Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 680 x 700 x 1280 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Maximum static load capacity | 150 kg | |
|---|---|---|
| Net weight (excluding packaging) | 23 kg | |
| Recommended daily usage duration | 8 hours | |
| Seat foam density | 45 kg/m³ | |
| Caster rolling durability cycle count | 100000 cycles | |
| Gas lift cycle rating | 120000 cycles | |
| Backrest recline maximum static load | 90 kg | |
| Recommended user height range | 1900 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest and headrest upholstery | Tensioned breathable black polyester mesh | |
|---|---|---|
| Seat cushion core | High-density molded polyurethane foam | |
| Armrest pads | Soft-touch polyurethane (PU) padded surface | |
| Structural armrest and back frame components | Reinforced black polypropylene (PP) plastic | |
| Five-star base | Polished die-cast aluminum alloy | |
| Gas lift cylinder | Chrome-plated steel Class 3 gas lift | |
| Casters | Dual-wheel polyurethane (PU) casters with metal roller bearings | |
| Chassis mechanism | 3mm thick cold-rolled steel tilt and lock mechanism | |
| Footrest surface | Breathable black mesh over PP support frame | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seat height adjustment | 100mm vertical stroke via Class 3 gas lift, controlled by right-side lever | |
|---|---|---|
| Backrest recline function | 135degree recline with multi-position tension adjustment and lock | |
| Headrest adjustment | Height adjustment up to 50mm and 25-degree tilt rotation | |
| Armrest adjustment | 70mm vertical height adjustment to match desk and user elbow height | |
| Retractable footrest | Pull-out 280mm extension under seat for leg support during recline | |
| 360-degree swivel rotation | Full rotational movement for easy access to surrounding workspace | |
| Smooth caster mobility | Dual-wheel casters roll freely on carpet, tile, and hardwood flooring | |
| Lumbar support | Fixed curved lumbar zone integrated into middle back mesh panel | |
| Tilt tension control | Adjustable resistance knob under seat matches user weight for recline force | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Commercial office workstations | Suitable for 8-hour daily use by staff in open-plan and private offices | |
|---|---|---|
| Home office workspaces | Ideal for remote workers requiring ergonomic support for long work sessions | |
| Conference and meeting rooms | Appropriate for extended meetings and collaborative discussion spaces | |
| Executive and management offices | High-back design provides comfort and professional aesthetic for private offices | |
| Gaming and recreational workspaces | Recline and footrest support casual use during breaks or gaming sessions | |
| Shared co-working spaces | Durable construction and adjustable features suit diverse rotating user groups | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to dimensional safety and performance requirements for office task chairs | |
|---|---|---|
| EN 1335-2:2018 | Applies to mechanical stability, strength, and durability test requirements for office seating | |
| EN 1021-1:2014 | Applies to upholstered furniture flammability resistance against ignition sources |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to performance and durability test standard for general-purpose office chairs | |
|---|---|---|
| ANSI/BIFMA X5.11-2015 | Applies to load rating requirements for office chairs supporting heavy users |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to size and dimensional tolerance requirements for office seating | |
|---|---|---|
| GB/T 10357.3-2013 | Applies to mechanical strength and durability test methods for office chairs | |
| GB 18584-2001 | Applies to limits of harmful substances released by wooden and upholstered furniture | |
| GB/T 29648-2013 | Applies to stability performance requirements for office swivel chairs |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to size and dimensional tolerance requirements for office seating; 2. GB/T 10357.3-2013: Applies to mechanical strength and durability test methods for office chairs; 3. GB 18584-2001: Applies to limits of harmful substances released by wooden and upholstered furniture; 4. GB/T 29648-2013: Applies to stability performance requirements for office swivel chairs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
