Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 690 x 690 x 1390 mm | |
|---|---|---|
| seat width | 509 mm | |
| seat depth | 495 mm | |
| seat height adjustment range | 570 mm | |
| five-star base diameter | 700 mm | |
| caster diameter | 50 mm | |
| seat cushion thickness | 127 mm | |
| backrest total height | 515 mm | |
| headrest dimensions | 320 x 180 mm | |
| armrest height above seat | 220 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| maximum recommended user weight | 150 kg | |
|---|---|---|
| net product weight | 18.6 kg | |
| maximum recline angle | 135 degrees | |
| caster rolling durability | 100000 cycles | |
| gas lift stroke length | 150 mm | |
| daily recommended use duration | 8 hours | |
| applicable user height range | 1880 mm | |
| maximum applicable user height | 1880 mm | |
| tilt mechanism static load | 136 kg | |
| base static load capacity | 1136 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat upholstery | Woven grey polyester fabric | |
|---|---|---|
| seat cushion core | 50kg/m³ high-density molded foam | |
| back support pads | Fabric-wrapped foam over nylon support frame | |
| headrest padding | Fabric-wrapped high-resilience foam | |
| armrest construction | Injection-molded PP plastic T-shaped tops | |
| chair frame | Fiberglass-reinforced nylon | |
| five-star base | Injection-molded light grey PP plastic | |
| caster wheels | PU tread with PP hub, double-wheel design | |
| gas lift cylinder | Chromed steel with black plastic sleeve | |
| tilt mechanism | 2mm thick steel plate under seat | |
| dual back support pads | Fabric-wrapped 45kg/m³ foam over fiberglass-reinforced nylon frame | |
| internal chair frame | Fiberglass-reinforced nylon, 8mm average wall thickness |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full rotation enabled by central gas lift and base | |
|---|---|---|
| pneumatic seat height adjustment | 150mm vertical travel via under-seat lever | |
| recline tilt with upright lock | 135-degree max recline with adjustable tension | |
| fixed height T-arm support | Static armrests aligned to standard desk elbow height | |
| dual independent lumbar support pads | Separate left/right padded panels for spinal alignment | |
| height-adjustable headrest | 100mm vertical travel to support neck and head | |
| silent rolling casters | Smooth double-wheel movement on hard and soft floors | |
| waterfall seat edge design | Contoured front edge to reduce leg pressure | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| private office workspace | For individual workstations requiring all-day seating comfort | |
|---|---|---|
| home office setup | Fits residential work areas with neutral light grey finish | |
| open plan office task seating | Standard footprint suitable for clustered workstation layouts | |
| call center workstations | Durable build supports 8+ hours daily seated use for agents | |
| co-working space hot desks | Adjustable height accommodates diverse user body types | |
| study room desk seating | Suitable for students and home users during extended study sessions | |
| residential study room seating | Suitable for students and remote learners during extended study sessions | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional and safety requirements | |
|---|---|---|
| EN 1335-2:2018 | Applies to office chair strength, durability and stability | |
| EN 1022:2018 | Applies to seating furniture stability verification for domestic and contract use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applies to office chair static/dynamic load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to office chair dimensional stability and strength testing | |
|---|---|---|
| GB 28007-2011 | Applies to upholstered furniture formaldehyde emission limits | |
| GB/T 10357.3-2013 | Applies to chair strength and durability mechanical test methods |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to office chair dimensional stability and strength testing; 2. GB 28007-2011: Applies to upholstered furniture formaldehyde emission limits; 3. GB/T 10357.3-2013: Applies to chair strength and durability mechanical test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
