Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 780 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Static load per seat | 300 kg | |
|---|---|---|
| Total unit static load capacity | 900 kg | |
| Unit net weight | 23 kg | |
| Powder coat thickness | 70 μm | |
| Seat/back panel steel thickness | 1.2 mm | |
| Support beam steel thickness | 3.0 mm | |
| Leg assembly steel thickness | 2.0 mm | |
| Warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat pans | 1.2mm cold-rolled steel with rolled rounded safety edges | |
|---|---|---|
| Backrest panels | 1.2mm perforated cold-rolled steel with gradient perforation pattern | |
| Structural support beam | 3.0mm thick cold-rolled steel triangular profile | |
| Outboard armrests | Curved cold-rolled steel with welded gusseted connections | |
| Leg assemblies | 2.0mm thick splayed cold-rolled steel with anti-tilt bracing | |
| Leveling feet | Chrome-plated steel with non-slip rubber contact pads | |
| Surface finish | Epoxy-polyester electrostatic powder coating over phosphated steel | |
| Frame hardware | Grade 8.8 zinc-plated steel bolts and lock nuts | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed linear 3-seat layout with no intermediate dividing armrests | |
|---|---|---|
| Leveling adjustment | Threaded adjustable feet allow 15mm vertical height adjustment | |
| Surface sanitation | Smooth non-porous metal surfaces support spray disinfection for high-hygiene areas | |
| Backrest ventilation | Perforated backrest panels allow continuous air flow to reduce seated heat buildup | |
| Structural rigidity | Gusseted welded leg-to-beam connections prevent frame wobble under heavy load | |
| Assembly requirement | Knock-down bolted assembly using basic hand tools with provided hardware | |
| Safety design | Rolled rounded edges on all seat and backrest perimeters eliminate sharp injury risks | |
| Floor protection | Rubber pads on leveling feet prevent scuffing and slipping on hard floor surfaces | |
| Backrest recline angle | 110° | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Airport terminal waiting areas | Heavy-duty construction supports continuous high-volume daily passenger use | |
|---|---|---|
| Hospital and clinic waiting zones | Non-porous disinfectable surfaces meet healthcare hygiene requirements | |
| Railway and bus station concourses | Stable anti-tilt design and high load capacity suit high-traffic transit environments | |
| Government service hall queuing areas | Neutral silver finish matches formal public space interiors | |
| Bank and office reception waiting areas | Fixed 3-seat layout organizes queuing without rearrangement | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Non-domestic seating strength/durability/stability, applicable for public area use |
|---|
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable for structural safety and finish quality | |
|---|---|---|
| GB/T 10357.2-2013 | Chair stability test standard, applicable for anti-tilt performance verification | |
| GB/T 10357.3-2025 | Chair strength and durability test standard, applicable for load and fatigue verification |
This product must meet the following technical requirements: 1. GB/T 3325-2017: Metal furniture general technical requirements, applicable for structural safety and finish quality; 2. GB/T 10357.2-2013: Chair stability test standard, applicable for anti-tilt performance verification; 3. GB/T 10357.3-2025: Chair strength and durability test standard, applicable for load and fatigue verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
