PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	660 × 680 × 1290 mm
Seat width	500 mm
Seat depth	460 mm
Seat height adjustment range	530 mm
Backrest height from seat surface	580 mm
Armrest height above seat	180 mm
Armrest height above floor	710 mm
Headrest forward protrusion	60 mm
Five-star base diameter	700 mm
Caster diameter	60 mm
Seat cushion thickness	50 mm
Backrest frame width	505 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Assembled net weight	17 kg
Recommended static user load capacity	150 kg
Gas lift durability rating	120000 lift cycles
Caster rolling durability	40000 rolling cycles
Seat foam density	45 kg/m³
Back mesh abrasion resistance	50000 Martindale cycles
Tilt mechanism locking positions	3 positions
Maximum recline angle	135 degrees
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest upholstery	Breathable polyester office mesh
Seat cushion core	High-density cold-cured molded foam
Seat surface upholstery	Wear-resistant polyester fabric
Structural back frame	Glass-fiber reinforced nylon
Height adjustment gas lift	Chrome-plated steel Class 3 pneumatic cylinder
Tilt mechanism plate	2.5 mm thick stamped steel
Armrest pads	Soft-touch polyurethane padding
Five-star base	Reinforced black nylon
Casters	Dual-wheel non-marking polyurethane
Internal seat support frame	1.5 mm thick steel tubing
Seam stitch pitch	8 mm
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	100 mm stroke pneumatic adjustment via under-seat lever
Backrest tilt function	135degree recline with tension adjustment knob
Swivel function	360-degree full rotation on central gas lift bearing
Headrest adjustment	60 mm height adjustment plus angle tilt
Armrest adjustment	100 mm height adjustment with 4-direction position locking
Lumbar support	Contoured built-in S-curve lumbar support zone
Mobility function	Dual-wheel casters for smooth rolling on hard floors and low-pile carpet
Tilt lock function	3-position lockable recline for upright work or relaxed leaning
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Shipping volume per unit	0.15 CBM
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office workstation use	Suitable for daily 8-hour desk work in open-plan or private office settings
Home office use	Ideal for remote work setups in home studies or dedicated work spaces
Conference room use	Appropriate for meeting room seating with swivel and recline for collaborative work
Recommended user height range	Fits users 185 cm tall
Desk compatibility	Works with standard 760 mm height office desks
Flooring compatibility	Non-marking casters safe for hardwood, tile, laminate and low-pile carpet
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office furniture office chair safety standard	EN 1335:2020
Office chair stability standard	EN 1335:2018
Office chair surface flammability standard	EN 1021:2014

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Office chair general purpose standard	ANSI/BIFMA X2017

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Office chair structural safety standard	GB/T 10357.2
Office chair durability standard	GB/T 10357.3
Upholstered furniture formaldehyde limit	GB 18584

Standardized tender description text

This product must meet the following technical requirements:
1. Office chair structural safety standard: GB/T 10357.2;
2. Office chair durability standard: GB/T 10357.3;
3. Upholstered furniture formaldehyde limit: GB 18584;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · ERG-MESH-6668-HB

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · ERG-MESH-6668-HB

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · ERG-MESH-6668-HBOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The High-Back Adjustable Mesh Ergonomic Office Chair (Model ERG-MESH-6668-HB, unbranded) delivers structured, supportive seating built for extended daily use. Its streamlined, professional silhouette features a tall contoured mesh back anchored to a reinforced black nylon five-star base, with soft-touch padded armrests and an integrated adjustable headrest that balances visual lightness with robust structural presence. The overall form measures 660 x 680 x 1290 mm, with a 500 mm wide, 460 mm deep seat and a 580 mm tall backrest measured from the seat surface, creating a proportional layout that fits neatly alongside standard work surfaces without overwhelming surrounding space. Construction prioritizes durability and long-haul comfort: the backrest uses breathable polyester office mesh rated for 50000 Martindale abrasion cycles, stretched over a glass-fiber reinforced nylon frame with a built-in S-curve lumbar support zone. The seat pairs a 45 kg/m³ high-density cold-cured molded foam core with wear-resistant polyester fabric upholstery, mounted to a 2.5 mm thick stamped steel tilt mechanism plate. Height adjustment relies on a chrome-plated Class 3 steel gas lift rated for 120000 lift cycles, connected to dual-wheel non-marking polyurethane casters tested for 40000 rolling cycles. Functional design supports flexible working postures: a 100 mm stroke seat height adjustment operates via an under-seat lever, while the backrest offers 135-degree recline with adjustable tension and 3 lockable positions. The seat swivels 360 degrees on the central bearing, the headrest adjusts 60 mm in height with variable tilt, and armrests move 100 mm vertically with 4-direction position locking. The casters roll smoothly across hard flooring and low-pile carpet without leaving surface marks. This chair is suited for 8-hour daily use in open-plan office workstations, private offices, home study remote work setups, and collaborative conference rooms, accommodating users up to 185 cm tall and pairing seamlessly with standard 760 mm height office desks. For procurement, note each unit ships in 2 cartons with a packaged gross weight of 23 kg and total carton volume of 0.26 m³, requires 40 minutes of assembly per set, and supports a maximum static user load of 150 kg, making it a reliable choice for high-traffic work environments.

High-Back Adjustable Mesh Ergonomic Office Chair Specifications
