendation | GB/T 19001Quality management systems requirement | |
| Upholstered furniture durability recommendation | GB/T 2012Upholstered furniture - Sofas | |
| Metal furniture finish recommendation | GB/T 3325General technical requirements for metal furniture |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324General technical requirements for wooden furniture; 2. Tempered glass safety recommendation: GB 15763.2Safety glazing materials for building - Part 2: Tempered glass; 3. Upholstery durability recommendation: GB/T 19001Quality management systems requirement; 4. Upholstered furniture durability recommendation: GB/T 2012Upholstered furniture - Sofas; 5. Metal furniture finish recommendation: GB/T 3325General technical requirements for metal furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
