Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 800 mm | |
|---|---|---|
| Single seat width | 500 mm | |
| Seat depth | 400 mm | |
| Seat height from floor | 450 mm | |
| Backrest height | 400 mm | |
| Backrest thickness (formed panel) | 20 mm | |
| Armrest height from seat surface | 220 mm | |
| Support leg spread width | 1600 mm | |
| Floor pad diameter | 50 mm | |
| Armrest diameter (tubing) | 25 mm | |
| Seat panel thickness | 1.2 mm | |
| Perforation diameter (back panel) | 5 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight range | 28 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Maximum number of seated users | 3 | |
| Seat edge static impact resistance | 45 kg drop from 300mm height | |
| Frame connection static load endurance | 20000 cycles of 100kg per seat | |
| Corrosion resistance suitability | Indoor and semi-outdoor covered use | |
| Floor load distribution | Equalized across 4 support legs | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat panels | 1.2mm thick 201 stainless steel sheet with polished finish and rounded rolled front edge | |
|---|---|---|
| Backrest panels | 1.0mm thick 201 stainless steel perforated sheet with uniform 5mm round holes, reinforced formed perimeter edges | |
| Main support beam | 2.0mm thick rectangular stainless steel tube running full bench length under seats, welded to seat supports | |
| Support legs | 2.5mm thick formed stainless steel Y-spider legs, welded to main beam with integral floor glide mounts | |
| Armrests | 25mm diameter polished stainless steel round tube, bent to ergonomic curve, welded to side seat frames | |
| Floor glides | Stainless steel adjustable threaded glides with non-marring rubber contact pads | |
| Seat/back partitions | 1.5mm thick formed stainless steel dividers between each seat, separating individual seating positions | |
| Surface finish | No.4 brushed stainless steel finish across all components, no applied coating or upholstery | |
| Hardware and fasteners | All-stainless steel welded construction at primary joints, no exposed ferrous fasteners | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed non-reclining seating configuration | All seats and backrests are permanently mounted to the main support beam at a fixed 105 degree seat-to-back angle, no adjustment mechanisms | |
|---|---|---|
| Integrated end armrests | Curved polished armrests fitted at both extreme ends of the 3-seat bench, providing arm support for outermost users and defined bench boundaries | |
| Perforated back ventilation | Full-perforation backrest panels allow constant air circulation between user and backrest, reducing heat buildup during extended waiting periods | |
| Adjustable floor leveling | Threaded adjustable glides at the base of each 4 support legs rotate to compensate for 10mm of uneven floor height, eliminating bench rock when installed on tile or concrete surfaces | |
| Fixed individual seat separation | Vertical stainless steel dividers between each adjacent seat define clear 500mm wide individual seating positions, discouraging overcrowding and improving personal space for waiting users | |
| Sanitization-compatible design | Smooth, non-porous all-stainless steel surfaces with no fabric, seams or recessed crevices allow full wipe-down disinfection with standard hospital-grade cleaning agents | |
| Fixed floor-ready installation | Bench is delivered as a single fully welded integrated unit, requiring no assembly of seat or back components, only placement and glide leveling before use | |
| Anti-tip structural design | Splayed 4-point spider leg geometry extends beyond the seat perimeter, with a wide support base that prevents forward or sideways tipping even under uneven user loading | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit | |
|---|---|---|
| Shipping carton dimensions | 1800 x 700 x 500 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit (CBM) | 0.63 cbm | |
| On-site assembly time | 10 minutes | |
| 20ft GP container loading quantity | 42 units | |
| 40ft HQ container loading quantity | 105 units | |
| Protective packaging materials | 50mm EPE foam wrap on all metal surfaces, corrugated cardboard corner protectors, stretch wrap over full unit | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital clinic waiting areas | All-stainless steel construction withstands frequent sanitization, heavy daily use, and exposure to medical cleaning chemicals, ideal for high-turnover patient waiting zones | |
|---|---|---|
| Airport, rail and bus terminal waiting halls | Heavy-duty rigid construction supports continuous heavy passenger traffic, perforated backs remain comfortable for extended waiting periods, and non-upholstered surfaces resist staining from luggage or food spills | |
| Government service hall and bank queuing areas | Defined 3-seat configuration provides orderly, durable seating for citizens and customers, easy to maintain between service peaks, and neutral metallic finish matches formal public interior design | |
| Outpatient and emergency department public corridors | Non-porous seamless construction allows rapid disinfection between users, reducing infection risk in high-traffic medical environments with no fabric to trap contaminants | |
| School administration and public lobby areas | Sturdy construction resists rough handling and heavy student use, requires no routine upholstery maintenance, and provides long service life with minimal upkeep | |
| Semi-outdoor covered bus stops and station platforms | Stainless steel material resists humidity and occasional rain exposure under cover, does not rust or degrade from weather exposure in partially protected outdoor locations | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 Furniture - Strength, durability and safety - Non-domestic seating | Applies as acceptance reference for strength, stability and safety requirements for non-domestic public waiting seating | |
|---|---|---|
| EN 10088-2:2014 Stainless steels - Technical delivery conditions for sheet/plate and strip of corrosion resisting steels | Applies as reference for stainless steel sheet material properties and corrosion resistance requirements for construction components |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for metal furniture | Applies as acceptance reference for dimensional tolerance, welded joint quality, surface finish quality and structural stability of this all-stainless steel public seating unit | |
|---|---|---|
| GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools | Applies as acceptance reference for seat static load, backrest static load, impact resistance and fatigue cycle testing for public use seating | |
| GB/T 24821-2009 Public seating for airport terminals | Applies as reference specification for heavy-duty public gang seating used in high-traffic waiting areas, covering load ratings and safety clearances |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for metal furniture: Applies as acceptance reference for dimensional tolerance, welded joint quality, surface finish quality and structural stability of this all-stainless steel public seating unit; 2. GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools: Applies as acceptance reference for seat static load, backrest static load, impact resistance and fatigue cycle testing for public use seating; 3. GB/T 24821-2009 Public seating for airport terminals: Applies as reference specification for heavy-duty public gang seating used in high-traffic waiting areas, covering load ratings and safety clearances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
