Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 800 mm | |
|---|---|---|
| Individual seat width | 500 mm | |
| Individual seat depth | 450 mm | |
| Seat height from floor | 430 mm | |
| Backrest height per position | 400 mm | |
| Seat pad thickness | 40 mm | |
| Back pad thickness | 30 mm | |
| Armrest height from seat surface | 220 mm | |
| Leg spread width (front to back) | 620 mm | |
| Gap between adjacent seat dividers | 20 mm | |
| Floor glide adjustment range | 15 mm | |
| Backrest angle from horizontal seat surface | 100 degrees | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Unit net weight | 22 kg | |
|---|---|---|
| Static load per seat | 150 kg | |
| Total unit static load capacity | 450 kg | |
| Seating capacity | 3 adults | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Frame static load test capacity | 1200 kg | |
| Recommended warranty period for commercial use | 3 years | |
| Seam stitch tensile strength | 120 N | |
| Wobble tolerance after leveling | 0 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main support frame | 1.5mm thick chrome-plated cold-rolled steel tube | |
|---|---|---|
| Seat and back support panels | 1.2mm thick perforated steel base under padding | |
| Seat upholstery | 0.8mm thick blue polyurethane (PU) leather over foam | |
| Back upholstery | 0.8mm thick matching blue polyurethane (PU) leather over foam | |
| Armrests | Polished die-cast aluminum alloy | |
| Seat divider uprights | 1.8mm thick chrome-plated steel | |
| Leg supports | 2.0mm thick chrome-plated angled steel legs | |
| Floor glides | Nickel-plated steel threaded stems with rubber non-slip pads | |
| Seat cushion foam | 40mm thick high-resilience polyurethane foam, density 45kg/m³ | |
| Back cushion foam | 30mm thick high-resilience polyurethane foam, density 40kg/m³ | |
| Hardware fasteners | Stainless steel grade 304 bolts and connecting brackets | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 3 fixed individual seating positions separated by rigid metal dividers | |
|---|---|---|
| Surface cleaning access | Smooth non-porous PU upholstery and polished metal frame | |
| Floor leveling | 6 threaded adjustable glides (two per leg assembly) | |
| Installation type | Freestanding unit, no permanent floor anchoring required | |
| Ergonomic support | Fixed upright backrest angle of 100 degrees from seat surface | |
| Armrest support | Contoured dual armrests at outermost positions, no intermediate armrests between seats | |
| Corrosion resistance | Multi-layer chrome plating on all steel frame components | |
| Configuration flexibility | Connectable side brackets to link multiple 3-seat units into longer continuous waiting rows | |
| Row configuration | Integrated side connection brackets to link multiple 3-seat units into longer continuous waiting rows | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 1800 x 700 x 250 mm | |
| Gross shipping weight per carton | 26 kg | |
| Shipping volume (CBM) per unit | 0.315 CBM | |
| Assembly time per unit | 20 minutes | |
| 20ft GP container loading capacity | 84 units | |
| 40ft HQ container loading capacity | 208 units | |
| Packaging material | 5-layer corrugated carton with EPE foam edge protection and plastic bag wrapping | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Healthcare facility waiting areas | Suitable for hospital outpatient halls, clinic waiting zones, and vaccination sites | |
|---|---|---|
| Transit hub waiting zones | Suitable for bus terminals, train stations, and airport public waiting areas | |
| Office building lobbies and reception areas | Suitable for corporate visitor waiting spaces and government service halls | |
| Education institution public areas | Suitable for school administration offices, library waiting zones and student service centers | |
| Bank and service center waiting areas | Suitable for bank branches, post offices and utility service centers | |
| Temporary event seating | Suitable for exhibition halls, conference venues and temporary public event spaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety - Non-domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability | |
| EN 13759:2004 | Furniture - Seating - Test methods for hardware components |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture | |
|---|---|---|
| GB/T 16799-2008 | Polyurethane leather for furniture | |
| GB 28007-2011 | Safety requirements for children's furniture, edge radius requirements | |
| GB/T 35607-2017 | Evaluation of green product furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture; 2. GB/T 16799-2008: Polyurethane leather for furniture; 3. GB 28007-2011: Safety requirements for children's furniture, edge radius requirements; 4. GB/T 35607-2017: Evaluation of green product furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
