| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2000 x 850 x 800 mm | |
|---|---|---|
| Single armchair overall dimensions | 920 x 820 x 800 mm | |
| Seat height (all seating units) | 420 mm | |
| Seat depth (all seating units) | 580 mm | |
| Backrest height (above seat surface) | 420 mm | |
| Armrest height (above floor) | 620 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Wood veneer side panel thickness | 18 mm | |
| Support foot height | 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seat sofa net weight | 75 kg | |
|---|---|---|
| Seat static load capacity (per seat position) | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Recommended seating capacity | 5 persons | |
| Seam stitch tensile strength | 100 N | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Black 1.2mm thick PU faux leather | |
|---|---|---|
| Side panel trim | Curved walnut-grain engineered wood veneer over MDF core | |
| Seat cushion padding | High-density polyurethane foam, 80mm thick seat core | |
| Backrest padding | High-density polyurethane foam, 50mm thick back core | |
| Armrest padding | 30mm thick polyurethane foam wrapped with matching PU upholstery | |
| Seating internal frame | 25mm thick kiln-dried hardwood and engineered wood composite frame | |
| Seating support feet | Polished chrome-plated steel, rectangular low-profile design | |
| Coffee table frame | Polished 30x30mm square section chrome-plated steel tube | |
| Coffee table top | 12mm thick black tempered matte glass / high-pressure laminate panel | |
| Seat support system | 4mm thick sinuous steel spring suspension with 80mm spacing, covered with 50g polyester non-woven fabric | |
| Coffee table foot pads | 10mm diameter adjustable nylon glides | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright posture support | |
|---|---|---|
| Upholstery maintenance | Stain-resistant wipe-clean PU surface | |
| Coffee table surface design | Dual-section flat top with integrated central seam | |
| Structural stability | Floor contact points with hidden non-slip pads | |
| Seating arrangement flexibility | Freestanding modular arrangement | |
| Armrest design | Full-width padded armrests integrated with side wood panels | |
| Seating posture support | Fixed non-reclining 105° upright seat-back angle | |
| Floor protection | All floor contact points fitted with 5mm thick non-slip rubber pads | |
| Structural durability | Reinforced corner block joinery at all seat frame joints | |
| Armrest support | Full-width padded armrests integrated with curved wood side panels | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Total shipping units | 4 cartons | |
|---|---|---|
| 3-seat sofa shipping carton dimensions | 2050 x 900 x 650 mm | |
| Single armchair shipping carton dimensions | 970 x 870 x 650 mm | |
| Coffee table shipping carton dimensions | 1250 x 650 x 150 mm | |
| Total gross shipping weight | 180 kg | |
| Total shipping volume | 2.3 CBM | |
| Assembly time requirement | 60 minutes | |
| 40HQ container loading quantity | 42 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive office reception zones | Suitable for visitor waiting areas in private executive offices, formal walnut and black finish matches professional executive furniture schemes | |
|---|---|---|
| Corporate lobby waiting areas | Suitable for high-traffic main office lobbies, durable stain-resistant upholstery withstands regular public use | |
| Meeting room breakout spaces | Suitable for informal discussion zones adjacent to formal meeting rooms, provides comfortable seating for pre-meeting waiting or post-meeting discussion | |
| Corporate boardroom ancillary areas | Suitable for peripheral seating in boardrooms, cohesive formal aesthetic matches high-end boardroom furniture finishes | |
| VIP client reception suites | Suitable for high-grade client meeting spaces, premium wood veneer trim creates an upscale professional impression for visiting clients | |
| Recommended supporting configuration | Pair with the matching steel frame black top coffee table included in the set, can be supplemented with matching side tables for additional beverage or document placement space | |
| Branch office customer waiting areas | Suitable for 20㎡ customer service waiting zones in bank, real estate and professional service branch offices, wipe-clean surfaces reduce facility maintenance workload | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| Office furniture safety recommendation | EN 16139:2013 | |
|---|---|---|
| Formaldehyde emission recommendation | EN 13986:2004+A1:2015 | |
| Non-domestic seating safety recommendation | EN 16139:2013 | |
| Wood-based panel emission recommendation | EN 13986:2004+A1:2015 | |
| Furniture surface resistance recommendation | EN 12720:2009+A1:2013 |
US and Canada office-furniture standards
| Lounge seating performance recommendation | ANSI/BIFMA X2021 | |
|---|---|---|
| Occasional table performance recommendation | ANSI/BIFMA X2021 |
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB/T 3324 | |
|---|---|---|
| Upholstered furniture durability recommendation | GB/T 19001 | |
| Formaldehyde emission recommendation | GB 18584 | |
| Upholstery fire performance recommendation | GB 20286 | |
| Wooden furniture general technical recommendation | GB/T 3324 | |
| Upholstered furniture seating durability recommendation | GB/T 37910.1 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB/T 3324; 2. Upholstered furniture durability recommendation: GB/T 19001; 3. Formaldehyde emission recommendation: GB 18584; 4. Upholstery fire performance recommendation: GB 20286; 5. Wooden furniture general technical recommendation: GB/T 3324; 6. Upholstered furniture seating durability recommendation: GB/T 37910.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
