Automatic mm / inch conversion · Core engineering specifications
| seat height from floor | 450 mm | |
|---|---|---|
| seat width between armrests | 520 mm | |
| seat depth (upright position) | 500 mm | |
| backrest height | 750 mm | |
| armrest height from seat | 220 mm | |
| extended footrest length | 450 mm | |
| IV pole total height from seat surface | 1200 mm | |
| frame tube wall thickness | 1.5 mm | |
| floor clearance under seat | 180 mm | |
| overall upright dimensions | 650 x 1150 x 1100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net weight range | 38 kg | |
|---|---|---|
| maximum static user weight capacity | 150 kg | |
| IV pole load capacity | 5 kg | |
| backrest recline angle range | 0° to 110° | |
| upholstery abrasion resistance | 100000 Martindale cycles | |
| upholstery disinfectant compatibility | resistant to 10% bleach and standard hospital-grade quaternary disinfectants | |
| design service life | 8 years | |
| available color options | 1 standard teal color, custom color available for bulk orders | |
| net product weight | 38 kg | |
| maximum backrest recline angle | 110° |
Core acceptance fields · Panels / hardware / frame / upholstery
| primary load frame | 1.5mm thick cold-rolled steel tube with silver powder-coated finish | |
|---|---|---|
| seat/back/legrest padding | 50mm thick high-density polyurethane foam, 40kg/m³ density, 45% rebound rate | |
| upholstery covering | 1.2mm thick medical-grade anti-bacterial waterproof vinyl, teal color | |
| armrest top padding | 20mm thick foam wrapped in matching teal vinyl, mounted to steel arm supports | |
| IV pole construction | 19mm diameter chrome-plated solid steel tubing with dual J-hooks at top | |
| footrest support structure | 1.2mm thick bent steel tube with powder-coated finish, connected to seat frame via hinge mechanism | |
| adjustment locking hardware | Zinc-plated steel pin lock and support brackets for backrest and footrest positions | |
| floor glides | Non-marking black rubber floor glides on all four frame legs | |
| upholstery seam construction | Reinforced stitched seams with 8 stitches per inch, sealed edges to prevent fluid ingress | |
| frame finish coating thickness | 60 micron epoxy powder coat, corrosion-resistant for clinical cleaning cycles | |
| primary load-bearing frame | 1.5mm thick cold-rolled steel tube with silver epoxy powder-coated finish, 60 micron coating thickness, corrosion-resistant for clinical cleaning | |
| floor contact glides | 30mm diameter non-marking black rubber floor glides with steel inserts on all four frame legs, anti-slip for hard clinical flooring |
Adjustment / rotation / tilt / mobility / storage features
| backrest recline adjustment | Manual ratchet lock adjustment with 4 fixed positions from upright (90°) to semi-reclined (110°), adjusted via side lever | |
|---|---|---|
| footrest operation | Flip-up extendable leg rest that locks into horizontal extended position, folds flush under seat when not in use | |
| IV bag support | Fixed-position rear-mounted IV pole with 2 curved hooks to hold standard IV fluid bags and infusion sets, no height adjustment visible | |
| side utility rail | Integrated 3-bar metal side rail on user's left to hold personal items or small medical accessories | |
| seated posture support | Contoured integrated headrest at top of backrest, lumbar support zone stitched into back panel, contoured leg cushion for lower leg support | |
| floor stability | Four-point fixed leg base with rubber glides to prevent sliding during patient transfer or adjustment, no casters visible | |
| cleaning access | Open frame design with 180mm floor clearance to allow mopping and disinfection under and around the chair without moving the unit | |
| armrest support | Fixed padded armrests on both sides to support patient arms during IV line placement and extended infusion sessions | |
| overall dimensions (reclined, footrest extended) | 650 x 1800 x 1100 mm | |
| patient accessory support | Integrated 3-bar steel side utility rail on user's left to hold personal items, small medical accessories or patient call buttons during treatment | |
| ergonomic posture support | Contoured integrated padded headrest at top of backrest, stitched lumbar support zone in mid-back panel, contoured leg cushion with calf cutout for lower leg pressure relief | |
| floor stability performance | Four-point fixed wide-stance leg base with anti-slip rubber glides, 600mm leg spread to prevent tipping during patient transfer or position adjustment, no casters installed |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 1 carton | |
|---|---|---|
| shipping carton dimensions | 680 x 670 x 970 mm | |
| shipping gross weight | 43 kg | |
| shipping volume per unit | 0.44 CBM | |
| assembly time on site | 10 minutes | |
| 20ft GP container loading quantity | 60 units | |
| 40ft GP container loading quantity | 128 units | |
| packaging material | 5-layer corrugated carton with 20mm EPE foam wrapping and corner protectors to prevent frame and upholstery damage in transit | |
| included hardware | Mounting bolts for IV pole, assembly instructions, spare floor glide | |
| shipping carton external dimensions | 680 x 670 x 970 mm |
Recommended spaces / users / usage modes
| Hospital outpatient infusion centers | Configured for extended seated intravenous therapy sessions, with recline and leg elevation support to reduce patient fatigue during 4 hour treatment sessions | |
|---|---|---|
| Community health clinics and vaccination centers | Durable, easy-to-disinfect fixed seating suitable for 100+ patient daily turnover in public primary care settings with minimal maintenance requirements | |
| Blood donation centers | 110° semi-reclining position supports optimal blood flow during phlebotomy and post-donation recovery periods, with fixed armrests for stable arm positioning | |
| Dialysis clinics and oncology treatment suites | Thick pressure-relieving padding and stable steel frame accommodates patients during 4+ hour long-duration treatment sessions, with disinfectant-resistant surfaces for infection control | |
| post-operative recovery areas | Adjustable position and arm support provides comfortable resting space for patients following minor procedures | |
| long-term care facilities | Low-maintenance, disinfectable surface and robust frame suitable for resident care and routine medical administration | |
| Post-operative minor procedure recovery areas | Adjustable recline position and contoured support provides comfortable resting space for patients following minor outpatient procedures before discharge | |
| Long-term care residential facilities | Low-maintenance fluid-impermeable surface and robust steel frame suitable for routine resident care, medication administration and minor medical treatment delivery |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable for structural load and stability testing | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette, required for clinical upholstery fire safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and Public Seating - Tests for strength, durability and stability, applicable for structural performance validation for high-traffic public medical areas |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to steel frame structural strength and finish durability for acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable to formaldehyde and VOC limits for any foam or adhesive components | |
| GB/T 19981.2-2014 | Textiles - Domestic laundering and drying procedures for textile testing, applicable to vinyl upholstery colorfastness to cleaning agents |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to steel frame structural strength and finish durability for acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable to formaldehyde and VOC limits for any foam or adhesive components; 3. GB/T 19981.2-2014: Textiles - Domestic laundering and drying procedures for textile testing, applicable to vinyl upholstery colorfastness to cleaning agents; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
