PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	660 × 660 × 1230 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	136 kg
Net weight (reference)	18 kg
Backrest static load rating	68 kg
Caster rolling durability cycles	100000
Gas lift cycle rating	120000
Seat foam density	45 kg/m³
Mesh fabric abrasion resistance	50000 Martindale cycles
Standard warranty period	3 years
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support frame	Injection-molded black nylon
Backrest tension surface	Breathable woven elastic mesh
Seat support inner frame	12mm thick molded plywood
Seat cushion padding	High-resilience polyurethane foam
Seat upholstery	Wear-resistant black woven fabric
Headrest padding	Molded polyurethane foam with fabric wrap
Armrest structure	Fixed-height black nylon with PU padded top
Five-star base	Reinforced injection-molded black nylon
Gas lift cylinder	Class 3 carbon steel with black powder coat
Height adjustment mechanism	2.5mm thick steel tilt chassis
Casters	50mm diameter black PU swivel casters
Lumbar support slats	Reinforced nylon adjustable inserts

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	100mm vertical travel via pneumatic gas lift, actuated by side lever
Backrest tilt function	Synchro-tilt with 12-degree maximum recline, single position lock
Headrest adjustment	Vertical height and 30-degree pivot angle adjustment for neck support
Lumbar support	Segmented flex slats that conform to spine curvature during recline
Armrest design	Fixed-height curved armrests with 205mm clearance above seat
Mobility	360-degree swivel rotation and free rolling on 5 dual casters
Tilt tension control	Rotary knob under seat to adjust recline resistance for user weight
Seat waterfall edge	Contoured front seat edge to reduce leg pressure during long sitting
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Private office workspace	Suitable for 8-hour daily executive or staff desk use, ergonomic support for long sitting periods
Open plan office workstation	Fits standard 1200mm wide workstations, rolling base allows easy movement between tasks
Home office setup	Black neutral finish matches residential and commercial decor, suitable for remote work use
Conference room seating	Adjustable height accommodates standard conference table heights 760 mm
Hot-desking shared workspaces	Durable commercial construction withstands frequent user adjustment and rotation
Training room environments	Wheeled base allows easy reconfiguration, breathable mesh maintains comfort during long sessions
Recommended desk height pairing	760 mm standard office desk height, matches seat height adjustment range
User height range	185 cm, headrest and seat adjustment accommodate most adult user heights

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Applicable standard EN 1335-1:2000	Office furniture: Office work chairs, dimensional safety and strength requirements
Applicable standard EN 1335-2:2009	Office work chairs: Safety requirements, for structural performance verification
Applicable standard EN 1335-3:2009	Office work chairs: Test methods, for standardized stability and durability testing

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Applicable standard ANSI/BIFMA X5.1-2017	Office Chairs: General purpose, standard for strength, durability and stability testing
Seat dynamic load rating	102 kg

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Applicable standard GB/T 3326-2016	Office furniture: General technical requirements for desks and chairs, for dimensional and structural acceptance
Applicable standard GB/T 10357.2-2013	Furniture mechanical test: Chair and stool stability, for static stability verification
Applicable standard GB/T 10357.3-2013	Furniture mechanical test: Chair and stool strength and durability, for load cycle verification
Applicable standard GB 18584-2001	Indoor decorating and refurbishing materials: Limit of harmful substances in wooden furniture, for formaldehyde emission acceptance

Standardized tender description text

This product must meet the following technical requirements:
1. Applicable standard GB/T 3326-2016: Office furniture: General technical requirements for desks and chairs, for dimensional and structural acceptance;
2. Applicable standard GB/T 10357.2-2013: Furniture mechanical test: Chair and stool stability, for static stability verification;
3. Applicable standard GB/T 10357.3-2013: Furniture mechanical test: Chair and stool strength and durability, for load cycle verification;
4. Applicable standard GB 18584-2001: Indoor decorating and refurbishing materials: Limit of harmful substances in wooden furniture, for formaldehyde emission acceptance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFC-MESH-ERG-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFC-MESH-ERG-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFC-MESH-ERG-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Ergonomic High-Back Mesh Office Chair with Adjustable Headrest (model OFC-MESH-ERG-001) is an unbranded office task chair designed for balanced support and versatile use across work environments. Visually, it features a streamlined, professional profile with a consistent matte black finish across its frame, base, and fabric components, structured to pair unobtrusively with both commercial and residential interior palettes. Its layout prioritizes ergonomic alignment, with a tall contoured backrest, centrally positioned lumbar support zone, padded fixed armrests, and an adjustable headrest positioned to cradle the neck during seated work. Built for regular commercial and personal use, the chair combines durable, purpose-selected materials: a breathable woven elastic mesh tension surface for the backrest, supported by an injection-molded black nylon frame; a 90mm thick seat cushion made of high-resilience polyurethane foam wrapped in wear-resistant black woven fabric, set on a 12mm thick molded plywood inner frame; a reinforced injection-molded black nylon five-star base fitted with PU dual casters; and a Class 3 black powder-coated carbon steel gas lift. The headrest uses molded polyurethane foam with a matching fabric wrap, while armrests are constructed from fixed-height black nylon with soft PU padded tops for forearm comfort. Core functional features are tailored for long-duration sitting: 100mm of vertical seat height adjustment controlled via a side-mounted pneumatic lever, a synchro-tilt backrest with 12-degree maximum recline and single-position lock, a rotary under-seat knob to adjust tilt tension to match user weight, 360-degree swivel rotation, and free-rolling casters for easy movement. The segmented flex slat lumbar support conforms to natural spine curvature during recline, while the headrest offers both vertical height adjustment and 30-degree pivot adjustment to customize neck support. The mesh back promotes air circulation to reduce heat buildup during extended use. This chair is suitable for a wide range of spaces: private offices, where it supports 8 hours of daily executive or staff desk work; open-plan workstations, as it fits standard desk footprints and allows easy movement between tasks; home offices, where its neutral black finish complements residential decor for remote work; conference rooms, where its adjustable height aligns with standard table heights; shared hot-desking spaces, thanks to its durable commercial-grade construction that tolerates frequent adjustment and user rotation; and training rooms, where the wheeled base enables quick space reconfiguration and breathable mesh maintains comfort during long sessions. For procurement, note that each unit ships in two cartons, with a reference assembly time of 40 minutes per set. It supports a maximum recommended user weight of 136 kg, with durable component ratings suited for high-traffic commercial use, and fits standard 20-foot container loading for bulk orders at documented space utilization rates.

Ergonomic High-Back Mesh Office Chair with Adjustable Headrest Specifications
