Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1900 x 750 x 780 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat depth (front edge to back cushion front face) | 580 mm | |
| Seat width per individual position | 560 mm | |
| Backrest height from seat surface | 330 mm | |
| Armrest height from floor | 620 mm | |
| Armrest width (rail cross-section) | 20 mm | |
| Leg height (floor to bottom of seat frame rail) | 300 mm | |
| Leg cross-section dimension | 30 mm | |
| Seat cushion thickness (uncompressed) | 120 mm | |
| Back cushion thickness | 100 mm | |
| Underseat clearance height | 280 mm | |
| Seat Cushion Thickness | 180 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Net product weight | 42 kg | |
|---|---|---|
| Total static load capacity (distributed across seats) | 360 kg | |
| Seat foam density | 40 kg/m³ | |
| Seat foam compression resilience | 42 % | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Recommended maximum user count | 3 adults | |
| Structural frame static load test rating | 600 kg | |
| Expected structural warranty | 5 years | |
| Cushion thickness (seat, compressed under standard load) | 120 mm | |
| Back foam density | 30 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary support frame | 1.8mm thick square steel tube with dark bronze powder coated finish | |
|---|---|---|
| Armrest rails | 20mm square steel tube matching frame finish, welded to leg and seat frame assembly | |
| Legs | Tapered square steel legs with matching bronze finish, fitted with non-marking polymer floor glides | |
| Seat cushion core | High-density polyurethane foam wrapped with 20mm soft polyester fiber batting | |
| Back cushion core | Medium-density polyurethane foam with fiber wrap, fixed to internal back support panel | |
| Upholstery fabric | Woven polyester blend fabric in terracotta color, matte textured finish | |
| Seat support base | 8mm thick plywood panel fixed to steel frame, supporting seat cushions | |
| Fabric seam stitch pitch | 8 stitches per inch | |
| Floor protection components | 5mm thick injection-molded polyethylene glides, fitted to base of each leg | |
| Back support panel | 6mm thick bent plywood panel attached to rear frame rail, securing back cushions | |
| Internal frame welds | Full-penetration fillet welds at all tube joints, ground smooth before powder coating | |
| Fabric fire retardant treatment | Optional NFPA 260 compliant fabric treatment available for commercial hospitality and office installations |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Three separated, fixed seat cushions with matching fixed back cushions, no recline or adjustment mechanisms | |
|---|---|---|
| Arm support | Continuous thin metal arm rails on both left and right sides, integrated directly into the structural frame for rigid arm support | |
| Floor protection | Non-marking glides on all six leg contact points, designed to prevent scratching on hard floor surfaces including wood, tile and polished concrete | |
| Assembly requirement | Knock-down construction with frame sections and cushions shipped separately, requiring bolted assembly of leg and frame components on site | |
| Cleaning access | Cushions are non-removable, requiring on-surface upholstery cleaning per fabric care instructions | |
| Stability design | Six-point leg support (front left, center left, rear left, front right, center right, rear right) for even weight distribution and reduced frame flex on uneven floors | |
| Upholstery color option range | 1 standard terracotta fabric option, with optional custom fabric options available for volume orders | |
| Load distribution | Perimeter steel frame transfers occupant load directly to legs without intermediate cross-braces that would block underseat cleaning access | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 2 | |
|---|---|---|
| Largest package dimensions (L x W x H) | 1950 x 780 x 280 mm | |
| Total shipping gross weight | 48 kg | |
| Total shipping volume (CBM) | 0.58 CBM | |
| On-site assembly time (two people) | 40 minutes | |
| 20ft GP container loading quantity (fully assembled knock-down) | 72 units | |
| 40ft HQ container loading quantity (fully assembled knock-down) | 186 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Sized for three-person seating in corporate lobbies, waiting rooms and visitor zones, with durable construction for regular daily use | |
|---|---|---|
| Open plan office casual lounge zones | Low-profile minimal frame fits collaborative breakout areas, providing upright seating for informal meetings and short breaks | |
| Hotel public areas and lounge spaces | Warm terracotta fabric and refined metal finish suit boutique hotel lobbies, corridor waiting points and guest lounge areas | |
| Residential open-plan living spaces | Slim frame profile works for modern minimalist and industrial style home living rooms, occupying minimal visual space | |
| Co-working space common areas | Robust metal frame and high-wear fabric specification supports high-traffic shared workspaces, with fixed cushions that resist displacement during frequent use | |
| Retail store customer waiting zones | Compact footprint fits small retail checkout waiting areas and fitting room lounges, with easy-to-clean fabric for high-turnover use |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Furniture – Seating – Determination of stability, applicable for static stability verification for domestic and contract lounge seating | |
|---|---|---|
| EN 16139:2013 | Furniture – Strength, durability and safety – Requirements for non-domestic seating, applicable for light-duty contract reception use | |
| EN 13759:2011 | Furniture – Test methods for assessment of surface resistance to cold liquids, applicable for frame finish and fabric stain resistance testing | |
| EN 14465:2003 | Textiles – Upholstery fabrics – Specification and test methods, applicable for fabric strength, abrasion and colorfastness verification |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural strength and finish durability testing of the steel frame | |
|---|---|---|
| GB/T 1952.1-2012 | General technical requirements for upholstered sofas, applicable for cushion performance, structural stability, and upholstery durability testing | |
| GB 18584-2001 | Indoor decorating and refurbishing materials – Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for internal plywood components | |
| GB 20286-2006 | Requirements and mark on burning behavior of fire retarding products and subassemblies in public places, applicable for public area installation fire performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural strength and finish durability testing of the steel frame; 2. GB/T 1952.1-2012: General technical requirements for upholstered sofas, applicable for cushion performance, structural stability, and upholstery durability testing; 3. GB 18584-2001: Indoor decorating and refurbishing materials – Limit of harmful substances of wood based furniture, applicable for formaldehyde emission limits for internal plywood components; 4. GB 20286-2006: Requirements and mark on burning behavior of fire retarding products and subassemblies in public places, applicable for public area installation fire performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
