Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2000 x 850 x 880 mm | |
|---|---|---|
| Single armchair overall dimensions | 850 x 820 x 880 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height from floor | 450 mm | |
| Seat depth (single/3-seat) | 550 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height from seat surface | 430 mm | |
| Armrest height from seat surface | 180 mm | |
| Sofa leg height | 150 mm | |
| Coffee table top thickness | 25 mm | |
| Coffee table frame tube size | 20 x 40 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seat sofa static load capacity | 450 kg | |
|---|---|---|
| Total set net weight range | 135 kg | |
| Seating capacity | 5 persons | |
| Foam density (seat/back) | 40 kg/m³ | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Recommended warranty period | 3 years | |
| Seam strength | 220 N | |
| Recommended structural warranty period | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa seating and back upholstery | Dark brown matte faux leather (PU leather) | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Backrest cushion core | Medium-density polyurethane foam with vertical pleated upholstery detailing | |
| Sofa internal frame | Kiln-dried hardwood + plywood structural frame | |
| Sofa legs | Matte black powder-coated angled tapered metal legs | |
| Coffee table top | Light oak wood-look high-pressure laminate (HPL) on particleboard core | |
| Coffee table support frame | Matte black powder-coated rectangular steel tube open frame | |
| Armrest padding | Same faux leather upholstery over high-density foam padding | |
| Sofa bottom dust cover | Black non-woven fabric under-seat dust cover | |
| Sofa seat support | 80 mm sinuous spring suspension with 50 mm elastic webbing | |
| Leg floor glides | Injection-molded polyethylene glides, press-fitted to leg bottom | |
| Upholstery adhesive | Low-VOC water-based upholstery adhesive |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 1 x 3-seat sofa + 2 x single armchairs | |
|---|---|---|
| Lumbar support | Integrated vertically pleated lumbar section on all seat backrests | |
| Coffee table placement | Freestanding open-frame coffee table positioned central to seating group | |
| Floor protection | Injection-molded plastic glides fitted to bottom of all metal legs | |
| Upholstery maintenance | Smooth non-porous faux leather surface, cleanable with mild detergent and damp cloth | |
| Structural stability | Fixed non-reclining, non-swivel seating structure with 4 angled metal legs per unit | |
| Clearance under coffee table | 425 mm floor clearance under table frame | |
| Color option availability | Dark brown upholstery finish, black frame finish, light wood table top | |
| Coffee table function | Freestanding open-frame coffee table positioned central to seating group, 425 mm under-table floor clearance | |
| Finish durability | Matte black powder-coated frame finish, 60 μm coating thickness, scratch and rust resistant for indoor commercial use | |
| Set layout compatibility | 3400 x 2400 mm minimum required floor space for full set arrangement with 800 mm circulation clearance between seating and table | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping cartons | 4 cartons | |
|---|---|---|
| 3-seat sofa carton dimensions | 2050 x 900 x 650 mm | |
| Single armchair carton dimensions (per unit) | 900 x 870 x 650 mm | |
| Coffee table carton dimensions | 1250 x 650 x 120 mm | |
| Total set gross shipping weight | 160 kg | |
| Total shipping volume (CBM) | 2.5 CBM | |
| Assembly time per full set | 40 minutes | |
| 20ft GP container loading capacity | 22 sets | |
| 40ft HQ container loading capacity | 56 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for front-of-house waiting zones, providing formal professional seating for visiting clients and guests | |
|---|---|---|
| Executive office meeting nooks | Suitable for placement in private executive offices for small informal meetings with 5 attendees | |
| Public institution waiting rooms | Suitable for government, bank or service center waiting areas, with durable easy-to-clean upholstery for high daily foot traffic | |
| Small business lounge spaces | Suitable for startup office lounges or employee break areas, providing comfortable structured seating for short rests | |
| Hotel business center waiting zones | Suitable for hotel business centers or conference floor pre-function areas, matching business hospitality interior palettes | |
| Recommended matching accessories | Pair with office area rugs, table lamps and side tables to complete reception layout, coffee table sized for placement of magazines, water cups and promotional materials | |
| Medical clinic administrative waiting areas | Suitable for private clinic or dental office administrative waiting zones, with non-porous upholstery that supports sanitization between visitor use |
EU Market Access Requirements* EN Standards
| Applicable EN 13761:2002 | Office furniture - Visitor chairs, applicable to single armchairs and sofa seating units | |
|---|---|---|
| Applicable EN 15372:2008 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable to reception coffee table | |
| Applicable EN 1022:2018 | Furniture - Seating - Determination of stability, applicable to all seating units | |
| Applicable EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, referenced for structural durability of public reception seating |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Applicable GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal structural frame and coffee table wood-based components | |
|---|---|---|
| Applicable GB/T 19995.1-2005 | Technical requirements for polyurethane synthetic leather for furniture, applicable to faux leather upholstery | |
| Applicable GB 18584-2001 | Limit of harmful substances in wood furniture for interior decoration materials, applicable to all wood-based components | |
| Applicable GB/T 35607-2017 | Green product assessment specification for furniture, recommended for public area procurement environmental requirements |
This product must meet the following technical requirements: 1. Applicable GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal structural frame and coffee table wood-based components; 2. Applicable GB/T 19995.1-2005: Technical requirements for polyurethane synthetic leather for furniture, applicable to faux leather upholstery; 3. Applicable GB 18584-2001: Limit of harmful substances in wood furniture for interior decoration materials, applicable to all wood-based components; 4. Applicable GB/T 35607-2017: Green product assessment specification for furniture, recommended for public area procurement environmental requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
