| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 630 x 650 x 1270 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net weight upper reference | 15 kg | |
|---|---|---|
| maximum recommended user load | 130 kg | |
| caster rolling durability rating | 100000 cycles | |
| seat foam density | 45 kg/m³ | |
| seat foam rebound rate | 60% | |
| mesh upholstery abrasion resistance | 50000 cycles | |
| warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| backrest upholstery | Breathable black polyester mesh | |
|---|---|---|
| backrest internal frame | Glass-fiber reinforced nylon | |
| seat pan structure | 14 mm thick high-density fiberboard | |
| seat padding | 55 mm thick high-density molded polyurethane foam | |
| seat upholstery | Black woven polyester fabric | |
| armrest pads | Soft polyurethane padding on polypropylene support posts | |
| 5-star base | 2.0 mm thick glass-fiber reinforced nylon | |
| gas lift cylinder | Class 3 chrome-plated steel, 28 mm outer diameter | |
| tilt mechanism chassis | 2.5 mm thick stamped steel | |
| casters | Dual-wheel nylon with polyurethane tread | |
| structural fasteners | Zinc-plated steel anti-loose screws | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| seat height adjustment | Pneumatic Class 3 gas lift, 140 mm stroke for 570 mm seat height | |
|---|---|---|
| backrest tilt function | Kneel-tilt mechanism with 125° maximum recline and lockable positions | |
| tilt tension control | Under-seat rotary knob adjusts spring tension for user weight | |
| 360° swivel rotation | Full rotation enabled by central gas lift swivel joint | |
| headrest adjustment | Height and angle adjustable mesh headrest for neck support | |
| lumbar support | Contoured adjustable lumbar zone for lower back posture support | |
| armrest adjustment | Vertical height adjustment with 100 mm travel for elbow support | |
| rolling mobility | 5 dual-wheel casters enable smooth movement on hard and soft floors | |
| stable support | Reinforced 5-star base distributes user weight evenly for tip resistance | |
| gas lift stroke | 140 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| private office workspace | Suitable for 8-hour daily desk work for professional staff | |
|---|---|---|
| home office setup | Fits standard home workstations for remote work and study | |
| open plan office task stations | Consistent black finish coordinates with modern office decor | |
| call center and customer service areas | Breathable mesh back reduces heat buildup for extended shifts | |
| conference and meeting room use | Professional appearance and swivel function suit collaborative meetings | |
| recommended desk compatibility | Pairs with 760 mm high standard office desks for proper ergonomics | |
| target user group | Adults 190 cm tall, up to 130 kg body weight | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | European standard for office chair dimensions and safety requirements | |
|---|---|---|
| EN 1335-2:2018 | European standard for office chair mechanical performance and stability | |
| EN 1021-1:2014 | European standard for upholstered furniture flammability (cigarette ignition) | |
| EN 1021-2:2014 | European standard for upholstered furniture flammability (match ignition) |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1 Test 5 | Static load test for chair backrests, 667 N applied force requirement | |
|---|---|---|
| static load rating for 5-star base | 1136 kg |
Standards applicable to China-market projects
| GB/T 3326-2016 | Standard for furniture size and dimension tolerance for office chairs | |
|---|---|---|
| GB/T 35607-2017 | Standard for green product assessment of furniture, limited harmful substances | |
| GB/T 10357.3-2013 | Test method for furniture mechanical performance of chairs and stools |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Standard for furniture size and dimension tolerance for office chairs; 2. GB/T 35607-2017: Standard for green product assessment of furniture, limited harmful substances; 3. GB/T 10357.3-2013: Test method for furniture mechanical performance of chairs and stools; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
