Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1800 x 768 x 840 mm | |
|---|---|---|
| Single seat effective width | 600 mm | |
| Seat height from floor | 450 mm | |
| Seat surface depth | 450 mm | |
| Backrest height above seat | 390 mm | |
| Armrest height above seat | 200 mm | |
| Leg spread width at floor | 1650 mm | |
| Seat to underside leg clearance | 320 mm | |
| Wood edge trim thickness | 12 mm | |
| Floor glide diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Static load per seat | 200 kg | |
|---|---|---|
| Total unit static load capacity | 600 kg | |
| PU surface abrasion resistance | 100000 cycles | |
| Backrest static load resistance | 760 N | |
| Leg assembly static load | 1000 kg | |
| Net unit weight | 38 kg | |
| Surface disinfectant tolerance | Compatible with 75% alcohol and quaternary cleaners | |
| Fire performance rating | B1 grade | |
| Standard product warranty | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back facing | 60 kg/m³ density PU self-skinning upholstery | |
|---|---|---|
| Internal padding | 40 mm thick high-resilience polyurethane foam | |
| Seat and back edge trim | 12 mm thick bent beech plywood with clear lacquer finish | |
| Support beam structure | 10.5 mm thick triangular cold-rolled steel tube | |
| Internal seat support plate | 1.2 mm thick SPCC cold-rolled steel plate | |
| Leg frame | 1.5 mm thick chrome-plated curved steel tubing | |
| End armrest tops | 50 mm wide black PU padded arm caps | |
| Armrest supports | Die-cast aluminum alloy with matching chrome finish | |
| Floor glides | Nylon base with TPE anti-slip pad | |
| Fasteners | Zinc-plated steel hex bolts and lock nuts | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed inline 3-seat arrangement on shared steel beam, non-folding, non-reclining | |
|---|---|---|
| Armrest layout | Fixed padded armrests only at two outer ends of the unit, no intermediate dividers | |
| Floor installation | Free-standing with anti-slip glides; pre-drilled holes for optional permanent floor anchoring | |
| Surface maintenance | Non-porous seamless PU surfaces resist liquid penetration, wipe-clean without special treatments | |
| Contour ergonomics | Slightly contoured seat pans and angled backrests support upright short-term seated posture | |
| Structural stability | Dual-curved cantilever leg design distributes weight evenly across three floor contact points per side | |
| Customization option | Upholstery color and intermediate armrest additions available on request | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | Disinfectable PU surfaces and durable construction suit high-turnover patient waiting zones | |
|---|---|---|
| Airport and transit station waiting zones | High static load rating and abrasion resistance support heavy daily public use | |
| Bank and government service halls | Neutral teal finish and fixed beam design provide tidy, durable queuing seating | |
| Office building reception lobbies | Compact inline layout fits narrow lobby spaces without blocking circulation paths | |
| School and training center common areas | Stable construction and easy-clean surfaces withstand frequent student and visitor use | |
| Recommended configuration option | Add intermediate PU armrests between seats for high-security public facilities to define individual spaces | |
| Compatible floor types | Suitable for tile, terrazzo, epoxy and polished concrete floors without additional matting | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| Public seating safety standard | EN 16139:2013 | |
|---|---|---|
| Furniture surface flammability | EN 1021:2014 |
US and Canada office-furniture standards
| Multi-seat public seating standard | ANSI/BIFMA X2019 |
|---|
Standards applicable to China-market projects
| Metal furniture structural standard | GB/T 3325 | |
|---|---|---|
| Upholstered furniture fire standard | GB 20286 | |
| Furniture surface VOC limit | GB 18584 |
This product must meet the following technical requirements: 1. Metal furniture structural standard: GB/T 3325; 2. Upholstered furniture fire standard: GB 20286; 3. Furniture surface VOC limit: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
