Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 780 mm | |
|---|---|---|
| Single seat width | 520 mm | |
| Seat depth | 480 mm | |
| Seat height from floor | 450 mm | |
| Backrest height above seat | 400 mm | |
| Seat pad thickness | 40 mm | |
| Backrest pad thickness | 30 mm | |
| Armrest height above seat | 220 mm | |
| Leg stance width at base | 1600 mm | |
| Floor clearance under seat | 280 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 28 kg | |
|---|---|---|
| Static load per seat | 200 kg | |
| Total rated static load for full bench | 600 kg | |
| Recommended occupancy | 3 adults | |
| Frame static load capacity | 1000 kg | |
| Foot pad floor load distribution | 200 kg per leg | |
| Seam stitch durability | 30000 abrasion cycles | |
| Surface corrosion resistance | 48 hours neutral salt spray | |
| Backrest static load resistance | 760 N per seat | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary load-bearing frame | 1.5mm thick polished chrome-plated cold-rolled steel tubing with welded joints | |
|---|---|---|
| Seat and back divider frames | Die-cast aluminum alloy with chrome finish | |
| Armrests | Die-cast polished aluminum alloy with ergonomic closed-loop curve | |
| Seat padding | High-density polyurethane foam with density 45kg/m³ | |
| Backrest padding | High-density polyurethane foam with density 40kg/m³ | |
| Seat/back upholstery surface | 0.8mm thick matte polyurethane (PU) leather with stain-resistant finish | |
| Support legs | 1.8mm thick chrome-plated steel with flared splay design | |
| Floor feet | 10mm thick rubber non-slip adjustable leveling pads | |
| Fasteners | Stainless steel hex bolts and locking nuts for all structural joints | |
| Seat-to-frame connection brackets | 3mm thick powder-coated steel plates | |
| Edge trim | 1mm thick chrome-plated steel edging around all seat and back pad perimeters | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3 individual seats with rigid dividers between positions | |
|---|---|---|
| Armrest support | Dual end armrests with ergonomic curved grip surface | |
| Floor stability | 4 adjustable leveling feet to compensate for uneven floor surfaces | |
| Cleaning access | 280mm under-seat floor clearance | |
| Upholstery maintenance | Non-porous PU surface supports wipe-down cleaning with standard disinfectants | |
| Structural rigidity | Fully welded frame joints with no moving parts | |
| Anti-corrosion performance | Multi-layer chrome plating on all metal components | |
| Floor protection | Rubber contact pads on all feet | |
| Upright seating support | 10 degree backrest recline angle | |
| Backrest tilt angle from vertical | 10 degrees | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 1800 x 700 x 280 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume (CBM) | 0.35 CBM | |
| Required assembly time | 30 minutes | |
| 20ft GP container loading quantity | 105 units | |
| 40ft HC container loading quantity | 250 units | |
| Included hardware kit | All required bolts, hex wrench, and assembly instructions | |
| Inner packaging materials | Polyethylene foam wrap and corner protectors, plastic bag for hardware | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | Suitable for high-turnover healthcare waiting spaces, with wipe-clean surfaces and durable construction to withstand continuous daily use | |
|---|---|---|
| Transit station waiting zones | Ideal for airport, train station and bus terminal seating, with stable fixed structure and high load capacity for heavy public traffic | |
| Government and public service lobbies | Appropriate for bank, post office and municipal service hall waiting areas, with neutral professional appearance and defined individual seating positions | |
| Office building reception areas | Suitable for corporate lobby and reception waiting zones, with polished metal finish matching modern commercial interior design | |
| Education institution common areas | Usable in school administrative offices, library waiting zones and student service areas, with sturdy construction resistant to heavy use by student populations | |
| Outdoor covered waiting areas | Suitable for covered bus stops and building entrance waiting zones, with chrome-plated rust-resistant frame that withstands mild outdoor humidity | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable to non-domestic seating strength, durability and safety: sets performance requirements for public use seating including gang benches | |
|---|---|---|
| EN 1022:2018 | Applicable to seating stability testing: defines test methods for stability of fixed seating on level and uneven surfaces | |
| EN 12520:2015 | Applicable to furniture strength, durability and safety for outdoor and public seating: includes requirements for structural integrity under repeated use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable to general purpose office chairs: provides reference test methods for static load, fatigue and stability for multi-seat public waiting seating | |
|---|---|---|
| ANSI/BIFMA X5.4-2020 | Applicable to lounge and public seating: defines performance criteria for seating intended for short-term occupancy in commercial spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to metal furniture general technical requirements: sets structural stability, dimension tolerance, and surface finish criteria for fixed metal waiting seating | |
|---|---|---|
| GB/T 10357.2-2013 | Applicable to furniture mechanical performance testing for seating: defines static load and fatigue test methods for chair seats and backrests for commercial use | |
| GB 18584-2001 | Applicable to indoor furniture environmental control: sets limits for formaldehyde and heavy metal emissions from upholstered and coated furniture components | |
| GB/T 29601-2013 | Applicable to public seating for indoor public places: specifies durability, safety and usability requirements for high-traffic waiting area furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to metal furniture general technical requirements: sets structural stability, dimension tolerance, and surface finish criteria for fixed metal waiting seating; 2. GB/T 10357.2-2013: Applicable to furniture mechanical performance testing for seating: defines static load and fatigue test methods for chair seats and backrests for commercial use; 3. GB 18584-2001: Applicable to indoor furniture environmental control: sets limits for formaldehyde and heavy metal emissions from upholstered and coated furniture components; 4. GB/T 29601-2013: Applicable to public seating for indoor public places: specifies durability, safety and usability requirements for high-traffic waiting area furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
