Automatic mm / inch conversion · Core engineering specifications
| 3-seat sofa overall dimensions | 2100 x 880 x 820 mm | |
|---|---|---|
| Single armchair overall dimensions | 900 x 850 x 820 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Side end table overall dimensions | 600 x 600 x 550 mm | |
| 3-seat sofa seat height | 420 mm | |
| 3-seat sofa seat depth | 580 mm | |
| 3-seat sofa armrest height from floor | 620 mm | |
| Coffee table leg diameter | 50 mm | |
| Sofa seat cushion thickness | 120 mm | |
| Sofa backrest thickness | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| 3-seat sofa static load capacity per seat | 150 kg | |
|---|---|---|
| Seating set total net weight | 95 kg | |
| Seating capacity | 4 people | |
| Total seating capacity | 4 people | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Table top surface impact resistance | 10 J | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa & armchair outer upholstery | Black matte faux leather (PU) | |
|---|---|---|
| Sofa & armchair internal frame | Solid kiln-dried hardwood frame with reinforced corner blocking | |
| Seat core padding | 40kg/m³ high-density polyurethane foam | |
| Backrest padding | 30kg/m³ polyurethane foam with Dacron wrap | |
| Sofa feet | Dark mahogany-look injection molded plastic feet | |
| Table tops | Light oak-look high-pressure laminate (HPL) on 25mm thick particleboard core | |
| Table legs and frame | Chrome-plated 1.2mm thick steel square tube legs with cross-brace supports | |
| Seam construction | Double-stitched reinforced seams with 8mm stitch pitch | |
| Table foot glides | Non-marking black plastic floor glides | |
| Sofa support system | 70mm wide elastic webbing spaced 100mm apart under seat foam | |
| Floor protection components | Non-marking 5mm thick black plastic floor glides | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed non-reclining upright seating position | |
|---|---|---|
| Armrest design | Full-wrap integrated wide armrests padded with matching upholstery | |
| Table stability bracing | Perimeter steel apron under table tops with horizontal cross braces between legs | |
| Floor protection | Integrated foot glides on all sofa feet and table legs | |
| Surface maintenance | Stain-resistant faux leather upholstery and wipe-clean laminate table tops | |
| Modular arrangement flexibility | Independent sofa, armchair, coffee table and side table units | |
| Seating positioning | Fixed non-reclining 105° upright back angle | |
| Armrest construction | Full-wrap integrated wide armrests padded with matching upholstery | |
| Table stability system | Perimeter steel apron under table tops with horizontal cross braces between opposite legs | |
| Floor protection function | Integrated foot glides on all sofa feet and table legs | |
| Surface maintenance design | Stain-resistant non-porous faux leather upholstery and wipe-clean laminate table tops | |
| Layout flexibility | Independent sofa, armchair, coffee table and side table units |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 4 cartons | |
|---|---|---|
| 3-seat sofa carton dimensions | 2150 x 920 x 600 mm | |
| Armchair carton dimensions | 950 x 890 x 600 mm | |
| Coffee table carton dimensions | 1250 x 650 x 150 mm | |
| Side table carton dimensions | 650 x 650 x 150 mm | |
| Total shipment gross weight | 115 kg | |
| Total shipment volume | 1.65 CBM | |
| On-site assembly time | 30 minutes | |
| 40ft HQ container loading quantity | 72 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception areas | Suitable for formal guest waiting zones in office lobbies, executive floor reception spaces and visitor entry areas | |
|---|---|---|
| Small meeting and breakout spaces | Appropriate for informal small group discussions, short break areas and internal team waiting zones | |
| Government and institutional waiting rooms | Durable construction and neutral professional appearance suits public sector service counters, administrative office waiting areas and official meeting spaces | |
| Hotel and serviced office business lounges | Modular configuration works for premium business centers, hotel executive lounges and co-working visitor areas | |
| Medical and professional office waiting areas | Easy-to-clean upholstery and sturdy construction is suitable for clinic waiting rooms, legal office reception areas and financial service client lounges | |
| Corporate office reception lobbies | Suitable for formal guest waiting zones in main office lobbies, executive floor reception spaces and visitor entry areas | |
| Professional service office waiting areas | Easy-to-clean upholstery and sturdy construction is suitable for legal office reception areas, financial service client lounges and clinic waiting rooms | |
| Employee entrance waiting zones | Suitable for visitor check-in waiting areas near employee entrances and security checkpoints |
EU Market Access Requirements* EN Standards
| Applicable office furniture seating strength standard | EN 16139:2013 | |
|---|---|---|
| Applicable table strength and durability standard | EN 15372:2016 | |
| Non-domestic seating strength standard | EN 16139:2013 | |
| Non-domestic table strength standard | EN 15372:2016 | |
| Upholstered furniture flame retardant standard | EN 1021:2014 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Applicable upholstered furniture flammability standard | GB 20286 | |
|---|---|---|
| Applicable furniture mechanical safety standard | GB/T 3324 | |
| Applicable furniture surface durability standard | GB/T 4893.8 | |
| Upholstered furniture flammability requirement | GB 20286 | |
| Wooden furniture structural requirement | GB/T 3324 | |
| Furniture surface durability requirement | GB/T 4893.8 |
This product must meet the following technical requirements: 1. Applicable upholstered furniture flammability standard: GB 20286; 2. Applicable furniture mechanical safety standard: GB/T 3324; 3. Applicable furniture surface durability standard: GB/T 4893.8; 4. Upholstered furniture flammability requirement: GB 20286; 5. Wooden furniture structural requirement: GB/T 3324; 6. Furniture surface durability requirement: GB/T 4893.8; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
