Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 720 x 720 x 1420 mm | |
|---|---|---|
| Seat height adjustment range | 540 mm | |
| Seat cushion dimensions | 500 x 500 x 60 mm | |
| Backrest width | 490 mm | |
| Five-star base diameter | 700 mm | |
| Headrest dimensions | 320 x 180 mm | |
| Footrest extension length | 460 mm | |
| Armrest height above seat | 280 mm | |
| Seat depth | 500 mm | |
| Caster diameter | 65 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Maximum recommended user weight | 250 kg | |
|---|---|---|
| Chair net weight | 25 kg | |
| Recommended user height range | 1830 mm | |
| Seat foam density | 50 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Gas lift cycle rating | 120000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest upholstery | Tight-woven breathable polyester mesh | |
|---|---|---|
| Seat cushion core | High-density molded polyurethane foam | |
| Seat upholstery | Breathable mesh over foam pad | |
| Structural frame | Nylon reinforced with 30% glass fiber | |
| Armrest pads | Soft polyurethane (PU) padded surfaces | |
| Armrest support posts | Injection-molded nylon with height adjustment locks | |
| Five-star base | 2.0mm thick powder-coated steel | |
| Retractable footrest | 1.5mm thick steel tube with PP foot pad | |
| Gas lift cylinder | SGS/Class 3 certified steel gas lift | |
| Casters | 65mm diameter nylon twin-wheel mute casters | |
| Seat mechanism chassis | 3.0mm thick steel synchro-tilt plate | |
| Headrest frame | Injection-molded PP with mesh cover |
Adjustment / rotation / tilt / mobility / storage features
| Swivel function | 360-degree full rotation around central gas lift | |
|---|---|---|
| Seat height adjustment | 100mm vertical travel via pneumatic gas lift | |
| Recline function | 140-degree maximum backrest recline with 4 locking positions | |
| Armrest adjustment | 4D adjustment: 80mm height, 50mm front/back slide, 30mm width, 30° rotation | |
| Headrest adjustment | 100mm height travel, 20° angle rotation, 50mm depth slide | |
| Lumbar support adjustment | 50mm height travel, 40mm depth adjustment | |
| Footrest operation | Retractable pull-out design, locks in extended position for reclined rest | |
| Tilt tension control | Adjustable knob modulates recline resistance to match user weight | |
| Seat depth adjustment | 50mm front/back seat slide to support different thigh lengths | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Corporate open office workstations | Suitable for 8-hour daily desk work with adjustable ergonomic support | |
|---|---|---|
| Home office spaces | Fits standard height home desks with compact footprint and recline function | |
| Manager private offices | Professional black finish matches executive office furniture sets | |
| Co-working flexible seating | Adjustable features accommodate varied user heights and preferences | |
| Short-break rest use | Retractable footrest and 140° recline support short rest periods during workdays | |
| User height compatibility | Supports adult users between 160cm and 183cm for proper ergonomic fit | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office chair safety requirement | EN 1335:2020 | |
|---|---|---|
| Office chair structural strength | EN 1728:2014 | |
| Furniture flammability | EN 1021:2014 |
US and Canada office-furniture standards
| General purpose office chairs | ANSI/BIFMA X2017 | |
|---|---|---|
| Office chair casters | ANSI/BIFMA X2017Clause 13 | |
| Gas lift safety | ANSI/BIFMA X2017Clause 8 | |
| Caster rolling durability | 100000 cycles | |
| Static load rating for five-star base | 1136 kg |
Standards applicable to China-market projects
| Office chair safety requirement | GB/T 38733 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 | |
| Furniture mechanical stability | GB/T 10357.2 |
This product must meet the following technical requirements: 1. Office chair safety requirement: GB/T 38733; 2. Formaldehyde emission limit: GB 18584; 3. Furniture mechanical stability: GB/T 10357.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
