PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	700 × 635 × 1260 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	150 kg
Net weight range	22 kg
Caster rolling durability	40000 cycles
Gas lift cycle life	120000 cycles
Backrest tilt angle range	22 degrees
Mesh fabric abrasion resistance	50000 double rubs
Seat foam density	45 kg/m³
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest upholstery	Tensioned breathable polyester mesh
Seat cushion core	High-resilience molded polyurethane foam
Armrest pads	Soft-touch polyurethane padding on plastic supports
Internal back frame	Glass-fiber reinforced polypropylene
Five-star base	Polished die-cast aluminum alloy
Height adjustment mechanism	Chrome-plated steel Class 3 gas lift
Tilting chassis	2.5mm thick stamped steel multi-lock mechanism
Casters	60mm diameter polyurethane dual-wheel casters
Headrest frame	Injection-molded ABS plastic with mesh overlay
Lumbar support component	Flexible TPE plastic adjustable lumbar pad
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	100mm vertical travel via gas lift, lockable at any height in range
Headrest adjustment	40mm height adjustment and 30-degree angle tilt to support cervical spine
Armrest adjustment	75mm height adjustment to align with varying desk heights
Backrest tilt function	Synchronized tilt with 3-position locking mechanism, adjustable tension knob
Lumbar support	Elastic self-adapting lumbar panel that flexes with user back movement
Caster mobility	360-degree swivel dual casters suitable for hard floors and low-pile carpet
Seat rotation	360-degree full swivel around central gas lift axis for multi-directional access
Recline tension control	Rotary knob under seat adjusts tilt resistance to match user weight
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Corporate open office workstations	Suitable for 8-hour daily desk work with ergonomic support for seated tasks
Home office study spaces	Fits standard 760 mm height office desks for remote work use
Executive private offices	High-back design provides upper back and head support for management roles
Conference meeting rooms	Swivel and tilt function supports long-duration collaborative meetings
IT and coding workstations	Adjustable components accommodate varied postures during extended screen time
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-1:2020	Office furniture - Office work chairs - Part 1: Dimensions, for dimensional compliance verification
EN 1335-2:2018	Office furniture - Office work chairs - Part 2: Safety requirements, for structural safety testing
EN 1335-3:2009	Office furniture - Office work chairs - Part 3: Test methods, for durability performance validation

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	Office Chairs standard, applicable for strength, durability and stability performance testing
ANSI/BIFMA e3-2019	Furniture sustainability standard, applicable for environmental attribute verification

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable for non-metallic structural components
GB 28007-2011	Safety and performance requirements for office swivel chairs, mandatory for domestic market sales
GB/T 35607-2017	Eco-friendly product evaluation requirements for furniture, recommended for green procurement

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for non-metallic structural components;
2. GB 28007-2011: Safety and performance requirements for office swivel chairs, mandatory for domestic market sales;
3. GB/T 35607-2017: Eco-friendly product evaluation requirements for furniture, recommended for green procurement;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · ERG-OFC-MSH-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · ERG-OFC-MSH-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · ERG-OFC-MSH-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Ergonomic High-Back Mesh Office Chair with Adjustable Headrest and Lumbar Support, model ERG-OFC-MSH-001, is an unbranded public and workspace seating solution designed for long-duration seated use. Its streamlined, contemporary form features a contoured high-back profile paired with a wide, supportive seat, structured to deliver consistent postural alignment without bulky, obstructive detailing. The open mesh back creates a light, unobtrusive visual presence suitable for a range of interior design schemes, while the polished five-star base adds a refined, durable structural anchor. The chair is constructed for long-term heavy use, with a tensioned breathable polyester mesh backrest supported by a glass-fiber reinforced polypropylene internal frame. The seat uses a high-resilience molded polyurethane foam core with 90mm cushion thickness, topped with breathable mesh upholstery. Other structural components include soft-touch polyurethane armrest pads on plastic supports, a polished die-cast aluminum alloy five-star base, 60mm diameter polyurethane dual-wheel casters, and a chrome-plated steel Class 3 gas lift paired with a 2.5mm thick stamped steel multi-lock tilting chassis. The mesh fabric withstands 50000 double rubs for abrasion resistance, the casters deliver 40000 cycles of rolling durability, and the gas lift supports 120000 adjustment cycles, with a maximum recommended user weight capacity of 150kg and net weight of 22kg. Functional design supports personalized, comfortable positioning across varied user needs: seat height adjusts 100mm vertically with lockable positioning at any point in range, the headrest offers 40mm of height adjustment and 30-degree tilt to support the cervical spine, armrests adjust 75mm in height to align with different desk surfaces, and the backrest offers 22 degrees of synchronized tilt with a 3-position lock and adjustable tension control. An elastic self-adapting lumbar panel flexes with natural back movement to maintain consistent lower back support, while 360-degree swivel seat movement and dual casters enable smooth, multi-directional access across hard floors and low-pile carpet. This chair is well suited for corporate open office workstations supporting 8-hour daily desk tasks, home office study spaces paired with standard 760mm height office desks, executive private offices for management roles, conference meeting rooms for long collaborative sessions, and IT or coding workstations where extended screen time requires flexible posture support; it is recommended for pairing with a 2.4m executive desk for optimal fit. Procurement teams should note each unit ships in 2 cartons, with a packaged gross weight of 23kg per set, 0.26m³ carton volume, and 40 minutes of required assembly time per unit; a 20GP container can hold 135 sets at 85% space utilization for bulk order planning.
