Name: High-Back Ergonomic Mesh Office Chair with Adjustable Headrest
Brand: YUXIANG
SKU: HCMPZF

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	620 × 680 × 1300 mm
Seat cushion width	480 mm
Seat cushion depth	460 mm
Seat cushion thickness	80 mm
Seat height adjustment range (floor to seat top)	540 mm
Backrest total height (seat surface to headrest top)	690 mm
Headrest width	470 mm
Armrest height above seat surface	180 mm
Five-star base total span	680 mm
Minimum overall chair height (lowest seat/headrest position)	1120 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended maximum user weight	150 kg
Static load rating for five-star base	1000 kg
Product net weight	14.2 kg
Caster rolling noise level	40 dB
Seat foam density	60 kg/m³
Seat foam rebound rate	60%
Mesh upholstery abrasion resistance	100000 double rubs
Frame fatigue cycle rating	100000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest construction	Breathable polyester tension mesh over glass-fiber reinforced PP frame
Headrest construction	Mesh-covered PP pad with height adjustment bracket
Seat cushion core	High-density molded polyurethane foam with fabric upholstery cover
Seat front edge	Contoured waterfall edge design
Armrests	Integrated fixed loop PP armrests connected to back frame
Five-star base	Injection-molded nylon/PP five-star caster base
Casters	60 mm diameter nylon dual-wheel swivel casters
Height adjustment mechanism	Pneumatic Class 3 gas lift with steel cylinder
Tilt mechanism	2.5mm thick steel butterfly tilt-lock chassis under seat
Internal seat support board	12 mm thick molded plywood seat pan
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

360-degree swivel rotation	Full swivel enabled by central gas lift and caster base
Seat height adjustment	100 mm vertical travel via under-seat pneumatic lever
Backrest recline function	3-position lockable recline up to 125 degrees with tension adjustment
Headrest adjustment	Height-adjustable headrest to support neck positioning
Mobility function	Smooth rolling on all hard floor and low-pile carpet surfaces via dual-wheel casters
Lumbar support	Contoured integrated lumbar zone built into mesh backrest
Weight-activated tilt tension	Automatic tension adjustment to match user weight for balanced recline
Stable stationary use	Non-tilting locked upright position for focused task work
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office workstations	Ergonomic support for 8+ hour daily seated desk work for office staff
Home office study spaces	Compact footprint fits standard home desk setups for remote workers
Conference and meeting rooms	Professional appearance and swivel function support collaborative meeting use
Computer and IT work areas	Breathable mesh back reduces heat buildup during extended screen use
Reception and administrative areas	Durable construction and mobility suit high-traffic front-desk usage
Training room installations	Stackable-free mobile design supports flexible training space reconfiguration
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-1:2020	Office furniture - Office work chairs, dimensional safety and performance requirements
EN 1335-2:2018	Office work chairs, safety requirements for structural stability and load testing
EN 1335-3:2009	Office work chairs, test methods for durability and mechanical performance validation

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	Office chairs, general purpose, strength, durability and structural stability standard
ANSI/BIFMA X5.11-2015	Office chairs for large occupants, extended load capacity test requirements

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3326-2016	Office furniture: desks and chairs, dimension specification applicability for size verification
GB/T 35607-2017	Office furniture: seating, mechanical safety requirements for structural strength validation
GB 18584-2001	Interior decoration materials: furniture, formaldehyde emission limit for material compliance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3326-2016: Office furniture: desks and chairs, dimension specification applicability for size verification;
2. GB/T 35607-2017: Office furniture: seating, mechanical safety requirements for structural strength validation;
3. GB 18584-2001: Interior decoration materials: furniture, formaldehyde emission limit for material compliance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EOCH-MSH620-FXARM

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EOCH-MSH620-FXARM

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EOCH-MSH620-FXARMOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The YUXIANG EOCH-MSH620-FXARM high-back ergonomic mesh office chair balances professional visual appeal with purpose-built functional design for extended seated use. Its structured layout features a tall, contoured mesh backrest paired with a wide, padded seat, fixed integrated loop armrests aligned to the back frame, and a supportive height-adjustable headrest, all mounted atop a stable five-star caster base that enables full 360-degree swivel movement. The chair presents a streamlined, modern silhouette that fits seamlessly across both commercial and residential interior styles without unnecessary bulk. Construction prioritizes durability and long-term comfort. The backrest uses breathable polyester tension mesh stretched over a glass-fiber reinforced polypropylene frame, with a built-in contoured lumbar zone for consistent lower back support. The headrest is a mesh-covered polypropylene pad mounted on an adjustable bracket, while the seat core consists of high-density molded polyurethane foam topped with fabric upholstery, finished with a contoured waterfall front edge to reduce pressure on the backs of the legs. The integrated fixed armrests are constructed from polypropylene, connected directly to the back frame for structural stability. The base is an injection-molded nylon and polypropylene five-star unit fitted with 60mm nylon dual-wheel swivel casters, paired with a Class 3 pneumatic steel gas lift for height adjustment and a 2.5mm thick steel butterfly tilt-lock chassis under the seat. The mesh upholstery is engineered to withstand heavy repeated use, with tested abrasion resistance, while the seat foam delivers consistent rebound for lasting cushioning, and casters operate at a low noise level to avoid disrupting shared spaces. Practical functions are tailored to varied user needs. The seat offers 100mm of vertical height adjustment via an under-seat pneumatic lever, while the backrest supports 3-position lockable recline up to 125 degrees, with weight-activated automatic tension adjustment to deliver balanced recline resistance for different users. The height-adjustable headrest can be positioned to support optimal neck alignment, and the dual-wheel casters roll smoothly across hard floors and low-pile carpet for easy repositioning. The breathable mesh back reduces heat buildup during long periods of sitting, supporting comfort across full workdays. This chair is suited for a wide range of settings, including open-plan office workstations for staff completing 8+ hours of daily desk work, compact home office study spaces for remote workers, conference and meeting rooms supporting collaborative discussion, computer and IT work areas with extended screen use, high-traffic reception and administrative zones, and flexible training room installations. For procurement teams, key considerations include that each unit ships across two cartons, with a 40-minute reference assembly time per set. The chair holds a recommended maximum user weight of 150 kg, with a high static load rating for the five-star base, and 135 sets can be loaded in a 20GP container at 85% space utilization, supporting efficient bulk order planning for large-scale fit-outs.
