Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seater sofa dimensions | 2100 x 920 x 860 mm | |
|---|---|---|
| Single armchair dimensions | 1050 x 900 x 820 mm | |
| Coffee table dimensions | 1300 x 700 x 420 mm | |
| Seat height from floor | 420 mm | |
| Seat depth for sofa and armchairs | 580 mm | |
| Backrest height from seat surface | 440 mm | |
| Armrest height from seat surface | 180 mm | |
| Armrest width | 160 mm | |
| Coffee table glass top thickness | 12 mm | |
| Leg/base height for sofas and armchairs | 20 mm | |
| Overall 2-seater sofa dimensions | 2100 x 920 x 860 mm | |
| Per-seat width on 2-seater sofa | 900 mm | |
| Coffee table leg spread width | 1000 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set net weight range | 195 kg | |
|---|---|---|
| 3-seater sofa static load capacity | 450 kg | |
| Recommended seating capacity for full set | 5 people | |
| Seat foam indentation load deflection | 40 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Seat cushion foam thickness | 120 mm | |
| Backrest foam thickness | 80 mm | |
| Seat foam indentation load deflection density | 40 kg/m³ | |
| Tempered glass coffee table top impact resistance | 100 kg | |
| Seam stitch tensile strength | 100 N |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Full-grain look dark brown smooth leather, 1.4mm thickness | |
|---|---|---|
| Padded armrest upholstery | Matching dark brown leather with rounded edge stitching | |
| Internal seating frame | Kiln-dried solid hardwood frame with 30mm x 50mm structural battens, reinforced corner blocks | |
| Seat support platform | 8mm thick serpentine steel springs with 50mm spacing, covered by 20mm thick polyester fiber pad | |
| Sofa base trim and hidden feet | Matte dark brown polymer bottom trim with small anti-slip plastic glides | |
| Coffee table tabletop | 12mm thick black tempered glass with polished straight edges | |
| Coffee table support frame | 1.5mm thick powder-coated black steel T-base with cross support bar, polished chrome accent tips on feet | |
| Internal padding under upholstery | 200g/m² polyester wadding layer between foam and leather to reduce upholstery wrinkling | |
| Coffee table foot pads | 5mm thick rubber anti-slip pads attached to frame leg bottoms | |
| Upholstery adhesive | Low-VOC water-based upholstery adhesive | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular layout with central 3-seater sofa, two symmetrically placed armchairs, and matching coffee table | |
|---|---|---|
| Cushion design | Fixed non-removable seat and back cushions integrated into the sofa frame | |
| Backrest support | Ergonomic gently curved single-piece back per seat position with integrated lumbar contour | |
| Armrest design | Fully padded wide curved armrests with soft rounded edges, continuous with the sofa side panel | |
| Floor protection | Hidden low-profile plastic glides on all seating unit bases to prevent hard floor scratching | |
| Coffee table function | Stable flat tempered glass top for placing drinks, books and decorative items, low-profile T-base to maximize legroom under the table | |
| Upholstery maintenance | Smooth non-porous leather surface for wipe-clean maintenance with standard leather care products | |
| Weight distribution | Wide low-profile base on all seating units prevents tipping during normal seated movement, 200mm base overhang on all sides for stability | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 5 cartons | |
|---|---|---|
| Reference carton dimensions for 3-seater sofa | 2200 x 980 x 650 mm | |
| Reference carton dimensions per single armchair | 1120 x 960 x 620 mm | |
| Reference carton dimensions for coffee table components | 1380 x 780 x 120 mm (glass top); 1250 x 600 x 150 mm (metal frame) | |
| Total reference gross shipping weight | 240 kg | |
| Total shipping volume (CBM) | 3.1 CBM | |
| On-site assembly time | 40 minutes | |
| 40ft HQ container loading quantity | 42 sets | |
| Reference carton dimensions for 2-seater sofa | 2200 x 980 x 650 mm | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Formal residential living room | Suitable for medium to large living rooms as primary conversational seating, symmetric layout creates a balanced, sophisticated visual for guest reception and daily relaxation | |
|---|---|---|
| Executive office reception lounge | Suitable for corporate executive waiting areas or VIP reception rooms, dark brown leather finish conveys a professional, upscale impression for client meetings | |
| High-end hotel suite living area | Suitable for luxury hotel presidential or executive suite seating areas, matching premium interior finishes and requiring low long-term maintenance | |
| Private study lounge area | Suitable for placement adjacent to a home office desk or study bookshelf as a secondary seating spot for reading or brief breaks | |
| Recommended supporting layout | Place the central 3-seater sofa against a feature wall, position the two armchairs symmetrically across the coffee table with 450mm clearance between seats and table edge for easy movement | |
| Luxury residential open-plan lounge | Suitable for open-concept living spaces connected to dining areas, low back height does not block sightlines across the open space |
EU Market Access Requirements* EN Standards
| EN 12520:2015 Furniture - Strength, durability and safety - Requirements for domestic seating | Applicable for static load, durability and safety testing for all seating units in the set, for EU market compliance | |
|---|---|---|
| EN 1022:2018 Domestic furniture - Seating - Determination of stability | Applicable for front, side and rear stability testing of armchairs and sofa to prevent tipping during normal use | |
| EN 12150-1:2015 Glass in building - Thermally toughened soda lime silicate safety glass | Applicable for the tempered glass coffee table top, requiring impact resistance and fragmentation safety properties | |
| EN 13722:2004 Furniture - Strength and durability of tables for domestic use | Applicable for coffee table static load, leg strength and surface durability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for solid wood internal frame structural safety, dimensional stability and formaldehyde emission limits for residential wooden furniture | |
|---|---|---|
| GB 28007-2011 General technical requirements for children's furniture (if used in family spaces) | Applicable for edge rounding and structural safety requirements if the set is placed in spaces accessible to children | |
| GB/T 16799-2008 Furniture leather | Applicable for leather upholstery tear strength, color fastness to rubbing and harmful substance limits | |
| GB/T 3323-2017 General technical requirements for metal furniture | Applicable for coffee table steel frame structural strength, coating adhesion and corrosion resistance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for solid wood internal frame structural safety, dimensional stability and formaldehyde emission limits for residential wooden furniture; 2. GB 28007-2011 General technical requirements for children's furniture (if used in family spaces): Applicable for edge rounding and structural safety requirements if the set is placed in spaces accessible to children; 3. GB/T 16799-2008 Furniture leather: Applicable for leather upholstery tear strength, color fastness to rubbing and harmful substance limits; 4. GB/T 3323-2017 General technical requirements for metal furniture: Applicable for coffee table steel frame structural strength, coating adhesion and corrosion resistance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
