Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 700 x 700 x 1270 mm | |
|---|---|---|
| Five-star base diameter | 700 mm | |
| Seat width | 530 mm | |
| Seat depth | 520 mm | |
| Seat height adjustment range | 540 mm | |
| Backrest total height | 760 mm | |
| Headrest dimensions | 320 x 180 mm | |
| Armrest height adjustment travel | 80 mm | |
| Retractable footrest extension length | 300 mm | |
| Caster diameter | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended maximum user weight | 159 kg | |
|---|---|---|
| Net product weight | 24 kg | |
| Gas lift static load rating | 150 kg | |
| Five-star base static load capacity | 1136 kg | |
| Caster rolling durability cycles | 100000 cycles | |
| Seat foam density | 55 kg/m³ | |
| Foam rebound rate | 60% | |
| Mesh fabric abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest and headrest upholstery | Geometric patterned breathable polyester mesh | |
|---|---|---|
| Seat cushion core | High-density molded polyurethane foam | |
| Retractable footrest padding | Fabric-wrapped polyurethane foam pad | |
| Armrest support frames | Light gray reinforced polypropylene with metal adjustment hardware | |
| Armrest contact pads | Soft polyurethane padded surfaces | |
| Chair structural frame | Nylon-glass fiber reinforced plastic back and seat inner frame | |
| Five-star base | Light gray reinforced nylon composite | |
| Caster wheels | PU rolling tread with PP inner hub and metal mounting pin | |
| Gas lift cylinder | Chrome-plated steel Class 3 gas lift | |
| Recline mechanism | 2.5mm thick cold-rolled steel tilt chassis | |
| Seam stitch pitch | 8 mm | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seat height adjustment | Pneumatic adjustment via side lever, 100mm vertical travel | |
|---|---|---|
| Backrest recline function | Multi-position lock up to 150° for work and napping | |
| Retractable footrest operation | Slide-out padded footrest that stows fully under seat when unused | |
| Headrest adjustment | 50° angular rotation and 60mm height adjustment for neck alignment | |
| Armrest adjustment | 80mm height adjustment with padded arm surfaces | |
| Swivel function | 360-degree full rotation around central gas lift column | |
| Caster mobility | Smooth-rolling dual-wheel casters for hard and soft flooring | |
| Lumbar support | Contoured integrated lumbar zone aligned to natural lower back curve | |
| Backrest recline maximum angle | 150° | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Private home office workstations | Suitable for long-hour desk work with recline and footrest for break periods | |
|---|---|---|
| Open-plan commercial office spaces | Light neutral finish and ergonomic support for shared employee workstations | |
| Executive private offices | High-back support and premium mesh finish for professional work environments | |
| Co-working flexible desk spaces | Adjustable dimensions and swivel function suit diverse user body types | |
| Study rooms for teen and adult users | Supports upright study posture and reclined rest for multi-use spaces | |
| Nap-friendly break work areas | 150° recline and footrest enable short rest periods during workdays | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional and general safety requirements | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair mechanical strength and durability performance | |
| EN 1335-3:2018 | Applies to office chair stability and structural integrity verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to general-purpose office chair strength, durability and safety |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office furniture chair dimensional accuracy and stability testing | |
|---|---|---|
| GB/T 10357.3-2013 | Applies to office chair seat, backrest and armrest strength/durability testing | |
| GB 28007-2011 | Applies to office chair caster durability and safety requirements |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office furniture chair dimensional accuracy and stability testing; 2. GB/T 10357.3-2013: Applies to office chair seat, backrest and armrest strength/durability testing; 3. GB 28007-2011: Applies to office chair caster durability and safety requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
