Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 680 x 800 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Individual seat width | 550 mm | |
| Seat depth | 480 mm | |
| Backrest height above seat | 370 mm | |
| Armrest height above seat | 200 mm | |
| Leg spread width (front to back) | 650 mm | |
| Perforation diameter (seat/back panels) | 5 mm | |
| Seat panel thickness | 1.5 mm | |
| Frame tube diameter | 38 mm | |
| Floor glide diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net product weight | 28 kg | |
|---|---|---|
| Static load capacity per seat | 150 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| Surface abrasion resistance | 50000 cycles | |
| Structural cycle test rating | 100000 use cycles | |
| Seating capacity | 3 adults | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat panels | 1.5mm thick brushed stainless steel sheet with perforated round holes | |
|---|---|---|
| Backrest panels | 1.2mm thick brushed stainless steel sheet with matching perforated pattern | |
| Armrests | Bent 38mm diameter brushed stainless steel tubular steel, polished rounded edges | |
| Support legs | Angled 38mm diameter brushed stainless steel tubular steel, welded cross-brace connection | |
| Seat dividers | 1.5mm thick bent stainless steel vertical panels between each seat | |
| Floor glides | Nylon-padded adjustable stainless steel glides at each leg base | |
| Frame hardware | Stainless steel bolted and welded joints, anti-corrosion treated fasteners | |
| Surface finish | Brushed #4 stainless steel finish, no additional paint or powder coating | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3 divided seat positions with individual back support, no adjacent seat interference | |
|---|---|---|
| Ventilation performance | Perforated seat and back panels allow continuous air circulation, reducing heat buildup during extended seated use | |
| Floor installation compatibility | Freestanding design with adjustable glides, optional floor anchor mounting possible via leg base holes | |
| Stand assist support | Fixed end armrests and vertical dividers provide rigid support points for users to push against when standing | |
| Anti-tip stability | Splayed four-leg design with 650mm front-to-back leg spread prevents tipping under uneven user weight distribution | |
| Corrosion resistance suitability | All exposed metal construction is suitable for high-moisture or high-cleaning-frequency environments | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 unit | |
|---|---|---|
| Packed carton dimensions | 1850 x 730 x 520 mm | |
| Gross packaged weight | 32 kg | |
| Packaged volume per unit | 0.70 CBM | |
| Assembly time for 2 installers | 20 minutes | |
| 20ft GP container loading quantity | 38 units | |
| 40ft HQ container loading quantity | 92 units | |
| Packaging materials | 5-layer corrugated carton, expanded polyethylene foam corner protection, plastic film wrap | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | All-metal seamless construction allows repeated disinfection, perforated surfaces resist liquid pooling for clinical environments | |
|---|---|---|
| Transportation terminal waiting zones | High durability and static load rating support continuous heavy use in airport, railway station and bus terminal public areas | |
| Government and public service hall waiting areas | Neutral brushed metal finish matches formal public interior design, fixed stable structure resists vandalism and heavy use | |
| Office building reception and lobby waiting zones | Minimalist industrial aesthetic complements modern office interior design, easy to clean between visitor use | |
| Outdoor covered waiting areas | All-metal construction with corrosion-resistant finish performs well in semi-outdoor locations with direct weather protection | |
| Bank and financial service branch waiting areas | Rigid, fixed construction provides secure, durable seating for customer waiting areas with high daily foot traffic |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Public seating furniture - Requirements for safety, strength and durability, applicable for structural performance requirements for public area waiting seating | |
|---|---|---|
| EN 1022:2018 | Domestic and non-domestic seating - Determination of stability, applicable for anti-tip testing requirements for freestanding multi-seat benches |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | General purpose office chairs - Tests for strength and durability, applicable as reference for static load, fatigue and stability testing for commercial waiting seating | |
|---|---|---|
| ANSI/BIFMA X5.4-2020 | Lounge and public seating, applicable for public area multi-seat bench performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural stability, dimensional tolerance and surface finish acceptance inspection for public waiting benches | |
|---|---|---|
| GB/T 10357.1-2013 | Furniture mechanical performance test for seating strength and durability, applicable for static load, impact and fatigue testing of this bench | |
| GB/T 10357.2-2013 | Furniture mechanical performance test for chair backrest strength, applicable for backrest static load and fatigue testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural stability, dimensional tolerance and surface finish acceptance inspection for public waiting benches; 2. GB/T 10357.1-2013: Furniture mechanical performance test for seating strength and durability, applicable for static load, impact and fatigue testing of this bench; 3. GB/T 10357.2-2013: Furniture mechanical performance test for chair backrest strength, applicable for backrest static load and fatigue testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
