Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2000 × 850 × 820 mm | |
|---|---|---|
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Three-seat sofa seating capacity | 3 persons | |
|---|---|---|
| Single armchair seating capacity | 1 person per chair | |
| Complete set seating capacity | 5 persons | |
| Three-seat sofa distributed seat load | 300 kg total | |
| Single armchair static seat load | 160 kg | |
| Backrest static load | 90 kg per seating position | |
| Foam density, seat cushions | 38 kg/m3 | |
| Foam density, back cushions | 28 kg/m3 | |
| Seat foam indentation support factor | 2.4 | |
| Net weight, complete seating set | 115 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery surface | Black full-grain leather-look upholstery with tight tailored panel seams | |
|---|---|---|
| Seat cushioning | High-resilience polyurethane foam, 120 mm thick seat core, 38 kg/m3 density target | |
| Back cushioning | Bonded polyurethane fill over 28 kg/m3 foam in fixed upholstered backs | |
| Internal load frame | Kiln-dried hardwood and engineered wood composite frame, 25 mm structural rail target | |
| Support legs | Chrome or brushed stainless steel rectangular sled legs with four floor contacts per seating unit | |
| Coffee table | Matte dark wood-composite top and side panels with an open lower display shelf |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed reception configuration | Three-seat sofa and two identical armchairs face the central coffee table for formal visitor seating | |
|---|---|---|
| Fixed cushion design | Seat and back cushions are built into tailored upholstered frames rather than removable loose cushions | |
| Low open-shelf table | Coffee table provides a 1200 x 600 mm top and a full-width under-top shelf for magazines or presentation materials | |
| Floor-level support | Each seating unit uses a slim metal perimeter base with short vertical legs, leaving a 100 mm cleaning gap |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary reception application | Corporate lobby, executive waiting area or formal meeting lounge, providing five fixed seats around a central table | |
|---|---|---|
| Facility procurement fit | Suitable for offices, hotels and serviced business centers needing wipeable black upholstery and compact metal-leg furniture |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
