Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2200 x 850 x 820 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 820 x 800 mm | |
| 3-seat sofa seat height | 420 mm | |
| 3-seat sofa seat depth | 620 mm | |
| 3-seat sofa backrest height | 400 mm | |
| Single armchair seat width | 680 mm | |
| Single armchair seat depth | 600 mm | |
| Coffee table overall dimensions | 900 x 900 x 450 mm | |
| Coffee table glass top thickness | 12 mm | |
| Sofa leg height | 150 mm | |
| Sofa armrest width | 120 mm | |
| Floor clearance under sofas | 120 mm | |
| 3-seat sofa seat cushion thickness | 120 mm | |
| 3-seat sofa back cushion thickness | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 78 kg | |
|---|---|---|
| 3-seat sofa total static load capacity | 450 kg | |
| Seating set total user capacity | 5 persons | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Cushion foam compression set | 10% | |
| Cushion foam rebound rate | 55% | |
| Seam tensile strength | 120 N | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seating upholstery | Taupe matte faux leather (PU leather), stitched panel construction | |
|---|---|---|
| Seat cushion core | 45kg/m³ high-density polyurethane foam, wrapped with soft polyester fiber layer | |
| Back cushion core | 35kg/m³ high-resilience polyurethane foam, with matching fiber wrap | |
| Seating internal frame | Kiln-dried solid hardwood + 12mm plywood structural frame, dowel and corner block reinforced | |
| Sofa support legs | 1.5mm thick matte black powder-coated carbon steel, angled tapered design | |
| Coffee table top | 12mm thick clear tempered glass, polished rounded edge | |
| Coffee table frame | 1.2mm thick brushed 304 stainless steel tubular frame, circular base ring and 4 vertical support posts | |
| Seating support base webbing | 50mm wide elastic webbing, 80mm spacing grid under seat cushions | |
| Seam construction | Matching taupe polyester thread, 8 stitches per inch seam pitch | |
| Floor protection pads | 3mm thick non-slip rubber pads affixed to base of all metal legs | |
| Single armchair throw pillow | 30kg/m³ soft polyurethane foam fill, matched taupe faux leather cover | |
| Coffee table foot pads | 2mm thick transparent silicone anti-slip pads affixed to base of frame ring |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed upholstered 3+1+1 arrangement, no recline or adjustable components | |
|---|---|---|
| Cushion design | Fixed attached seat and back cushions, no removable cushion covers | |
| Coffee table access | Open circular underframe without lower shelf, providing full knee clearance for seated users on all surrounding seats | |
| Floor cleaning access | 120mm floor clearance under all seating units to accommodate standard flat mop and robot vacuum access | |
| Structural stability | Four-point angled leg placement on each seating unit, with outboard leg positioning to prevent tipping when users sit on armrest edges | |
| Surface performance | Faux leather upholstery with stain-resistant wipe-clean surface, suitable for high-traffic public reception areas | |
| Set layout flexibility | Modular standalone units allowing flexible arrangement to suit different reception room dimensions | |
| Upholstery performance | PU upholstery with 1.2mm material thickness providing breathability suitable for continuous 4 hour seating without discomfort | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total shipping cartons | 6 cartons | |
|---|---|---|
| Largest carton dimensions (3-seat sofa) | 2250 x 880 x 650 mm | |
| Single armchair carton dimensions | 930 x 850 x 630 mm | |
| Coffee table glass carton dimensions | 950 x 950 x 80 mm | |
| Coffee table frame carton dimensions | 920 x 920 x 420 mm | |
| Total gross shipping weight | 165 kg | |
| Total shipment volume | 2.4 CBM | |
| On-site assembly time | 40 minutes | |
| 40ft HQ container loading quantity | 42 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Formal neutral taupe upholstery and clean modern design suitable for executive floor guest waiting spaces, projecting professional understated corporate image | |
|---|---|---|
| Public institution waiting lobbies | Stain-resistant easy-clean upholstery and durable frame construction suitable for medium-traffic public waiting areas in government, bank or hospital administration spaces | |
| VIP meeting lounge areas | Comfortable upright seating posture and matching coffee table suitable for small informal meetings and guest refreshment service in private lounge zones | |
| Open-plan office breakout zones | Compact modular layout can be rearranged to fit open collaborative breakout areas for team informal discussion | |
| High-end serviced office common areas | Coordinated 3+1+1 set provides a complete ready-to-install reception solution for serviced office providers to furnish shared guest spaces | |
| Hotel business center waiting zones | Formal design and durable materials match hotel public area furniture requirements for long service life with minimal maintenance | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture - Seating - Determination of stability, applicable to verify anti-tipping performance of all seating units | |
|---|---|---|
| EN 12520:2015 | Furniture - Strength, durability and safety - Requirements for domestic seating, applicable for structural load and durability testing of upholstered seating units | |
| EN 12150-1:2015 | Glass in building - Thermally toughened soda lime silicate safety glass, applicable to the coffee table tempered glass top | |
| EN 14465:2003 | Furniture - Upholstery fabrics - Specification and test methods, applicable to verify abrasion and performance of the faux leather upholstery |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and dimension tolerance of the upholstered seating frames | |
|---|---|---|
| GB/T 19995.2-2005 | Safety requirements for glass furniture, applicable to the tempered glass coffee table top to ensure impact resistance and edge safety | |
| GB 20400-2006 | Limit of harmful substances in leather and fur, applicable to faux leather upholstery to control VOC and heavy metal content | |
| GB/T 35607-2017 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and dimension tolerance of the upholstered seating frames; 2. GB/T 19995.2-2005: Safety requirements for glass furniture, applicable to the tempered glass coffee table top to ensure impact resistance and edge safety; 3. GB 20400-2006: Limit of harmful substances in leather and fur, applicable to faux leather upholstery to control VOC and heavy metal content; 4. GB/T 35607-2017: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
