Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 620 x 440 mm | |
|---|---|---|
| Individual seat width | 500 mm | |
| Seat depth from front edge to beam | 420 mm | |
| Seat height to top of seat surface | 440 mm | |
| Integrated table top dimensions | 500 x 480 mm | |
| Table height above floor | 440 mm | |
| Support leg splay width | 550 mm | |
| Floor glide diameter | 50 mm | |
| Central connecting beam cross-section | 150 x 80 mm | |
| Seat front overhang past beam | 120 mm | |
| Clearance under seat to floor | 300 mm | |
| Leg vertical post diameter | 50 mm | |
| Integrated end table top dimensions | 550 x 480 mm | |
| Perimeter edge radius on seats and table | 15 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| Unit net weight | 22 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended user capacity | 2 seated users, table for shared item placement | |
| Floor glide vertical adjustment range | 15 mm | |
| Expected service life in high-traffic areas | 8 years | |
| Seat surface impact resistance | 10 J | |
| Unit lateral stability load threshold | 80 kg | |
| Surface abrasion resistance | 20000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat/table surfaces | Integrally molded polyurethane (PU) | |
|---|---|---|
| Central support beam | 2.0mm thick cold-rolled steel with black powder-coated finish | |
| Leg assemblies | 1.5mm thick polished chrome-plated steel | |
| Seat-to-beam mounting brackets | 3.0mm thick black powder-coated steel | |
| Floor glides | Injection-molded nylon base with rubber anti-slip pad | |
| Hardware fasteners | Zinc-plated steel bolts and lock nuts | |
| Surface edge treatment | Radius-molded rounded edges on all seat and table perimeters | |
| Chrome plating thickness on legs | 0.25 mm | |
| Seat underside reinforcement | Integrated molded PU ribbing 3mm thick | |
| Powder coating finish on central beam | 60 micron thick matte black polyester powder coat | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Leveling adjustment | Individual floor glides rotate to adjust height 15mm to compensate for uneven floors, no tools required for minor adjustments | |
|---|---|---|
| Floor mounting capability | Pre-drilled holes in glide bases allow permanent anchoring to concrete or tile floors to prevent unit shifting | |
| Easy surface cleaning | Seamless molded PU surfaces allow wipe-down disinfection with common commercial cleaning agents, no fabric seams to trap debris | |
| Integrated table utility | Central flush-mounted table surface provides shared space for personal items, reading materials, or electronic devices between two seating positions | |
| Anti-tip stability | Wide flared leg design places four contact points 550mm apart across the unit depth, eliminating forward or sideways tipping under normal seated load | |
| Modular connection compatibility | Ends of central support beam include pre-tapped connection points to link additional seating units into extended continuous rows | |
| Color customization | Individual seat and table segments can be specified in alternate PU colors to match space branding or wayfinding requirements | |
| Integrated end table utility | End-mounted flush table surface provides dedicated space for personal items, reading materials, or electronic devices adjacent to one seating position | |
| Replaceable segments | Individual seat or table units can be unbolted from the central beam for replacement if damaged, without disassembling the entire bench | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1780 x 650 x 180 mm | |
| Gross shipping weight | 27 kg | |
| Shipping volume per unit | 0.21 CBM | |
| On-site assembly time | 30 minutes | |
| 20ft GP container loading quantity | 130 units | |
| 40ft HQ container loading quantity | 320 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Hospital outpatient waiting areas | Non-porous easy-clean surfaces support frequent disinfection, armless design accommodates users of all sizes, integrated table holds patient paperwork or personal items | |
|---|---|---|
| Airport/rail transit terminal waiting zones | Heavy-duty steel frame supports continuous high-volume use, chrome legs resist scuffing from luggage, floor anchoring prevents shifting in high-foot-traffic corridors | |
| Public service office waiting rooms | Compact footprint fits narrow corridor spaces, multi-color segment design can be used for queue zone marking, durable surfaces resist wear from daily public use | |
| School/educational facility common areas | Smooth rounded edges reduce injury risk, stable design prevents tipping during rough use, open under-seat clearance allows easy floor cleaning | |
| Reception areas for commercial offices | Sleek polished chrome frame and multi-color aesthetic pairs with modern reception interiors, integrated table eliminates need for separate side tables for visitor items | |
| Outdoor covered waiting pavilions | Powder-coated steel and chrome-plated components resist light moisture exposure, PU surfaces do not degrade from incidental sun exposure under covered areas | |
| Covered outdoor entry waiting pavilions | Powder-coated steel and chrome-plated components resist light moisture exposure, PU surfaces do not degrade from incidental sun exposure under covered areas | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Non-domestic seating performance requirements for public area seating, covering strength, stability, and durability for heavy-use environments | |
|---|---|---|
| EN 12727:2000 | Furniture seating test methods for strength and durability of linked gang seating units | |
| EN 1022:2005 | Seating stability test standard applicable to armless multiple-position public benches |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to metal furniture for public seating, covering structural stability, dimensional tolerances, and finish durability | |
|---|---|---|
| GB/T 24821-2009 | Performance standard for public waiting seating, specifying static load, impact resistance, and fatigue testing requirements | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden/furniture components, applicable to surface coating and material emission limits | |
| GB/T 10357.3-2013 | Furniture mechanical test for seating strength and durability, applicable to seat and back load cycle testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to metal furniture for public seating, covering structural stability, dimensional tolerances, and finish durability; 2. GB/T 24821-2009: Performance standard for public waiting seating, specifying static load, impact resistance, and fatigue testing requirements; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden/furniture components, applicable to surface coating and material emission limits; 4. GB/T 10357.3-2013: Furniture mechanical test for seating strength and durability, applicable to seat and back load cycle testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
