Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 1900 x 800 x 800 mm | |
|---|---|---|
| single armchair overall dimensions | 780 x 760 x 800 mm | |
| coffee table overall dimensions | 1200 x 600 x 450 mm | |
| sofa seat height | 430 mm | |
| sofa seat depth | 520 mm | |
| sofa backrest height | 400 mm | |
| sofa armrest height | 620 mm | |
| armrest steel frame tube diameter | 50 mm | |
| coffee table lower shelf height | 200 mm | |
| side end table overall dimensions | 600 x 600 x 500 mm | |
| cantilever frame front clearance under seats | 150 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 3-seater sofa net weight | 55 kg | |
|---|---|---|
| 3-seater sofa total static load capacity | 450 kg | |
| seating upholstery abrasion resistance | 50000 cycles | |
| sofa foam compression recovery rate | 92% | |
| tempered glass tabletop impact resistance | 1000 g steel ball drop from 1m height | |
| cantilever frame fatigue cycle rating | 20000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat and back upholstery | 1.2mm thick dark brown polyurethane faux leather, tufted button detail | |
|---|---|---|
| seat core padding | 40mm thick high-density polyurethane foam, density 35kg/m³ | |
| backrest core padding | 30mm thick medium-density polyurethane foam, density 30kg/m³ | |
| armrest padding | 20mm thick foam wrapped under matching faux leather, padded top surface | |
| seating support frames | 1.5mm thick chrome-plated square steel tube, polished mirror finish, cantilever base design | |
| coffee table tabletops | 12mm thick black tempered safety glass, polished edge finish | |
| table support frames | 1.2mm thick polished chrome-plated steel square tube, welded corner joints | |
| frame base floor glides | Non-marking nylon adjustable glides at frame contact points | |
| upholstery stitching | High-strength polyester bonded thread, 8 stitches per 30mm seam pitch | |
| frame anti-corrosion treatment | Nickel-chrome multi-layer plating with 0.02mm chrome layer thickness | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Fixed reception seating design | No recline or adjustment mechanism, optimized for upright formal guest seating in public office areas | |
|---|---|---|
| Cantilever frame flex support | Steel cantilever base provides controlled passive flex when seated, eliminating need for separate spring suspension | |
| Dual-level coffee table storage | Upper glass surface for beverage and refreshment placement, lower glass shelf for decorative items or reading material storage | |
| Non-marking floor protection | Nylon glides prevent scuffing and scratching on polished tile, wood or vinyl office flooring | |
| Tufted upholstery anti-slip | Button tufting holds upholstery and foam in place, preventing material shift during extended high-traffic use | |
| Matching set modular layout | 1 three-seater sofa, 2 single armchairs, 1 coffee table, and 1 side table can be arranged in multiple open or clustered reception configurations | |
| Surface spill resistance | Faux leather upholstery and glass tabletops can be wiped clean with standard office cleaning agents without staining | |
| Stable cantilever weight distribution | Wide outward-angled cantilever legs eliminate tipping risk when occupants lean back against backrests | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 6 cartons | |
|---|---|---|
| 3-seater sofa carton dimensions | 1950 x 850 x 500 mm | |
| Single armchair carton dimensions | 820 x 800 x 500 mm each | |
| Table set carton dimensions | 1250 x 650 x 180 mm for coffee table, 650 x 650 x 120 mm for side table | |
| Total shipping gross weight | 155 kg | |
| Total shipping volume | 1.5 CBM | |
| On-site assembly time | 100 minutes | |
| 40HQ container loading quantity | 52 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for lobby and waiting zones to seat 5 guests, formal professional appearance for executive office entrances | |
|---|---|---|
| Business lounge and meeting waiting spaces | Durable upholstery and easy-clean surfaces support high daily traffic in shared public areas | |
| Small conference breakout rooms | Compact footprint allows flexible arrangement in team meeting and informal discussion spaces | |
| Executive private office guest seating | Two armchairs and side table can be deployed for 1:1 meeting seating in individual office spaces | |
| Hotel and bank public waiting areas | Neutral dark brown and chrome finish complements a wide range of modern commercial interior design palettes | |
| Recommended paired accessories | Low-pile commercial area rugs, floor lamps, framed wall art to complete the curated reception look shown in the product display |
EU Market Access Requirements* EN Standards
| Office seating safety requirement applicability | EN 1335:2018, applicable for stability, strength and durability requirements for non-adjustable office reception seating | |
|---|---|---|
| Glass furniture safety applicability | EN 12150:2015, applicable for thermally toughened soda lime silicate safety glass used in table components | |
| Furniture surface fire resistance applicability | EN 1021:2014, applicable for cigarette ignition resistance of upholstered seating for public spaces |
US and Canada office-furniture standards
| Lounge seating performance applicability | ANSI/BIFMA X2020applicable for static load, durability and stability testing of public area lounge seating | |
|---|---|---|
| Occasional table performance applicability | ANSI/BIFMA X2021applicable for strength, durability and stability requirements for office reception tables |
Standards applicable to China-market projects
| Upholstered furniture safety requirement applicability | GB 28007applicable for structural safety and stability requirements of upholstered seating used in public office spaces | |
|---|---|---|
| Tempered glass furniture safety applicability | GB 15763.2applicable for safety requirements of tempered glass used in table surfaces for public area furniture | |
| Formaldehyde emission limit applicability | GB 18580applicable for emission limits for any wood-based composite materials used in seating assembly | |
| Furniture mechanical performance applicability | GB/T 3324applicable for durability and static load testing requirements for metal frame office furniture |
This product must meet the following technical requirements: 1. Upholstered furniture safety requirement applicability: GB 28007applicable for structural safety and stability requirements of upholstered seating used in public office spaces; 2. Tempered glass furniture safety applicability: GB 15763.2applicable for safety requirements of tempered glass used in table surfaces for public area furniture; 3. Formaldehyde emission limit applicability: GB 18580applicable for emission limits for any wood-based composite materials used in seating assembly; 4. Furniture mechanical performance applicability: GB/T 3324applicable for durability and static load testing requirements for metal frame office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
