Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 690 x 680 x 1372 mm | |
|---|---|---|
| Seat width | 500 mm | |
| Seat depth | 500 mm | |
| Adjustable seat height | 619 mm | |
| Five-star base diameter | 640 mm | |
| Caster diameter | 60 mm | |
| Backrest height | 440 mm | |
| Extended depth with footrest out | 1321 mm | |
| Headrest height adjustment travel | 60 mm | |
| Armrest height above seat | 240 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static user weight capacity | 204 kg | |
|---|---|---|
| Net product weight | 21 kg | |
| Seat cushion foam density | 45 kg/m³ | |
| Seat cushion foam thickness | 80 mm | |
| Backrest foam rebound rate | 60% | |
| Caster rolling durability rating | 100000 cycles | |
| Gas lift static load rating | 150 kg | |
| Mesh fabric abrasion resistance | 50000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headrest upholstery | Breathable woven grey mesh over foam padding | |
|---|---|---|
| Split backrest panels | Tensioned breathable grey mesh over contoured PP support frames | |
| Seat cushion | Grey mesh top layer over high-density molded foam core | |
| Retractable footrest pad | Textured woven grey mesh over curved PP support | |
| Armrest structure | Light grey reinforced PP frame with soft PU padded top surfaces | |
| Central support frame | Powder-coated steel internal frame with light grey PP exterior covers | |
| Five-star base | Reinforced light grey nylon construction with ribbed structural supports | |
| Caster wheels | Dual-wheel PU soft tread with black PP hub and silver accent ring | |
| Gas lift cylinder | Chrome-plated steel Class 4 gas lift with black PP trim ring | |
| Recline mechanism chassis | 3 mm thick stamped steel plate with black powder coat finish | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | 110 mm vertical seat height travel via Class 4 gas lift, activated by right-side paddle | |
|---|---|---|
| Backrest recline | Lockable recline up to 135° from upright position, with adjustable tilt tension | |
| Headrest adjustment | 60 mm vertical height adjustment plus 40° pivot angle adjustment for neck support | |
| Split lumbar support | Independent dual back panels that flex to conform to spinal curvature | |
| Retractable footrest | Pull-out mesh-padded footrest that tucks fully under seat when not in use | |
| Swivel function | 360° unrestricted swivel rotation around central gas lift axis | |
| Mobility function | Smooth rolling on 5 dual-wheel casters suitable for hard floors and low-pile carpet | |
| Tilt tension control | Manual tension knob under seat adjusts recline resistance to match user weight | |
| Reclined maximum overall height | 1190 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Home office workspace | Provides lumbar support and recline function for long hours of computer work | |
|---|---|---|
| Commercial open-plan office | Durable construction and 360° mobility support shared workstation use | |
| Executive private office | Premium split-back ergonomic design and light grey finish match professional interiors | |
| Conference room breakout area | Rolling base and swivel function support flexible meeting collaboration | |
| Study room for student use | Adjustable height accommodates users from teen to adult height ranges | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office work chair dimensional and safety requirement verification | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair structural strength, durability and stability testing | |
| EN 1021-1:2014 | Applies to upholstered furniture ignition resistance from smouldering cigarettes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair structural performance and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk, chair and stool furniture dimension testing for office use | |
|---|---|---|
| GB/T 10357.3-2013 | Applies to chair strength and durability mechanical performance testing | |
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based furniture components |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk, chair and stool furniture dimension testing for office use; 2. GB/T 10357.3-2013: Applies to chair strength and durability mechanical performance testing; 3. GB 18584-2001: Applies to formaldehyde emission limits for wood-based furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
