Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 780 mm | |
|---|---|---|
| Single seat width | 520 mm | |
| Seat depth | 480 mm | |
| Seat height from floor | 430 mm | |
| Backrest height above seat | 400 mm | |
| Armrest height above seat | 200 mm | |
| Leg spread width (left to right) | 1680 mm | |
| Leg spread depth (front to back) | 600 mm | |
| Seat divider bar width | 35 mm | |
| Floor clearance under seat | 320 mm | |
| Glide foot diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 28 kg | |
|---|---|---|
| Static load per seat | 150 kg | |
| Total static load capacity | 450 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| Surface abrasion resistance | 50000 cycles | |
| Anti-tip stability angle | 15 degrees | |
| Durability cycle rating | 100000 use cycles | |
| Number of seated users | 3 | |
| Maximum recommended user weight per seat | 130 kg | |
| Seated user capacity | 3 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat panels | 1.2mm thick perforated cold-rolled steel sheet, chrome plated finish | |
|---|---|---|
| Backrest panels | 1.2mm thick perforated cold-rolled steel sheet, chrome plated finish | |
| Structural armrests | 1.5mm thick bent chrome-plated steel tube, polished finish | |
| Central support cross beam | 2.0mm thick rectangular steel tube, black powder coated finish | |
| Leg assemblies | 1.5mm thick chrome-plated cast steel, 4-prong spider design | |
| Seat divider bars | 1.2mm thick curved chrome-plated steel strip, raised edge between seats | |
| Adjustable floor glides | Nickel-plated steel base with rubber contact pad, thread-adjustable height | |
| Surface treatment | Multi-layer chrome plating over steel components, 0.08mm minimum plating thickness | |
| Structural outer armrests | 1.5mm thick bent seamless chrome-plated steel tube, polished smooth edge finish | |
| Structural weld joints | Full penetration TIG welds at all frame connection points, ground smooth and chrome plated to match adjacent surfaces | |
| Panel edge treatment | Folded rounded hem on all exposed seat and back panel edges, 10mm fold radius to eliminate sharp cut edges | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Fixed gang seating configuration | 3 individual fixed seats without moving parts, no recline or height adjustment | |
|---|---|---|
| Perforated panel ventilation | Evenly distributed 3mm perforations across seat and back allow air circulation, prevents heat buildup during extended sitting | |
| Adjustable floor leveling | Threaded glides on all four leg ends adjust up to 15mm to level the bench on uneven floors | |
| Integrated armrest support | Outer armrests provide stable support for users standing up or sitting down, rounded edges prevent clothing snags | |
| Floor clearance access | 320mm open gap under the seat allows brooms, vacuum cleaners and floor cleaning equipment to pass underneath | |
| Rust-resistant exterior finish | Chrome-plated exterior surfaces resist water splashes, disinfection spray and regular cleaning for public hygiene requirements | |
| Fixed seat dividers | Raised curved dividers between seats delineate individual seating spaces, prevent unwanted contact between adjacent users | |
| Outer armrest support | Curved closed-loop outer armrests provide stable load-bearing support for users when sitting or standing, rounded 10mm edge radius prevents clothing snags and impact injury | |
| Open floor clearance access | 330mm unobstructed vertical gap under the seat allows brooms, commercial vacuum cleaners and floor scrubbers to pass fully underneath the bench | |
| Rust-resistant sanitizable finish | Smooth non-porous chrome-plated exterior surfaces resist water splashes, disinfection spray and repeated daily cleaning without finish degradation | |
| Raised seat dividers | 40mm wide raised curved dividers between seats delineate individual seating boundaries, prevent unwanted lateral contact between adjacent users | |
| Debris-resistant perforated design | Open perforations allow liquid spills, dirt and small debris to fall through seat panels instead of pooling on seating surfaces, reducing cleaning time |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1780 x 680 x 420 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.51 CBM | |
| Assembly time per unit | 30 minutes | |
| 20ft GP container loading quantity | 52 units | |
| 40ft HQ container loading quantity | 126 units | |
| Standard export packaging | 5-layer double-walled corrugated carton, 20mm EPS foam edge protection, plastic stretch wrap, hardware pack included | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | Durable sanitizable metal construction withstands high daily foot traffic and frequent disinfection without surface degradation | |
|---|---|---|
| Airport, railway and bus transit terminals | Low-maintenance perforated metal design resists heavy use, allows quick cleaning between passenger turns and prevents debris buildup on seats | |
| Bank and government service lobbies | Neutral chrome finish complements formal public service environments, fixed seating provides clear orderly queuing and waiting space | |
| Office reception and employee break areas | Compact 3-seat footprint fits small reception zones, open frame design maintains visual openness in small entry spaces | |
| Outdoor covered public waiting zones | Chrome-plated rust-resistant steel construction withstands temperature changes and humidity in bus shelters or covered walkways | |
| School and university public common areas | Robust construction resists impact and vandalism in student spaces, no upholstery means no tearing or staining risk | |
| Hospital and outpatient clinic waiting areas | Non-porous sanitizable metal construction withstands 24/7 high foot traffic and frequent medical-grade disinfection without surface damage | |
| Office reception and visitor waiting areas | Compact 3-seat footprint fits small entry zones, open frame design maintains visual openness in limited reception spaces |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety for non-domestic seating, applies to level 2 high-use public waiting areas including hospitals, transport hubs and offices | |
|---|---|---|
| EN 13761:2002 | Furniture - Public seating, applies to dimensions, accessibility and performance requirements for gang seating used in shared public spaces | |
| EN 1022:2018 | Furniture - Seating - Determination of stability, applies to anti-tip testing for stationary fixed-position benches |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applies to structural strength, edge treatment and coating adhesion testing for this steel waiting bench | |
|---|---|---|
| GB/T 10357.2-2013 | Furniture mechanical performance test for chairs and stools: stability, applies to anti-tip verification of the 4-leg bench structure | |
| GB/T 10357.3-2013 | Furniture mechanical performance test for chairs and stools: strength and durability, applies to static load, impact and fatigue testing of seats and backrests | |
| GB 28007-2011 | Safety requirements for children's furniture, applies to edge rounding and small part safety if the bench is installed in spaces accessible to children |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applies to structural strength, edge treatment and coating adhesion testing for this steel waiting bench; 2. GB/T 10357.2-2013: Furniture mechanical performance test for chairs and stools: stability, applies to anti-tip verification of the 4-leg bench structure; 3. GB/T 10357.3-2013: Furniture mechanical performance test for chairs and stools: strength and durability, applies to static load, impact and fatigue testing of seats and backrests; 4. GB 28007-2011: Safety requirements for children's furniture, applies to edge rounding and small part safety if the bench is installed in spaces accessible to children; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
