Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 880 × 850 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat depth per seating position | 550 mm | |
| Seat back height above seat | 400 mm | |
| Armrest width per side | 120 mm | |
| Armrest height above seat | 180 mm | |
| Base frame leg height | 120 mm | |
| Coffee table open shelf clearance height | 200 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single seating position static load capacity | 150 kg | |
|---|---|---|
| 3-seater sofa net weight | 65 kg | |
| Seating foam density | 45 kg/m³ | |
| Seat cushion foam thickness | 80 mm | |
| Backrest foam thickness | 50 mm | |
| Seam stitch durability | 50000 double rub cycles | |
| Chrome base corrosion resistance rating | 200 hours salt spray resistance | |
| Total seating capacity across full set | 5 seats | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | 1.2mm thick black polyurethane (PU) faux leather | |
|---|---|---|
| Internal seat frame | 18mm thick multi-layer engineered hardwood plywood | |
| Cushion core | High-density polyurethane foam with polyester fiber wrap | |
| Base support frame | 1.2mm thick polished chrome-plated cold-rolled steel | |
| Padded armrests | Same black PU upholstery over 40mm thick foam padding | |
| Coffee table top | Matte dark gray wood veneer over 25mm thick MDF core | |
| Coffee table lower shelf | 15mm thick matte gray MDF panel | |
| Frame connection hardware | Zinc-plated steel bolts and corner brackets | |
| Cushion support base | 4mm thick sinuous steel spring webbing spaced 80mm apart | |
| Coffee table side supports | 25mm thick matte dark gray MDF panel with matching wood veneer finish | |
| Upholstery seam construction | 10mm stitch pitch with bonded polyester thread, reinforced at stress corners | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | Fixed 3+1+1 modular layout with matching center coffee table | |
|---|---|---|
| Seat base design | Non-reclining fixed upholstered seat with no tilt or adjustment mechanisms | |
| Floor contact design | Integrated chrome sled base with adjustable plastic glides | |
| Coffee table storage | Open front lower shelf for magazine and document storage | |
| Edge protection | Rounded upholstered edges on all armrests and seat fronts | |
| Knockdown assembly | Flat-pack delivery with bolt-together assembly for all seating units and coffee table | |
| Upholstery maintenance | Water and stain-resistant PU surface that wipes clean with mild detergent | |
| Seat suspension | Sinuous spring base with foam core, no sagging under 10000 cyclic load applications of 100kg | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate executive reception areas | Fits formal waiting spaces outside executive offices, conveying a professional, understated appearance for visiting clients and partners | |
|---|---|---|
| Office waiting rooms and visitor lobbies | Provides seating for 5 total visitors, arranged around a central coffee table for document placement and refreshments | |
| Meeting room breakout spaces | Suitable for informal pre-meeting gathering or post-meeting discussion, with easy-clean upholstery for high-frequency use | |
| Public service office waiting areas | Suitable for government, bank or professional service customer waiting zones, with hard-wearing construction and stable fixed seating | |
| Small business consulting rooms | Fits compact client meeting spaces for 5-person conversations without requiring separate lounge furniture pieces | |
| High-rise office sky lobbies | Suitable for window-facing waiting areas with city views, matching modern minimalist interior design palettes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 16139:2013 applicability | Relevant European standard for non-domestic seating, covering strength, durability and stability for contract office use | |
|---|---|---|
| EN 15372:2016 applicability | Relevant European standard for non-domestic tables, covering strength, durability and stability for office contract furniture | |
| EN 1022:2018 applicability | Relevant European standard for furniture seating stability determination |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 applicability | Relevant North American standard for lounge and public seating, covering static load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 applicability | Relevant North American standard for desk products, applicable to the reception coffee table performance requirements |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 18584-2001 applicability | Relevant limit standard for formaldehyde and heavy metal emissions from wooden furniture components | |
|---|---|---|
| GB/T 3324-2017 applicability | Relevant general technical standard for wooden furniture, applicable to the coffee table and internal sofa wood frame components | |
| GB 20210-2006 applicability | Relevant standard for upholstered furniture fire safety for public and commercial spaces |
This product must meet the following technical requirements: 1. GB 18584-2001 applicability: Relevant limit standard for formaldehyde and heavy metal emissions from wooden furniture components; 2. GB/T 3324-2017 applicability: Relevant general technical standard for wooden furniture, applicable to the coffee table and internal sofa wood frame components; 3. GB 20210-2006 applicability: Relevant standard for upholstered furniture fire safety for public and commercial spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
