Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 680 x 800 mm | |
|---|---|---|
| Per-seat usable width | 500 mm | |
| Seat height from floor | 430 mm | |
| Seat depth | 450 mm | |
| Backrest height above seat | 370 mm | |
| Armrest height above seat | 200 mm | |
| Leg span width (end to end) | 1650 mm | |
| Floor to under-seat clearance | 320 mm | |
| Perforated panel thickness | 1.5 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 32 kg | |
|---|---|---|
| Static load per seat | 200 kg | |
| Total static load for full unit | 600 kg | |
| Recommended occupancy | 3 adults | |
| Surface abrasion resistance | 50000 cycles | |
| Anti-rust coating performance | 200 hours salt spray resistance | |
| Seam weld static strength | 1000 kg | |
| Net unit weight | 32 kg | |
| Static load per seat position | 200 kg | |
| Total unit static load capacity | 600 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat panels | 1.5mm perforated cold-rolled steel with silver epoxy powder coating | |
|---|---|---|
| Backrest panels | 1.5mm perforated cold-rolled steel with silver epoxy powder coating | |
| Armrests | 20mm diameter bent steel tube with polished chrome-plated finish | |
| Support legs | 3mm thick die-cast aluminum alloy with silver powder coated finish | |
| Seat-back connecting brackets | 3mm thick cold-rolled steel with anti-corrosion coating | |
| Foot glides | Chrome-plated steel base with non-marking rubber pad | |
| Frame cross beams | 40x20mm rectangular steel tube with powder coated finish | |
| End support legs | 3mm thick die-cast aluminum alloy with silver powder coated finish, tri-stance spread base | |
| Side seat support frames | 2.5mm thick cold-rolled steel with powder coated finish, integrated with armrest mounts | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 3-position linked gang seating | |
|---|---|---|
| Ventilation design | Perforated seat and back panels | |
| Floor stabilization | Adjustable threaded glide feet | |
| Surface maintenance | Smooth anti-static powder coated finish | |
| Armrest support | Fixed curved armrests at both outer ends of the unit | |
| Structural rigidity | Triangular gusset brackets at seat-to-leg joints | |
| Cleaning access | 320mm under-seat clearance | |
| Seating structure | Fixed 3-position linked gang seating, no moving or adjustable components, permanent connected configuration for high-capacity public waiting use | |
| Ventilation performance | Uniform 5mm diameter perforations across full seat and back panels, 30% open area ratio to enable continuous air circulation and prevent heat buildup during extended sitting | |
| Cleaning compatibility | Seamless anti-static powder coated metal surfaces with no fabric upholstery, enabling wipe-down disinfection with standard public area cleaning agents without trapping dirt or contaminants | |
| Standing assistance | Fixed curved armrests mounted at both outer ends of the unit, providing stable handholds to support users when standing from outermost seat positions | |
| Joint reinforcement | Triangular gusset brackets at all seat-to-leg and seat-to-back joints, distributing dynamic load across the frame to prevent permanent deformation after repeated use |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 1850 x 730 x 180 mm | |
| Gross shipping weight | 38 kg | |
| Shipping volume per unit | 0.243 CBM | |
| On-site assembly time | 25 minutes | |
| 20ft container loading capacity | 110 units | |
| 40ft HQ container loading capacity | 270 units | |
| 20ft dry container loading capacity | 110 units | |
| 40ft high-cube container loading capacity | 270 units | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Hospital outpatient waiting areas | All-metal non-upholstered construction supports frequent disinfection and continuous high-volume use for patient and visitor seating | |
|---|---|---|
| Airport and railway station transit waiting zones | 3-seat high-capacity configuration with durable metal finish withstands heavy traffic, abrasion and constant public use | |
| Bank and government service hall waiting areas | Stable fixed seating configuration provides orderly queuing seating with easy cleaning and long service life | |
| Clinic and vaccination center waiting spaces | Ventilated perforated surface and wipe-clean finish meet hygiene requirements for healthcare settings | |
| Office building reception waiting areas | Neutral silver metal finish complements modern commercial interiors with minimal maintenance requirements | |
| Public service center queuing areas | Fixed gang configuration prevents unauthorized rearrangement of seating layout in managed public spaces | |
| Office building reception lobbies | Neutral silver metallic finish complements modern commercial interior design, with durable construction that maintains appearance with only routine cleaning for visitor waiting use | |
| Bus terminal and ferry terminal waiting areas | Corrosion-resistant powder coated finish resists exposure to outdoor moisture and tracked-in road salt, with high load capacity to accommodate luggage placed on seat surfaces |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety - Non-domestic seating, applicable for public area seating performance and safety requirement verification | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable for verification of anti-tip stability when users lean on backrests or armrests |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for dimensional tolerance, finish quality and structural strength verification of this metal waiting chair | |
|---|---|---|
| GB/T 10357.3-2013 | Furniture mechanical performance test for seating strength and durability, applicable for static load, impact and fatigue testing of seat and back components | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for coating heavy metal and VOC limit verification for the powder coat finish | |
| GB/T 10357.2-2013 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for dimensional tolerance, finish quality and structural strength verification of this metal waiting chair; 2. GB/T 10357.3-2013: Furniture mechanical performance test for seating strength and durability, applicable for static load, impact and fatigue testing of seat and back components; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable for coating heavy metal and VOC limit verification for the powder coat finish; 4. GB/T 10357.2-2013: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
